ENGINE

Five-cylinder turbocharged petrol engine with charge-air cooler

(Intercooler). Double overhead camshafts, 20 valves. Three-way catalytic

converter with Lambda sensor. Electronic engine management.

DRIVELINE

Front-wheel drive. Transverse engine. Five-speed manual all-synchromesh

gearbox. As an alternative, there is a five-speed, electronically controlled

automatic transmission with adaptive shifting pattern, winter mode and lock-

up function which reduces fuel consumption when cruising.

ELECTRICAL SYSTEM

Battery capacity 12 V, 600 A. Alternator 120 A.

STEERING GEAR

Power-assisted rack and pinion steering gear. Steplessly adjustable steering

wheel, vertically and horizontally. Three turns between end stops. Turning

circle 11.7 m.

BRAKES

Power-assisted anti-lock disc brakes (ABS), ventilated discs at front.

Electronic brake distribution between front and rear brakes (EBD). Diagonal-

split braking system.

CHASSIS

Front suspension with spring struts. Anti-dive and anti-lift function. Delta-

link semi-independent rear suspension. Anti-roll bars front and rear.

Options: Volvo’s anti-spin system (STC). Lowered chassis (Low Dynamic).

Automatic levelling.

LOAD CAPACITY

Luggage compartment: 262 litres

Max. load: 455 kg

Max trailer weight: 1600 kg

WEIGHT

Kerb weight: 1565 kg

http://vcc.volvocars.se/pp/newc70c/default.asp (1 of 3)24/09/2003 21:01:54

http://vcc.volvocars.se/pp/newc70c/default.asp

Max total weight: 2020 kg

FUEL TANK

68 litres

VOLVO C70 2.0T CONVERTIBLE (163 BHP)

●Engine type: Five-cylinder petrol light-pressure turbo engine

●Displacement: 1984 cc

●Power output: 120 kW (163 bhp) at 5100 rpm

●Torque: 230 Nm at 1800-5000 rpm

●Acceleration 0-100 km/h, man/aut: 9.9/10.7 sec

●Top speed, man/aut: 210/200 km/h

●Fuel consumption litres/100 km, mixed driving, man/aut*: 9.7/10.6

●CO2 emission, g/km, man/auto*: 230/253

●Environmental classification: Specific for each country

●Transmission: Five-speed manual gearbox or five-speed adaptive

automatic

* May vary depending on the car’s equipment level.

VOLVO C70 2.4T CONVERTIBLE (200 BHP)

●Engine type: Five-cylinder petrol light-pressure turbo engine

●Displacement: 2435 cc

●Power output: 147 kW (200 bhp) at 5700 rpm

●Torque: 285 Nm at 1800-5000 rpm

●Acceleration 0-100 km/h, man/aut: 8.5/9.0 sec

●Top speed, man/aut: 220/210 km/h

●Fuel consumption litres/100 km, mixed driving, man/aut*: 9.9/10.9

●CO2 emission, g/km, amn/auto*: 236/261

●Environmental classification: Specific for each country

●Transmission: Five-speed manual gearbox or five-speed adaptive

automatic

* May vary depending on the car’s equipment level.

VOLVO C70 T5 CONVERTIBLE (245 BHP)

●Engine type: Five-cylinder petrol high-pressure turbo engine

●Displacement: 2319 cc

●Power output: 180 kW (245 bhp) at 5400 rpm

●Torque: 330 Nm at 2400-5100 rpm

●Acceleration 0-100 km/h, man/aut: 7.5/8.0 sec

●Top speed, man/aut: 240/230 km/h

●Fuel consumption litres/100 km, mixed driving, man/aut*: 9.9/10.9

●CO2 emission, g/km, amn/auto*: 236/261

●Environmental classification: Specific for each country

http://vcc.volvocars.se/pp/newc70c/default.asp (2 of 3)24/09/2003 21:01:54

http://vcc.volvocars.se/pp/newc70c/default.asp

●Transmission: Five-speed manual gearbox or five-speed adaptive

automatic

* May vary depending on the car’s equipment level.

Warranty: 12-month international warranty without mileage limitation.

N.B. Some of this information may be incorrect due to product

changes which may have occurred since it was published. Some

of the equipment described or shown may now be available only

at extra cost. Before ordering, please ask your Volvo dealer for

the latest information. The manufacturer reserves the right to

make changes at any time, without notice, to prices, colour,

materials, specifications and models.
