Whirlpool AD40LJ0 User manual

Contents

Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Installing dehumidifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Operating dehumidifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Removing and emptying water bucket . . . . . . . . . . . . . . . . . . . .6-7

Water level float and automatic shutoff . . . . . . . . . . . . . . . . . . . .8

Caring for your dehumidifier . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

If you need assistance or service . . . . . . . . . . . . . . . . . . . . . .10-11

Dehumidifier

Use & Care Guide

Part No. 1183900 Rev. A

WARNING — To reduce the risk of fire, electrical shock, injury or

sickness when using your dehumidifier, follow these basic precautions:

• Plug into a grounded 3 prong

outlet.

• Do not remove ground prong.

• Do not use an adapter.

• Do not use an extension cord.

• Unplug dehumidifier before

servicing.

• Do not drink water collected in the

water bucket.

— SAVETHESE INSTRUCTIONS —

It is your responsibility to:

• Install the dehumidifier according to the Installation Instructions.

• Connect the dehumidifier only to the proper kind of outlet, with the correct

electrical supply and ground. See “Electrical requirements,” page 3.

IMPORTANT SAFETY INSTRUCTIONS

Safety information

Your safety and the safety of others

are very important.

We have provided many important safety messages in this manual and on

your appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you

and others.

All safety messages will follow the safety alert symbol and either the word

“DANGER” or ‘“WARNING.” These words mean:

DANGER

WARNING

All safety messages will tell you what the potential hazard is, tell you how to

reduce the chance of injury, and tell you what can happen if the instructions

are not followed.

You can be killed or seriously injured if you don’t follow instructions.

You can be killed or seriously injured if you don’t immediately follow

instructions.

Electrical requirements 3

WARNING Grounding instructions:

A 115-volt (103.5 min., 126.5 max.),

60-Hz, AC-only, 15- or 20-ampere fused

and properly grounded electrical

supply is required. A time-delay fuse or

time-delay circuit breaker is

recommended. Use a separate circuit to

connect only the dehumidifier.

For your personal safety, this

dehumidifier must be grounded. This

dehumidifier is equipped with a power

supply cord having a 3-prong ground

plug.

To minimize possible shock hazard, the

cord must be plugged into a mating

3-prong ground-type outlet, grounded

in accordance with local codes and

ordinances. If a mating outlet is not

available, it is the personal

responsibility and obligation of the

customer to have the properly

grounded outlet installed by a qualified

electrician.

Electrical Shock Hazard

Plug into a grounded 3 prong

outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these

instructions can result in death,

fire, or electrical shock.

3-prong

ground plug

3-prong ground-type

outlet

ground

prong

power supply cord

Safety information

Install dehumidifier on a level floor strong enough to support the

dehumidifier with a full bucket of water.

Good air circulation is needed

for best performance—allow

at least 12-18 inches (30.5 -

45.7 cm) of air space on all

sides of the dehumidifier.

Keep all outside doors,

windows and other

openings closed when

operating dehumidifier.

Humid outdoor air will

increase dehumidifier

workload.

Installing dehumidifier

12-18"

(30.5 - 45.7 cm)

12-18"

(30.5 - 45.7 cm)

Safety information 5

Operating dehumidifier

FAN SPEED:

Some models: this controls fan

operation. Use desired setting.

HIGH - for faster moisture removal.

LOW - for slower moisture removal.

EMPTY/ADJUST BUCKET light:

If this light is on, the dehumidifier is

not running. This light indicates that

you need to check:

• If the bucket is full, empty bucket

and replace.

• If the bucket is not in position,

remove bucket and replace. Make

sure the bucket fits all the way into

the dehumidifier and the light is off,

or dehumidifier will not run.

DRYNESS CONTROL:

This controls the amount of moisture in

the room.Turn the control knob

clockwise for more drying. Turn the

control knob counterclockwise for less

drying.Turn control knob to “NORMAL”

to maintain average humidity

conditions.

NOTE: For the first few days of use, turn

the Dryness Control clockwise to

“DRYEST” to remove extra moisture

from the furnishings as well as the

room air.

FAN SPEED

HIGH

LOW

DRYNESS CONTROL

EMPTY/ADJUST

BUCKET

OFF CONTINUOUS

Removing & emptying water bucket

Bucket method:

Bucket styles:

1. Use both side handles to lift bucket.

Pull bucket forward and remove.

Go to Step 2.

3. Pour water through opening into a

sink or tub.

4. Replace bucket completely and

check that EMPTY/ADJUST BUCKET

light is off.

WARNING

Sickness Hazard

Do not drink water collected in water bucket.

Doing so can result in sickness.

1. Lift bucket from bottom. Pull bucket

forward and remove. Go to Step 2.

style 1 style 2

2. Carry bucket to a large sink or tub.

Bucket style 2

Bucket style 1

Removing & emptying water bucket 7

Drain hose connection method:

(to drain water from bucket continuously)

Do Not

damage

outside or

connection

will leak.

drain hose

connector cover

(not on all models)

center of drain hose connector

3. Attach a garden hose to drain hose

connector. The garden hose should

not be longer than 8 feet (2.4 m). Run

other end of garden hose into a floor

drain. Check that the hose lies flat

and in the drain.

To use the bucket without the garden hose:

For bucket style 1:

Use a garden hose cap to seal the drain

hose connector.

For bucket style 2:

Use a garden hose cap to seal the drain

hose connector.

Replace drain hose connector cover.

1. If your dehumidifier does not have

a drain hose connector cover, go to

Step 2.

If your dehumidifier has a drain

hose connector cover, use a flat-

blade screwdriver to remove cover

from drain connector. Turn cover

counterclockwise. Discard cover. It

cannot be reused. Go to Step 2.

2. Drill out only the center of the drain

hose connector. Use a minimum 1/4"

drill bit.

Bucket style 1

1. Slide off the drain hose connector

cover. Go to Step 2.

Bucket style 2

Safety information

Water level float & automatic shutoff

For models with non-adjustable

Water Level Float:

For models with adjustable

Water Level Float:

All dehumidifiers have automatic

shutoff and a water level float. Some

dehumidifiers feature an adjustable

Water Level Float. The bucket must be

properly aligned for the Water Level

Float to work.

The Water Level Float will shut off the

dehumidifier automatically.

You can set the adjustable Water Level

Float at the “high” or “low” position. Both

settings will turn off the dehumidifier

automatically.

“High” setting: Water Level Float is

preset to the “high” position—left side

of opening.The dehumidifier will shut

off automatically when bucket is 3/4

full.

“Low” setting: Slide Water Level Float to

“low”position—right side of opening

— to make the bucket lighter to carry.

The dehumidifier will shut off

automatically when bucket is 1/2 full.

Safety information

Caring for your dehumidifier 9

General cleaning and

maintenance

1. Dust the front grille and side panels

with a soft brush or the dusting

attachment of your vacuum.

2. If cabinet paint chips, you can touch

up the paint with a good grade

enamel paint to prevent rust.

Water bucket cleaning

Every few weeks, rinse the inside

of the water bucket with

a mild detergent

to prevent growth

of mold, mildew

and bacteria.

MILD

DETERGENT

You may clean the exterior of your product:

Interior coils should be cleaned every year, or more often,

depending on dehumidifier usage. Cleaning should be done by a

qualified person.

Safety information

10 If you need assistance or service…

1. Before calling for

assistance…

Performance problems often result

from little things you can find and fix

yourself without tools of any kind.

Dehumidifier will not run:

• Is unit plugged into a live circuit with

proper voltage?

• Is unit turned on?

• Is water bucket installed properly?

• Does water bucket need emptying?

• Has a house fuse blown or circuit

breaker tripped?

Unit runs but does not dehumidify:

• Is unit in defrost cycle? (Provided on

some models.)

Normal operating sounds:

When your dehumidifier is operating

normally,you will hear sounds such as:

• Compressor sounds—the compressor

can be loud.This is normal.

• “Clicking” sounds—can be heard when

the unit or compressor turns off and

on, and when the Automatic Shutoff

Switch is working.

• Air movement from the fan.

Normal operating conditions:

• Unit will put out heat.

If you need service or call with a question, have this information ready:

Model number

Serial number

Purchase date

Phone number

Store

Model and serial numbers are located on the wall behind the water bucket.

2. If you need assistance in

the U.S.A.…

Call your local dealer or the Whirlpool

Consumer Assistance Center toll-free

at 1-800-253-1301. When requesting

assistance, please provide model

number, serial number, date of

purchase, and a complete description

of the problem.This information is

needed to better respond to your

request.

If you need further assistance, you can

write to:

Consumer Assistance Center

c/o Correspondence Dept.

2000 North M-63

Benton Harbor, MI 49022-2692

Please include a daytime phone

number in your correspondence.

Table of contents

Languages:

Other Whirlpool Dehumidifier manuals

Whirlpool

Whirlpool WDH70EAPW User manual

Whirlpool

Whirlpool AD35DSS0 User manual

Whirlpool

Whirlpool Coolerator User manual

Whirlpool

Whirlpool AD0402XM0 User manual

Whirlpool

Whirlpool TD2500XF0 User manual

Whirlpool

Whirlpool ADO15 User manual

Whirlpool

Whirlpool AD50GUSB User manual

Whirlpool

Whirlpool AD65USM2 User manual

Whirlpool

Whirlpool WPDV160XS User manual

Whirlpool

Whirlpool BFD500 User manual

Whirlpool

Whirlpool AD35USS1 User manual

Whirlpool

Whirlpool DS201NB User manual

Whirlpool

Whirlpool AD35DSS1 User manual

Whirlpool

Whirlpool AD25DSS0 User manual

Whirlpool

Whirlpool AD25BBK0 User manual

Whirlpool

Whirlpool WHAD701AW User manual

Whirlpool

Whirlpool 1ADM202XX0 User manual

Whirlpool

Whirlpool 1185020 User manual

Whirlpool

Whirlpool BHDH2500FS0 User manual

Whirlpool

Whirlpool WHAD703PAW User manual

Whirlpool

Whirlpool Dehumidifier User manual

Whirlpool

Whirlpool 1184914-W Parts list manual

Whirlpool

Whirlpool BHDH2500AS1 User manual

Whirlpool

Whirlpool AD40DSS0 User manual

Popular Dehumidifier manuals by other brands

Daitsu

Daitsu CD031IU-DFA owner's manual

Fehom

Fehom PDGT701BE user manual

Hitachi

Hitachi RD-190GX instruction manual

Westpoint

Westpoint MDF1-30AE instruction manual

SOLIS

SOLIS easy dry compact user manual

ENVIROBOSS

ENVIROBOSS EB240 owner's manual

Sinclair

Sinclair R-9112 instruction manual

Kenmore

Kenmore 580.54701 owner's manual

Demargo

Demargo DM828NF Installation and operating instructions

Altrad Lescha

Altrad Lescha LDH 600 Original instructions

BOMANN

BOMANN LE 1150 CB instruction manual

SPT

SPT SD-46 instruction manual

REMKO

REMKO SLN 40 Operation,technology,spare parts

Haier

Haier HD458 user manual

Logik

Logik L20DHW12 instruction manual

Frigidaire

Frigidaire FDR30S1 - 30 Pint Capacity Dehumidifier Wiring diagram

Blitz

Blitz HHD Series Operation and maintenance manual

Prem-I-Air

Prem-I-Air PD14DEN instruction manual
