Volvo S80 - User manual

S80 Quick GUIDE WEB EDITION

WELCOME TO THE GLOBAL FAMILY OF VOLVO OWNERS!

This Quick Guide provides a brief overview of the most common features and functions in your Volvo.

The Owner’s Manual and the other driver’s information provided contain important warnings and other

information not included in this guide.

The following symbols indicate:

Specific call-outs in a general illustration.

Step-by-step instructions.

Important information that should be read in the Owner’s Manual.

Important information, warnings and safety-related instructions marked by these symbols

can be found on the last page of this guide.

An asterisk (*) indicates optional equipment.

For additional information, contact Customer Service:

U.S.A.: 1-800-458-1552 www.volvocars.com/us

Canada: 1-800-663-8255 www.volvocars.com/ca

Climate control

Lighting controls

Instrument panel

Infotainment system

Bluetooth hands-free

External audio devices

Buttons in the center console

Menu settings

Vehicle care

Storage compartments

AUX/USB and 12-volt sockets

Engine Remote Start* (ERS)

04 Functions in your vehicle

05 Tips

Adjusting the seats

Adjusting the steering wheel

Folding down the rear seat backrests

Moonroof*

BLIS*

Pedestrian protection*

HomeLink®*

02 Driver support systems

03 Your driving environment

Remote key

Starting and switching off the engine

Parking brake

Keyless drive*

Wipers

01 Starting and driving

How do I start the engine?

How does the remote key work?

What do the lights in the remote key

(PCC* only) indicate?

Unlocks the doors and trunk and disarms the

alarm.

Locks the doors and trunk and arms the alarm.

Approach lighting.

Unlocks/opens the trunk (press once to

unlock; press twice to open the trunk slightly).

Information about the vehicle (Personal Car

Communicator (PCC*) only).

“Panic” alarm: Press and hold to sound the

alarm. Turn off the alarm with the unlock but-

ton.

The remote key can store the positions of

the power seat* and door mirrors.

Holding the end of the remote key with the

base of the key blade, insert the remote key

into the ignition slot and press it in as far as

possible.

Press the brake pedal.

Press the START/STOP ENGINE button

briefly and release it to start the engine.

Green light: the vehicle is locked.

Yellow light: the vehicle is unlocked.

Red light: the alarm has been triggered.

Alternatively flashing red lights: the alarm was

triggered less than 5 minutes ago.

See the additional information on the last

page of this guide.

How do I switch off the engine?

Park the vehicle and briefly press the

START/STOP ENGINE button to switch off

the engine.

Pull the remote key out of the ignition slot.

How does keyless drive* work?

A keyless drive remote key must be in your pos-

session.

Locking and arming the alarm (see the illustra-

tion)

–Press the pressure-sensitive area on any of the

outside door handles or the rubber-covered but-

ton next to the trunk opening control.

Unlocking and disarming the alarm

–Pull a door handle to unlock and open the door

or press the trunk opening control on the trunk

lid.

How do I set/release the parking brake? 01

Setting

Press firmly on the brake pedal.

Press the PUSH LOCK/PULL RELEASE

control: the symbol in the instrument panel

flashes while the parking brake is being ap-

plied and glows steadily when it has been fully

applied.

Release the brake pedal.

Releasing

Press firmly on the brake pedal.

Pull the PUSH LOCK/PULL RELEASE con-

trol.

See the additional information on the last

page of this guide.

How do I start the windshield wipers

and rain sensor*?

Press the lever down to start the windshield wipers

or up for the single-sweep function.

Rain sensor On/Off.

Turn to adjust the rain sensor sensitivity or

interval wiper speed.

What does BLIS* do?

Blind Spot Information System (BLIS) indicates

the presence of a passing vehicle in the door mir-

ror’s blind area.

– BLIS is activated when the engine is started and

can be deactivated/reactivated by pressing the

button.

How does HomeLink®* work?

The HomeLink Wireless Control System has to be

programmed with your garage door opener or oth-

er device before it can be used. See your Owner’s

Manual or www.homelink.com for instructions.

To use HomeLink:

– Press and hold the programmed HomeLink but-

ton until the device begins to operate (this may

take several seconds).

The device’s hand-held transmitter may also be

used at any time.

See the warning on the last page of this

guide.

Understanding this feature is essential, see

your Owner’s Manual for more information.

See also the warning on the last page of this

guide.

The optional system Collision Warning with Full

Auto-brake and Pedestrian Detection has a feature

that helps detect pedestrians and applies the

brakes to help slow or stop the vehicle.

This feature is designed to be a supplementary

driving aid and cannot detect pedestrians in all

situations. It is not intended to replace the driver’s

attention and judgement.

How do I adjust the seat?

Raise/lower the front edge of the seat cush-

ion.

Raise/lower the seat.

Move the seat forward/rearward.

Tilt the backrest.

Memory button (M).

Buttons for storing seat positions.

Programming the power seat’s* memory

Adjust the seat to the desired position.

Press and hold down the M (memory) button

(5).

With the M button depressed, briefly press

one of the buttons (6) to store the current

seat position.

How does Pedestrian Detection* work? 02

See the warning on the last page of this

guide.

Automatic complete open.

Manual open.

Manual close.

Automatic complete close.

Open to the ventilation position.

Close from the ventilation position.

How does the moonroof* work? 03

How do I fold down the rear seat back-

rests?

See your Owner’s Manual for information

about folding down the outboard head

restraints. See also the warning on the last

page of this guide.

How do I adjust the steering wheel?

Release the steering wheel.

Adjust up/down/fore/aft.

Lock the steering wheel in position.

Both sections of the split rear seat backrest can

be folded down: together or separately.

Pull the desired handle at the upper edge of

the trunk opening.

Fold the backrest down. Lower the center

head restraint if that section of the backrest is

to be folded down.

See the warning on the last page of this

guide.

See the warning on the last page of this

guide.

How does the AUTO headlight feature

work?

With the switch in the AUTO position:

• The headlights will switch automatically

between daytime running lights and low beam

headlights, depending on ambient lighting

conditions.

• High beams can be used.

• Active Bending lights* (ABL) switch between

high and low beams automatically if another

vehicle approaches or is directly ahead. Tunnel

detection* is also active.

How do I defrost the windshield? 04

How do I set the temperature? 04

Turn the controls to set the temperatures on

the driver and passenger sides respectively.

The selected temperature is shown in the

display.

Press AUTO to automatically regulate cooling,

heating, blower speed, recirculation, and air

distribution to maintain the chosen tempera-

ture. AUTO CLIMATE is displayed.

Press to activate electrical heating*; the sym-

bol (1) illuminates in the display.

Press again to also direct airflow toward the

windshield and front side windows; symbols

(1) and (2) will illuminate.

Press again to switch off both functions; no

symbols will be illuminated.

Models without electrical defrosting: Press to

direct airflow toward the windshield and front side

windows.

How do I operate the trip computer?

OK opens the trip computer menus, activates

a selection or erases displayed messages.

Use the thumb wheel to scroll among the

menu selections.

RESET resets the trip computer functions and

exits the menus.

How do I reset the trip computers?

When using the Geartronic manual shifting mode, a

white arrow will appear above or below the number

of the current gear to prompt the driver to shift up

or down (digital instrument panel* shown).

How does the gear shift indicator*

work? 04

Press the RESET button on the left steering

wheel lever twice briefly.

Scroll to the desired trip odometer (T1 or T2)

with the thumb wheel.

Press and hold RESET to reset.

See your Owner’s Manual for information

about the analog instrument panel.

How do I switch the infotainment sys-

tem on and off?

Press the power button briefly to switch the

system on.

Press and hold the button (until the screen

turns black) to switch off.

With the system on, press the button briefly to

mute/unmute the sound.

What does the trip computer’s “Distance

to empty” indicate? 04

This is the approximate distance that can be

driven on the remaining fuel based on average fuel

consumption during the last 20 miles (30 km) of

driving (digital* instrument panel shown).

When “...distance to empty” is displayed (analog

instrument panel), or “---” (digital* instrument

panel), refuel as soon as possible.

How do I change the digital instrument

panel’s display alternative (theme)*?

The digital instrument panel has three different

display alternatives (themes): Elegance/Eco/Per-

formance. To switch themes:

With the engine running and the vehicle safely

parked, press OK on the left steering wheel

lever.

Use the thumb wheel to scroll to Themes.

In the Themes menu, scroll to the desired

theme and press OK to select and confirm

your choice.

See your Owner’s Manual for information

about the analog instrument panel.
