Vybra VS001-OF User manual
Dual Height Oscillating Fan Manual
SKU: VS001-OF EAN: 5060663690272
Before using your unit, please read these instructions and keep them for future reference
Vybra Solutions Ltd, 5 Kingsway, Andover, UK
1. Important Safety Information
WARNING
When using electrical appliances, basic precautions should always be followed to reduce
the risk of re, electrical shock and injury.
1. Only use this appliance for the purposes described in the instruction manual.
2. Only connect this product to main power compliant with the information on the power
plate.
3. Do not cover this product with objects to avoid overheating or re.
4. Conrm the power is compliant with the label.
5. Do not use if the power cord is not damaged in any way.
6. Do not fold or pull the power cord hard.
7. Changing the power cord must be performed by professionals.
8. Do not place this product right under a power socket.
9. Do not use this product in bathroom or near a pool.
10. Keep children away from this product while it is working.
11. Please unplug when moving this product or power supply breaks.
12. Do not insert ngers or objects into the product.
13. Do not unplug the plug with wet hands
14. Never submerge the product, power cord or plug into water.
CORRECT DISPOSAL OF THE PRODUCT
This marking indicates that this product should not be disposed of with
other household waste throughout the UK. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources.
2. Technical Information
SKU & EAN Voltage Power Frequency Control
VS001-OF - 5060663690272 220-240V 50W 50-60Hz
Remote
with
battery
3. Installation Instructions
Please follow these instructions when using this product:
1. Carefully unpack the product and all accessories.
*Keep the package materials out of reach of children.
*Carefully check for any external damage.
2. Remove the screw stem from the lower column clockwise and unscrew the screw
stem on the upper column.
3. Install the lower column into the hole in the pedestal base and fasten the screw
stem.
4. Install the upper column into the lower column, and fasten the screw stem.
5. Mount the upper column into the main part, and fasten the screw stem
6. Before connecting the product, please check that:
*The main power source is corresponds with the information on the power plate.
*The socket and power cord are suitable for this product.
*The plug of power cord ts in the socket.
*The product is placed on a stable and at surface
FRONT GRILLE
CONTROL PANEL
STAND COLUMN
BASE
4. Structural
Diagram
5. Control Panel Instructions
The unit can be controlled by either the remote or pressing the buttons on the control
panel.
ON/OFF key:
The product turns ON or OFF when pressing this button.
Speed button:
Speed increases one level by touching the speed key on the panel or
speed button on the remote accordingly - 3 speeds in one cycle.
Timer button:
Press this button when the power is ON and the timer increases by one
hour intervals until 12 hours is reached.
The unit will turn off automatically when the time set is up.
To cancel or reset the timer - press this key continuously until it displays
‘00’.
Oscillation button:
The unit’s head will turn ON horizontally when pressing the oscillation
button. It will turn OFF when pressed again.
The vertical swing turns ON when held for 3 seconds, and turns OFF by holding for 3
seconds.
- DO NOT move the fan head by hand.
Screen off Function:
The indicator lights on the screen will go out after 3 minutes without operation.
The screen will awaken when any key is pressed.
• Functions on the Remote are the same as the manual control panel on the unit.
• The control distance of the Remote is about 5 meters.
• Remove batteries when not in use for a long period of time.
Remove the insulating
layer before inserting
Install a
3V button
battery
1 x 3V CR2025 Button
Battery included
6. Cleaning and Storage
Turn OFF the product and unplug from the socket before cleaning or maintenance.
Cleaning the exterior:
• Use a clean, soft cloth with neutral solvent to clean the exterior.
• Do not use corrosive or alkaline solvent to clean this product.
• Do not clean the inside of this product (circuit board, motor, etc.) with any solvent
• Ensure no water gets into the control circuit as this will cause a short circuit.
• Do not submerge the product, power cord or plug into water in any circumstances.
• Please pack up this product carefully for storage if this product is not used for a
long period of time.
Product Features:
• 3 Speeds Control:
- Low / Medium / High
• Vertical rotation angle of 90°
• Oscillation angle of 65°
• 1 to 12 hour Timer
• Remote control with battery included
• Room Temperature display
• Digital Screen display
• Auto off Screen in 3 minutes
• Removable easy to clean Grille
• Overheat protection for the motor
• Two standing columns for adjustable height
• Suitable for rooms up to 30m2
7. Electrical Diagram
This manual suits for next models
