Wharfedale Pro V 12M User manual

www.wharfedalepro.com

OPERATING MANUAL AND USER GUIDE

PROFESSIONAL SOUND SYSTEMS

V Series

V 10

V 12

V 12M

V 15

V 153

V 15B

V 18B

OPERATING MANUAL AND USER GUIDE

IMPORTANT WARNINGS & SAFETY INSTRUCTIONS

1. READ ALL INSTRUCTIONS – carefully and become familiar with the features and functions of these

products before operating them.

2. RETAIN THESE INSTRUCTIONS – for future reference.

3. COMPLY WITH ALL WARNINGS – All warnings and instructions for this product should be adhered to.

4. USE WITH AMPLIFIERS – In order to avoid damage to drivers and other equipment, it is advisable to

establish and follow a routine for powering up and powering down a sound system. With all system

components connected, turn on source equipment (mixers, signal processors, record and playback

units, etc.) BEFORE powering up ampliers. Transient voltages from powering up source equipment

can damage speakers if ampliers are already turned on. Make sure that amplier volumes are set to

their minimum settings and power up any system ampliers LAST. It is recommended that all system

components be allowed to stabilize for several seconds before any source signals are introduced

or level setting adjustments are made. Similarly, when shutting systems down, turn all ampliers off

rst, before powering down any other system components.

5. CABLES – Do not use shielded or microphone cables for connection between amplifiers and

speakers. Use only approved speaker cables with proper connectors.

6. CAUTION – These professional loudspeaker systems are capable of generating very high sound

pressure levels. Use care with placement and operation to avoid exposure to excessive volume

levels. Permanent hearing damage can result when operated to extreme levels.

7. SERVICE – There are no user serviceable parts inside this product. Users should not attempt to

service this product. Warranty nullication could result if this is attempted.

V Series

TABLE OF CONTENTS

Important Warnings and Safety Instructions…………………………....….…

W h a t a b o u t t h e V S e r i e s ………………………………………………………

Introduction / Overview……………………………………………………....….…

F e a t u r e s ……………………… . …………………………………… . …………… . . . . .

Setting up / Speaker Placement…………………………….………..................

Connections / Wiring……………………………………………………................

V series full rang and subwoofer connection plate…………………

Connection Diagram……………………….………………………….......………

S p e c i f i c a t i o n s …………………………………… . ………………………… . ………

Dimensional Drawings-V10/ V12/ V12M /V15 ………………….......

Dimensional Drawings-V153/V15B/ V18B……....………………….....

Warranty…………………………..……....…………………………..……...........

OPERATING MANUAL AND USER GUIDE

INTRODUCTION

Wharfedale V Series loudspeakers are the result of many years of experience in the use, design

and manufacturing of professional loudspeaker products. We take great pride in engineering and

building every Wharfedale Pro loudspeaker and wish to thank you for entrusting us with your sound.

From the time Gilbert Briggs built his first loudspeaker in 1932, to the present, Wharfedale

Loudspeakers have maintained the same standard of quality in components, workmanship and

performance. Actually, Wharfedale is one of a few present day manufacturers that design, engineer

and build all of their own transducers.

Please take a few minutes to read this manual completely in order to ensure that you get the most

out of your V Series Loudspeaker system.

V SERIES OVERVIEW:

The V Series are powerful, accurate, high quality loudspeaker systems with low distortion that were

designed to deliver high quality sound for the best value. From the V10 to the V153 plus the high-

powered subs, you have what it takes to assemble the system that your music deserves. Other

models to satisfy your most demanding sound needs include: V12 ,V12M, V15, and the V15B and

V18B Subwoofers.

An important factor in loudspeakers, is the smoothness of the sound coverage. Many speakers

that may sound great directly in front of them and in the horizontal plane have problems in the

vertical plane. The V Series™ speakers exhibit very smooth and well-behaved sound dispersion

characteristics in both the horizontal and vertical planes making positioning and set-up less

troublesome. Everyone on stage or in the audience will hear the same, high-quality sound. Because

of the trapezoidal cabinet design, the V-Series speakers can be positioned on the oor as a stage

monitor or mounted on a speaker stand.

When you need that extra bass punch, you can choose the V15B and the V18B reex subwoofers.

WHAT ABOUT THE V SERIES ?

Wharfedale V Series sound reinforcement speakers are designed for demanding sound

reinforcement applications.

The V Series loudspeakers are high quality, passive speaker systems designed to provide the

best sound in a powerful, feature laden, and easy to use package. They provide transparent

and accurate sound reproduction or reinforcement. The 25.4mm (1.0”) Phenolic high frequency

compression driver projects crystal clear high frequencies. A proprietary 90° x 60° Eliptical Wave

Guide (EWG) delivers the high frequencies in a well dened, even coverage pattern.

The V Series is very exible in application. With its heavy-duty grille, pocket handles, stand socket

and durable carpet nish, the V Series can rise to any sound reinforcement challenge.

V Series

♦2-way trapezoidal + multifaceted reflex systems

♦Passive Subwoofers

♦1.0 inch (25.4 mm) Phenolic diaphragm HF driver

♦Low distortion, high power, steel frame woofers

♦90° x 60° High Frequency Eliptical Wave Guide (EWG)

♦High slope internal crossover

♦Overcurrent driver protection (PTC)

♦Powerful 6.5 in. (165mm) mid-range speaker (V153)

♦High power 2” voice coil subwoofer (V15B)

♦High power 2.5” voice coil subwoofer (V18B)

♦Covered in rugged black carpet

♦Rugged handles

♦Integrated Stand adapter

♦2 x 1/4” input connectors (V10/12/12M/15/153)

♦3 x 1/4” input connectors (V15B/18B)

FEATURES

OPERATING MANUAL AND USER GUIDE

SETTING UP/ SPEAKER PLACEMENT

The uniform dispersion of the V Series Series makes it easy to position the speakers where you

need them, rather than trying to rearrange the room to accommodate the sound system. And the

trapezoidal shaped cabinet with heavy duty handles makes transporting the speakers that much

easier. An integral stand socket allows you to place the speakers high above the audience for best

sound coverage.

When you don’t think you are getting all the bass you need, the V Series has a couple of great

subwoofers: the V15B and V18B. These are powerful bass reflex subwoofers that give you the

lowest frequencies and the punch you need. They are straight forward, no nonsense, bass reex

subwoofers with exceptional low frequency response.

CONNECTIONS / WIRING

Connecting the V Series to your system is easy. The input panel includes parallel TS 6.35mm (1/4”)

connectors. Run your speaker wires from your amplier, to the speaker; you can use either input

connector. Be sure to use high quality, low gauge (thick) speaker wire and NOT shielded cable —

for

all speaker connections.

1/4” Jack Plug

The V15B and V18B Subwoofers have Hi-pass output jacks so you can use just one channel of

an amplier for your full range system including a subwoofer. Run your speaker wires to the input

of the sub and another speaker wire from the subwoofer hi-pass output jack to the input of the full

range speaker on a stand or sitting atop the sub. Placement depends on your sound coverage

requirements.

Ring= - on amp

terminal

Tip= + on amp

terminal

V Series

V SERIES FULL RANGE AND SUBWOOFER CONNECTION

PANEL

The V-10, V-12, V-12M,V-15 and V-153 feature two 1/4” phone jack socket connectors and are

paralleled. This means that these cabinets can be linked together with other cabinets of the same

impedance and design or with a subwoofer speaker. (See drawing)

Rear panel for

V-10/12/12M/15/153

Rear panel for

V-15B/18B

The V-15B, V-18B have three 1/4” phone jack.Two 1/4” phone jack are paralleled at the rear of

each cabinet. The other 1/4” phone jack allows connection to MID/HI output .

In the (standard) passive mode, the power amplier can be connected to the V-15B or 18B system

through the system’s internal low pass filters. The V Full Range Speaker is connected from the

input/output connector panel and receives a full range signal via the sub cabinet. (See drawing)

OPERATING MANUAL AND USER GUIDE

CONNECTION DIAGRAM

connecting multiple v series speakers together in a mono-main and stage monitor conguration using a single,

dual channel amplier.

MONO MAIN SYSTEM WITH TWO MONITORS

NOTE: This conguration represents a 4 ohm load to each output channel of the amplier.

V15B and V18B System Set-ups

V15B and V18B Stereo Sub with Passive Satellites

This is example shows a system with a single power ampliyer connecting the subs and satellites in stereo.

The mixer’s left and right outputs are connected to the inputs of the power amplier using shielded cable. The

outputs of the amplier are connected to the V15B or V18B INPUT using un-shielded speaker cable. Next, run

an un-shielded speaker cable from the V15B’s or V18B’s EXTENSION OUTPUT to the two satellite speakers.

For details on wiring your speaker cables.

IMPORTANT NOTE: To avoid any possible damage to your amp and speakers, be sure to check the

manufacturer’s owners manual to conrm your power ampliyer is capable of operating at 2 ohms.

V Series

V-10/12/15/153 FULL-RANGE SYSTEM

Impedance Considerations

When connecting speakers in parallel be sure to check the rated load impedance of the power amplier. Most

power ampliers are capable of safely driving speakerswith minimum impedance of 8 ohms or 4 ohms. A pair

of parallel-connected 8-ohm speakers have a to talimpedance of 4 ohms. Two 8-ohm speakers can safely be

paralleled on one output. 4-ohm speakers, however,should not be parallel-connected with other speakers.These

models can be connected in parallel, however, if you are using a power amplifier that can safely drive load

impedances of 2 ohms or lower. Check your speaker impedance .

V10/12/15/153&V15B and V18B EXTENDED FULL SYSTEM

WITH EXTERNAL ACTIVE CROSSOVER

OPERATING MANUAL AND USER GUIDE

SPECIFICATIONS

Model name

System Type

Frequency Response (+/- 10dB)

Sensitivity (dB) 1w@1m

Nominal Dispersion (H X V°)

Peak SPL (dB) 1w@1m

System impedance( Ω)

Power Handling

Continuous/ Music/ Peak(watts)

LF DRIVER

LF driver size (mm/inch)

Coil size (mm/inch)

Frame material

MID DRIVER size (mm/inch)

HF DRIVER

Coil size (mm/inch)

Exit size (mm/inch)

Diaphragm material

HF Horn

Shape/ material

Throat size (mm/inch)

CROSSOVER SECTION

protect type

Product Dimensions

Height

Front

Back

Depth

Ship Dimensions

Height

Front

Back

Depth

Finish

Enclosure material/ thickness

Handles

Stand mount (bottom/top)

Rubber Feet

Connectors input/ Hi Pass

Net weight (Kg/Lbs)

Gross weight (Kg/Lbs)

V10

Reex Trapezoid 10"

2-way

65 - 20kHz

90 x 60

121

100/ 200/ 400

254/10

38.1/ 1.5

Steel

25.4/1

30/1.2

Phenolic

Eliptical/ plastic

30/1.2

3kHz

PTC

479mm/18.86"

326.7mm/12.86"

177.3mm/6.98"

279mm/10.98"

527mm/20.75"

353mm/13.90"

193mm/7.60"

302mm/11.89"

Black carpet

particle/ 12mm

Yes/--

2 x 1/4"Jack

9.9/21.8

10.8/23.8

V12

Reex Trapezoid 12"

2-way

55 – 20kHz

90 x 60

124

140/ 280/ 560

305/12

38.1/ 1.5

Steel

25.4/1

30/1.2

Phenolic

Eliptical/ plastic

30/1.2

2.8kHz

PTC

525mm/20.63"

370.7mm/14.59"

207.3mm/8.16"

318mm/12.52"

574mm/22.60"

404mm/15.90"

228mm/8.98"

340mm/13.39"

Black carpet

particle/ 12mm

Yes/--

2 x 1/4” Jack

12.0/26.4

13.5/29.7

V12M

Reex 12"

2-way monitor

55 – 20kHz

90 x 60

124

140/ 280/ 560

305/12

38.1/ 1.5

Steel

25.4/1

30/1.2

Phenolic

Eliptical/ plastic

30/1.2

2.8kHz

PTC

380mm/14.96"

525mm/20.67"

361.9mm/14.25"

394mm/15.51"

555mm/21.85"

375mm/14.76"

Black carpet

particle/ 12mm

No/No

2 x 1/4" Jack

11.1/24.42

12.2/26.9

V15

Reex Trapezoid 15"

2-way

45 - 20kHz

90 x 60

126

180/ 360/ 720

381/15

50.8/2.0

Steel

25.4/1

30/1.2

Phenolic

Eliptical/ plastic

30/1.2

2.8kHz

PTC

618mm/24.33"

455.6mm/17.94"

273.5mm/10.77"

340mm/13.39"

667mm/26.26"

482mm/18.98"

289mm/11.38"

364mm/14.33"

Black carpet

particle/ 12mm

Yes/--

2 x 1/4" Jack

16.6/36.52

18.2/40.1

This manual suits for next models

Table of contents

Other Wharfedale Pro Speakers System manuals

Wharfedale Pro

Wharfedale Pro Opus 1 User manual

Wharfedale Pro

Wharfedale Pro FOCUS-12M User manual

Wharfedale Pro

Wharfedale Pro WLA Series User manual

Wharfedale Pro

Wharfedale Pro Achromatic series User manual

Wharfedale Pro

Wharfedale Pro LA-15 User manual

Wharfedale Pro

Wharfedale Pro Programme 105 Guide

Wharfedale Pro

Wharfedale Pro Vista 100 User manual

Wharfedale Pro

Wharfedale Pro Opus2 User manual

Wharfedale Pro

Wharfedale Pro Achromatic WA-T4 User manual

Wharfedale Pro

Wharfedale Pro ISOLINE-AX User manual

Wharfedale Pro

Wharfedale Pro RS-10 User manual

Wharfedale Pro

Wharfedale Pro KH series Operator's manual

Wharfedale Pro

Wharfedale Pro VECTOR-12 Guide

Wharfedale Pro

Wharfedale Pro Achromatic series User manual

Wharfedale Pro

Wharfedale Pro Link-800 User manual

Wharfedale Pro

Wharfedale Pro Achromatic WA-T8 User manual

Wharfedale Pro

Wharfedale Pro D9.0 User manual

Wharfedale Pro

Wharfedale Pro EVP-12P User manual

Wharfedale Pro

Wharfedale Pro LX Seroes User manual

Wharfedale Pro

Wharfedale Pro Atlantic AT-100 User manual

Wharfedale Pro

Wharfedale Pro Titan 12 ACTIVE User manual

Wharfedale Pro

Wharfedale Pro WLA-25 Guide

Wharfedale Pro

Wharfedale Pro WLA Series User manual

Wharfedale Pro

Wharfedale Pro Kinetic 8 Guide

Popular Speakers System manuals by other brands

JVC

JVC CA-MXK5R instructions

LG NB4532B owner's manual

JVC

JVC CA-FSH100 instructions

5Core

5Core Pro Series Operation manual

EAW

EAW MQV1394e Specifications

Lynx

Lynx GXR-LA10A user manual

iLive

iLive ITB066B user guide

RDX

RDX QuickStation 4 product manual

Electro-Voice

Electro-Voice S-122 Specifications

Sven

Sven SPS-619 GOLD Operation manual

Pioneer

Pioneer CS-7070 instruction manual

EAW

EAW UB82e Technical specifications

Sondpex

Sondpex Active Speaker System and Digital Music... User manual and installation instructions

JVC

JVC NX-PN7 instructions

Marshall Amplification

Marshall Amplification AR-DM61-BT user manual

Yamaha

Yamaha NX-A01 - Speaker Sys Product bulletin

SE Audiotechnik

SE Audiotechnik I-LINE manual

Gemini

Gemini WRX-843 Series user manual
