Western CP600 User manual
CP600 Pivot
Operation Manual
POM-EN-December 2018
2
This Page Intentionally Left Blank
3
CP600 Pivot Operation Manual
POM-EN-December 2018
Section 1
Operation, Safety & Maintenance
Safety Symbols, Pictures and Denitions ................................. 3
Final Checks and Initial Operation ....................................... 5
Machine Alignment .................................................. 6
Cam and Safety Switch ............................................... 9
Maintenance Check List .............................................. 10
Power Drivetrain Maintenance ......................................... 12
Lockout/Tagout Procedures ............................................ 19
Tire Care .......................................................... 23
Winterizing ......................................................... 24
Lube & Oil Charts ................................................... 25
Service Log ........................................................ 27
Troubleshooting ..................................................... 30
Section 2
General Information
Span Tower Weights and Dimensions .................................... 2
Revolution Times and Water Application ................................. 4
Revolution Times and Water Application Charts ........................... 6
Sprinklers ......................................................... 7
End Guns- Nelson ................................................... 36
Standard Galvanized Drop Details ...................................... 37
Standard Flexible Hose Drop Detail ..................................... 38
Variable Spacing Drop Details .......................................... 39
Slurry Drops ........................................................ 40
Standard Galvanized Extended Drop Detail ............................... 41
Adjustable Drop ..................................................... 42
Section 3
Getting Started
Before Your Machine Arrives ........................................... 2
Slope Considerations ................................................ 3
Power Supply ...................................................... 6
Ground Rod Placement ............................................... 8
Pivot Pad (Concrete) ................................................. 10
Standard Pivot Pad (Concrete) ......................................... 11
6-5/8 Pivot Pad (Concrete) ............................................ 12
High Prole Pivot Pad (Concrete) ....................................... 13
Towable Pivot Pad (Concrete) .......................................... 14
Minimum Equipment for Machine Assembly/Set-up ......................... 15
Page iiiContents
4
POM-EN-December 2018
CP600 Pivot Operation Manual
Page iv Contents
Section 4
Panel Operation
Panel Identication .................................................. 2
Forward Operation ................................................... 4
Reverse Operation .................................................. 6
Auto Reverse / Auto Off Option ......................................... 8
Auto Restart Option .................................................. 10
Local/iControlremote ................................................. 11
Safety Override ..................................................... 12
Disconnect Switch ................................................... 13
Section 5
Electrical
A Word About Proper Grounding ........................................ 2
Standard Panel Span Cable Connections ................................. 3
Panel Wiring 90239-41_R4 ............................................ 4
Main Panel Parts List ................................................. 6
Standard Panel Schematic ............................................ 8
CP JB Intermediate Cam 10142-01 ...................................... 10
End Tower Junction Box w/out Auto Reverse and Booster 90017-01 ............ 12
Stall Timer Wiring 90016-01 ........................................... 13
Collector Ring Wiring ................................................. 14
Warning ........................................................... 15
Notes ............................................................. 16
5
POM-EN-December 2018
CP600 Pivot Operation Manual
Section 1
Operation, Safety & Maintenance
6
This Page Intentionally Left Blank
CP600 Pivot Operation Manual
POM-EN-December 2018
7
Throughout the manual you will nd pictures or symbols that are inserted for your safety. Most of
these pictures and symbols are universal and are known to the reader. It is always a good idea
to review these pictures and symbols to understand the context of how they are presented in the
manual.
WARNING: COULD CAUSE SERIOUS INJURY OR POSSIBLE DEATH.
WARNING: KEEP HANDS AND OBJECTS AWAY FROM MECHANICALLY MOVING
PARTS. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR POSSIBLE
DEATH.
WARNING; HIGH VOLTAGE POTENTIAL FOR ELECTROCUTION.
WARNING: STAY CLEAR OF HEAVY MATERIAL BEING LIFTED ABOVE.
WARNING: MACHINE MAY INTERMITTENTLY START OR STOP.
WARNING: BE AWARE OF SURROUNDING POWER LINES WHEN INSTALLING
OR TROUBLESHOOTING EQUIPMENT. FAILURE TO DO SO COULD CAUSE SE-
RIOUS INJURY OR POSSIBLE DEATH.
WARNING: DO NOT CLIMB ON OR JUMP OFF MACHINE.
WARNING: FOLLOW MANUFACTURES SPECIFICATIONS FOR PROPER TIRE
INFLATION AND INSPECTION. OVER INFLATION MAY CAUSE SERIOUS INJURY
OR DEATH.
Section 1-3
Operation, Safety & Maintenance
Safety Symbols, Pictures and Definitions
CP600 Pivot Operation Manual
POM-EN-December 2018
8
Winterization see manufacturers specications Section 9-24.
CAUTION: Hard hat and steel toe work boots recommended when assembling equip-
ment
CAUTION: Be aware of pinch points when assembling equipment.
CAUTION: Could cause minor injury and or damage to machinery equipment, compo-
nents, product, etc.,
Note: Manufacture’s general comment, recommendation or instruction.
Lock Out / Tag Out Manufacturer recommends locking the main power disconnect
before servicing or troubleshooting electrical components. See
CAUTION or WARNING Disconnect electrical power prior to servicing or troubleshoot-
ing components.
WARNING: DO NOT ATTEMPT TO ASSEMBLE OR TROUBLESHOOT MACHIN-
ERY IF THERE IS POTENTIAL FOR A LIGHTENING STORM. COMPONENTS ARE
HIGHLY CONDUCTIVE AND SERIOUS INJURY OR POSSIBLE DEATH MAY OC-
CUR IF STRUCK BY LIGHTENING.
DANGER: DO NOT IRRIGATE NEXT TO POWER LINES. SPRAYING WATER ON
POWER LINES COULD CAUSE SERIOUS INJURY OR DEATH.
Section 1-4 Operation, Safety & Maintenance
Safety Symbols, Pictures and Definitions
CP600 Pivot Operation Manual
POM-EN-December 2018
9
The following list of checks and operation procedures should be followed during the initial star
up of the circle. These same basic procedures can also be followed at the initial start up of each
irrigation season.
1. Bolts: Check to insure that all bolts have been properly installed and tightened.
2. Grounding: Be sure the machine is properly grounded. Refer to the Getting Started and Electri-
cal sections for proper main panel grounding.
3. Control Limit Switches: The limit switches in the tower junction boxes have been pre-set at the
factory, however, they should be checked according to the procedures out lined in maintenance
section, Control Switch Adjustment.
4. Control rods: Check that all control rods are connected to the cam arm.
5. Alignment: The machine should be in a straight line when erection is completed. Adjust the
control rod so the tower safety limit switch roller is in the middle of the “V” of the cam. Tighten the
adjusting nuts. After the machine is started, nal alignment should be performed according to the
procedure in maintenance section, alignment.
6. Voltage: Voltage at the pivot panel should be 480V on all three legs of the power lines.
Note: Voltage is dependant upon your location. Voltage should not be more than 5% higher or low-
er than the recommended voltage or damage may occur.
7. Lubrication: Check the oil level in all gearboxes and motors. Grease the two ttings on
the pivot elbow until grease is visible at the top and bottom of bearing.
8. Starting: When all the above checks have been made, the machine is ready to start.
Close the main panel inner door and turn the main disconnect switch on. Follow operation instruc-
tions outlined in Section 4 Panel Operation.
WARNING MAKE SURE POWER IS DISCONNECTED AT THE MAIN SERVICE
PANEL BEFORE PERFORMING ANY ELECTRICAL SERVICE TO THE
MACHINE OR BEFORE OPENING THE INNER DOOR OF THE MASTER CON
TROL PANEL.
Section 1-5
Operation, Safety & Maintenance
Final Checks and Initial Operation
CP600 Pivot Operation Manual
POM-EN-December 2018
10
Your Western Center Pivot irrigation system should be run with a slight leading bow (center tow-
ers ahead of pivot and end tower) in both directions. A correctly aligned machine will have an
equal bow when operated in either direction. DO NOT let the machine run with a large leading
bow in one direction and a lagging bow in the other. To align the machine, follow these steps:
Start at the pivot end of the machine with the machine running in the forward direction and the
percent timer set to 75 percent. Stand between tower 2 and tower 3 and sight across motors No. 2
and 1 to the pivot stand pipe. Tower 1 should start when motor 1 appears to be slightly behind and
shut o when it appears to be an equal distance ahead of the center of the standpipe.
When tower 1 is properly aligned, stand between towers 3 and 4 and sight across motors 3 and 2
to the pivot standpipe. Align tower 2 in the same manner as tower 1. As you get to the outer end
of the machine and can no longer see the pivot standpipe, pick a motor on one of the inner towers
and sight to it.
Section 1-6 Operation, Safety & Maintenance
Machine Alignment
