2. “All in One solar street light” adopts the long life Lithium battery for storing
energy, charging temperature at day time is between: -20°C～+60°C,when
temperature goes lower than -20°C ,the control system will stop automatically
to protect the battery, and it will revive to charge the battery while
temperature goes higher than-20°C. Discharging temperature at night is
between: -20°C～+60°C, any ambient beyond will take damage to the battery.
So please check these factors while selecting the street light.
3. Battery of the “All in One solar street light” can be stored for 6 months long
after fully charged. Therefore please examine and charge it periodically after
long transportation period or storage to prevent damaging.
4. The surface of the All in One solar street light can be kept clean with normal
detergent to get maximum power generation, clear the dust or tree leaves or
any grease.
5. All in one solar street light have got the standard of IP65.The vents on the
surface is designed for radiating. The materials are made of aluminum alloy
which can survive in the environment of seaside and desert.
6. The knob of the fuse is at the left rear end of the light; please insert the fuse
when in use. In addition there is one more fuse to be used as a backup. (If the
fuse don’t work, then the switch should be turned on)
Installation Instructions:
1. Place the light pole into the best spot with good day lighting. The light pole
should be the length of 6-8m, the thickness 3.75-5.0mm with material iron
or steel, the up diameter 80 mm tapered light pole.
2. Please check to ensure all the components have been received.
3. Unfold the knob of fuse (see below) and check if the fuse works or not, then
tighten. (If not just turn on the switch)
4. Place the lamp on the pole by its sleeve, and ensure it is steady.
Page 5 of 9
