walraven BIS Yeti 130 User manual
walraven.com
BIS Yeti®130 Frame Set 1000x600x400mm
Part no. 67685532
EN Assembly instruction
DE Montageanleitung
NL Montage-instructie
FR Instructions de montage
ES Instrucciones de montaje
PT Instrução de montagem
PL Instrukcja montażu
CZ Montážní návod
SK Montážny návod
RO Instrucţiuni de montaj
RU Инструкция по монтажу
UA Інструкція з монтажу
DK Monteringsvejledning
SE Monteringsanvisninga
NO Montasjeanvisning
IT Istruzioni di montaggio
+44 (0)1295 75 34 28
UK
+49 (0)921 75 60 0
DE
+31 (0)297 23 30 00
NL
+32 (0)16 82 20 40
BE
+420 326 724 009
CZ /SK
+48 12 684 00 95
PL
+33
(
0
)
4 76 04 10 70
FR
+34 93 721 33 75
ES
+7 (495) 664 35 08
RU
+1 800 610 5056
US
+380 44 351 27 47
UA
(+36 1) 920 2458
HU
+45 46 37 05 10
DK
CN
+46 (0)40 36 54 20
SE
+45 46 37 05 10
NO
+86 21 5176 0268
SG +65 9146 8260
Other countries
+31 (0)297 23 30 00
walraven.com
BIS Yeti®130 Frame Set installation appliance - Assembly Instruction - 06/2020 - pdf - Full content subject to modifications
1
1
1
1
2
2
2
2
3
3
4
4
5
5
5
5
6
6
6
6
7
7
7
7
8
8
8
8
8
8
8
8
8
8
8
8
8
88
8
8
888
9
9
9
9
9
9
9
9
9
9
9
9
10
10
10
10
1010
10 10
5
5
5
5
11
11
11
11
400mm
180 - 425mm
Fmax=1500N
Pos. Part No. #
1 67685130 BIS Yeti®130 Support System 4
2 65018627 BIS RapidStrut®Fixing Rail (BUP1000) 41x21x2.5mm l=400mm 4
3 65018627 BIS RapidStrut®Fixing Rail (BUP1000) 41x21x2.5mm l=600mm 2
4 65018627 BIS RapidStrut®Fixing Rail (BUP1000) 41x21x2.5mm l=1000mm 2
5 6566021 BIS Strut Rail End Cap 41x21mm 8
6 665885203 BIS RapidStrut®Rail Connector 90° G2 (BUP1000) 4
7 66588292 BIS Strut Cross Connector (BUP1000) 4
8 65381008 BIS Washer (Flat) (BUP1000) Ø8,4x25 mm 20
9 61480825 BIS Hexagon Head Bolt (BUP1000) M8x25 mm 12
10 61281008 BIS Hexagon Nut (BUP1000) M8 8
11 651868008 BIS RapidStrut®Slide Nut with Plastic Tabs (BUP1000) M8 4
1000
600
621
850
BIS Yeti®130 Frame Set 1000x600x400mm
Part no. 67685532
