Volvo S80 - User manual

WELCOME TO YOUR NEW VOLVO!

Getting to know your car is an exciting experience.

After looking through this Quick Guide you'll like your new Volvo even more.

You can find detailed information in the Owner's Manual.

Warning texts and other important information are only available in the

Owner's Manual, not in this folder. The Owner's Manual contains the most

up-to-date information.

Options are marked with an asterisk (*).

VOLVO S80

Quick Guide

Locks doors and boot lid and arms the

alarm1.

Unlocks doors and boot lid and dis-

arms the alarm1.

Unlocks boot lid.

Lighting is switched on. Door mirror

lighting, interior lighting, step light-

ing, number plate lighting, direction

indicators (on) and parking lamps are

activated.

"Panic" button. Press and hold for

approx. 3 seconds in an emergency to

trigger the alarm.

KEY & REMOTE CONTROL

START

SWITCH OFFTHE ENGINE AND REMOVE THE REMOTE CONTROL

Insert the remote control into the ignition

switch.

Press gently on the remote control. The

remote control is then pulled into the correct

position.

Depress the clutch or brake pedal. Press the START/STOP button to start the

engine2.

2The idling speed may be slightly higher for a short time during cold starting.

Park the car and press the START/STOP

button to switch off the engine.

Press on the remote control. The remote

control is then ejected. The automatic trans-

mission must be in P position.

1Automatic relocking takes place if a door/boot lid is not opened within 2 minutes after unlocking.

PERSONAL CAR COMMUNICATOR, PCC* WITH KEYLESS DRIVE

Green light: The car is locked.

Yellow light: The car is unlocked.

Flashing alternating red light: Someone

may be inside the car.

Red light: The alarm has been armed.

Information is retrieved from the car

when it is within range. Press the button

and wait for 5 seconds. If the button is

pressed when the car is out of range then

the PCC shows whether the car is locked

or unlocked using the memory function.

STARTING WITH KEYLESS DRIVE

Get into the car with the PCC in your pocket for

example. Depress the clutch or brake pedal.

Press the START/STOP button to start the

engine1.

1The idling speed may be slightly higher for a short time during cold starting.

SWITCHING OFF THE ENGINE

Park the car and press the START/STOP button

to switch off the engine.

IMPORTANT

With keyless drive the PCC only needs to

be inside the car. Keep it in your pocket for

example when you go to and from the car

and while driving.

The car is unlocked automatically when the

door is opened.

When parking the car after driving you only

need to press the button on the outside of

the door to lock the car.

LEATHER CARE BLIS – BLIND SPOT INFORMATION

SYSTEM*

Regular cleaning is required to preserve the

properties and appearance of the leather.

Treat the leather upholstery with Volvo's

leather care kit, once to four times per year.

The leather care kit is available at your Volvo

dealer.

If the BLIS’ indicator lamp illuminates despite

there being no vehicle within the blind spot,

the cause could be for example, reflection

from shiny wet road surface or low sun in the

camera. In the event of a direct fault in the

system the display shows the text Blind spot

syst. Service required

157

AUDIO SYSTEM

Set the sound pattern

Press the button to select BASS, TREBLE,

FADER, BALANCE, Dolby Pro Logic II*.

Turn the control to adjust.

1AUX input for e.g. MP3 player (set volume at medium

for optimum audio reproduction).

POWER/VOLUME

Press for ON/OFF

Turn to adjust the volume

Radio, TP, Handsfree* and RTI volume are

stored individually for the next time they

are used.

Select AM, FM1, FM2, CD or MODE.

Use MODE to activate AUX1and to adjust

the AUX audio source volume.

Change CD track using Left/Right arrow

or turn (3).

Select CD disc* using Up/Down arrow.

CD eject

Press to eject current CD disc.

Keep the button depressed to eject all

CD discs in the CD changer*.

CD changer*. Select CD disc 1–6.

RADIO

Turn to select radio station

Search station with left/right arrow. Store

up to 20 stations by holding in 0–9 on

FM1 and 0–9 on FM2. When a station has

been stored it is confirmed in the display.

Autostore the 10 strongest stations

Press in AUTO for approx. 2 seconds.

Autostoring is shown in the display for as

long as the search continues.

Select from 0–9 to playback one of the

stored radio stations.

LOWERING THE REAR SEAT BACKRESTS

Pull the handles separately to lower the left

and/or right-hand backrest.

Make sure that the rear head restraints are

raised. Lower the backrests.

ELECTRONIC CLIMATE CONTROL, ECC

MANUAL CONTROL

Fan speed

Air distribution

Defroster to quickly remove misting

from the windscreen and side windows.

Air quality system. OFF/AUT/Recircu-

lation.

Air conditioning ON/OFF

AUTOMATIC CONTROL

In AUTO mode the ECC system controls all

functions automatically making driving simpler

with optimum air quality.

Temperature

Turn the controls to select the required

temperature. The set temperature is shown

in the display.

Press AUTO for automatic control of tem-

perature and other functions.

STORAGE SPACES, 12 V SOCKET AND AUX

IMPORTANT

Using the 12 V socket in the cargo area could

discharge the battery.

The 12 V sockets in the centre console front/

rear work in ignition position I or higher. The

12 V socket on the right-hand side of the cargo

area is always active.

123456

12.3 12:34

P_3 C

1000km

to empty tank

3 62 41 5

8 9

Trip meter

The car is equipped with two independent

trip meters, T1 and T2, which are always

on.

Press (6) for 2 seconds to reset the trip

meter shown in the display.

Press (6) quickly to shift between

T1 and T2.

Fuel gauge

The arrow shows which side the fuel filler

cap is on.

Low fuel level

The symbol illuminates when 8 litres of fuel

remain in the tank (diesel cars: 7 litres).

Km to empty tank

Set the trip computer thumbwheel (8) to

display the calculated range to empty tank.

IMPORTANT

Km to empty tank displays a calculated

potential range to empty tank. The calcula-

tion is based on earlier driving style, hills,

type of traffic etc.

TRIP COMPUTER AND TRIP METERS

Clock

Turn the control (6) clockwise or anticlock-

wise to set the clock.

Multifunction control

Press to reset or switch between trip

meters T1 and T2.

Turn to adjust the clock.

READ

Press to read messages in the display.

Press again to acknowledge a message.

Trip computer

Set the required function by scrolling with

the thumbwheel.

Resets all functions

ADJUSTING THE STEERING WHEEL REFUELLING

WARNING! Adjust the steering wheel before

setting off, never while driving.

Press the button to open the fuel filler flap.

A B

HEADLAMP CONTROL

Display and instrument panel lighting

Fog lamps, front

Rear fog lamp

Automatic dipped beam. Main beam

flash works but not fixed main beam.

Parking lamps

Dipped beam. Dipped beam switches

off when the ignition is switched off.

Main beam can be activated with the

lever.

Headlamp levelling, dipped beam.

Automatic function for Bi-Xenon lights*.

Main beam flash.

Switch between main/dipped beam.

The symbol indicates that the rain sensor

is ON.

Single sweep, windscreen wipers

Interval wiping. Turn the thumb-

wheel (B) to adjust the wiper interval.

Normal speed

High speed

Windscreen and headlamp washing

RAIN SENSOR* AND WINDSCREEN WIPERS

RAIN SENSOR

Press to activate the rain sensor when the

lever is in position 0.

Adjust rain sensor sensitivity by turning

the thumbwheel.

CONTROL PANEL IN DRIVER'S DOOR

Locking/unlocking of all doors.

Retracting the door mirrors* takes

place by means of Land Rsimulta-

neously.

L R

Door mirror controls



Manual windows



Automatic windows

Locking the rear windows and

doors* (Child safety locks)

5 4 4352

ELECTRIC PARKING BRAKE, PPB (V8, AWD & RHD)

To apply



Press the button.

The lamp flashes until the parking

brake is fully applied, after which the

lamp illuminates.

Engage a gear and drive away. The parking

brake disengages automatically.

IGNITION POSITIONS (MODE 0, I) ADJUSTINGTHE FRONT SEAT

Lumber support

Backrest rake

Raise/lower seat

Seat cushion front edge raise/lower

Forwards/backwards

0Instrument/clock lighting, steering lock

unlocks.

IPower sunroof, power window lifts, fan,

ECC, windscreen wipers, 12 V sockets in

centre console, RTI.

The clutch/brake pedal must not be

depressed.

REMOTE CONTROL

Mode 0

Mode I

PCC & KEYLESS DRIVE

Mode I

Audio system/interior lighting works inde-

pendently of ignition position.

To disengage

Ignition position 0or higher.

Depress the clutch or brake pedal.



Pull out the button.

Disengage automatically

Engage a gear and drive away.

(In cars with automatic transmission the driver

must be wearing the seatbelt.)
