WEIGL ProCommander LX 2 User manual
Version 1.09
Info
RealTimeClk
Audio
Configure
Main Setup
0 - 31
Menu
Start Show?
Volume
ProCom - LX
MENU ProCommander Series – LEVEL 1 & 2
LEVEL 1 LEVEL 2
All channels will store the same value
Up = Back to the start
Left & Right = Volume/ Navigation
Enter = Press the button to select the displayed function or store value
00000
000.000.000.000
Set Factory?
Port 1 – 4 Value
IP-Adrs
Set Factory
Set Port
Set IP-Adrs
MainSetup
Menu
MENU ProCommander LX 2 – MainSetup – LEVEL 2
LEVEL 3 LEVEL 4 LEVEL 5
Left = Back/ one level up
Enter = Press the button to select the displayed function or store value
None
NanotcSCI47
Dynamixel
IAI
ON
OFF
0 - 250
0 - 250
Set RS485-2 Drv
Set StArt PlayL
Set Ease-In
Set TimeOut
RS485-2 Driver
Start Playlist
EaseIn Time
LTC-TimeOut
Configure
Menu
MENU ProCommander LX 2 – Configure – LEVEL 2
LEVEL 3 LEVEL 4 LEVEL 5
Left = Back/ one level up
Enter = Press the button to select the displayed function or store value
ON
OFF
SetIgnStClr
IgnStartClr
Configure
Menu
MENU ProCommander LX 2 – Configure – LEVEL 2
LEVEL 3 LEVEL 4 LEVEL 5
Left = Back/ one level up
Enter = Press the button to select the displayed function or store value
-8 - +7
0 - 15
0 - 31
Set Volume Ch:1-8
Set Bass Ch:1-8
Set Treble Ch:1-8
Treble
Bass
Volume
Audio
Menu
MENU ProCommander LX 2 – Audio – LEVEL 2
LEVEL 3 LEVEL 4 LEVEL 5
1 - 4
Set Gain:
Amplifier Gain
Left = Back/ one level up
Enter = Press the button to select the displayed function or store value
2012 +
1 - 12
1 - 31
Monday/1-Sunday/7
0 - 59
0 - 23
Set Year
Set Month
Set Day
Set DayOfWeek
Set Minute
Set Hour
Year
Month
Day
Day-Of-Week
Minute
Hour
RealTimeClk
Menu
MENU ProCommander LX 2 – RealTimeClk – LEVEL 2
LEVEL 3 LEVEL 4 LEVEL 5
Left = Back/ one level up
Enter = Press the button to select the displayed function or store value
Firmware Version
Serial Number
MAC-Address
IP-Address
Port 1
Port
IP-Address
MAC-Address
SerialNumber
Firmware Ver.
Info
Menu
MENU ProCommander LX 2 – Info – LEVEL 2
LEVEL 3 LEVEL 4
000.000.000.000
00-00-00-00-00-00
00.00.00.00
V0.00
LEVEL 5
Left = Back/ one level up
Enter = Press the button to select the displayed function or store value
