VOLTCRAFT CPS-1000 User manual

VOLTCRAFT® - TOP PERFORMANCE IN EVERY WAY

“For more than 25 years, our product range has been dynamically adapting to the constant changes in the industry.

We commit to offering first-class quality to our customers while delivering an excellent cost-performance ratio. This

philosophy remains the cornerstone of Voltcraft’s success.”

CPS-1000

MINI AUTOMOBILE

SWITCHING POWER SUPPLY

VERSION 08/10

Nº 51 83 86

With this product USB devices can be easily operated and charged via a car socket. Due to its small size it can be used in

almost every car socket. It is even possible to close a car socket cover, while the power supply is inserted. The product is

suitable for every USB device with a matching plug.

HIGHLIGHTS

USB-A output //

Output voltage 5 V/DC //

Max. 1000 mA //

Ultra small //

LED power indicator //

TECHNICAL DATA

Input voltage: 12 V/DC

Output voltage: 5 V/DC

Output current: max. 1000 mA

Output power: max. 5 W

Connections: Car plug ↔ USB-A female

Operating temperature: 0 to +60 ºC

Dimensions (Øx L): 28 x 45 mm

Weight: 12 g

PACKAGE CONTENT

Mini automobile switching power supply // Operating instructions

This data sheet is published by Voltcraft®, Lindenweg 15, D-92242 Hirschau / Germany, Phone +49 180 586 582 7. The data sheet reflects the current

technical specifications at time of print. We reserve the right to change the technical or physical specifications.
