Vizio E420VT User manual

E320VT / E370VT / E420VT – QUICK START GUIDE

EDGE LIT RAZOR LED™LCD HDTV

PACKAGE CONTENTS

Cleaning ClothRemote Control with

Batteries

User Manual and

Quick Start Guide

VIZIO LCD HDTV with Base

RF Adapter

USING THE REMOTE

Power/Standby: Turn the TV on or off.

Input: Change the input device.

A/V Controls: Control USB photo slideshow.

Info: Display the Info Window.

CC: Open the Closed Captioning menu.

Menu: Display the on-screen menu.

Exit: Close the on-screen menu.

Arrow: Navigate the on-screen menu and episode guide.

OK: Select highlighted menu option.

Back: Go to the previous on-screen menu options.

V Button: Open USB player.

Volume Up/Down: Increase or decrease the loudness of the TV’s audio.

Channel Up/Down: Change the channel. With each press of the button,

the channel will increase or decrease by one.

Mute: Turn the sound off or on. When mute is activated, the

TV’s audio is turned off.

Last: Return to the channel last viewed.

Number Pad: Use the number pad to manually enter a channel.

Dash (-): Use with number pad to manually enter a digital sub-

channel. (For example, 18-4 or 18-5.)

Wide: Switch between display modes.

Power/Standby

A/V Controls

Info

Arrow

Channel

Up/Down

Last

Number Pad

Wide

Mute

Volume

Up/Down

Exit

Input

Back

V Button

Dash (-)

INSTALLING THE BASE

Place the TV screen-down on a clean, ﬂat surface. To prevent

scratches or damage to the screen, place the TV on a soft

surface, such as carpet, rug, or blanket.

Place the base against the back of the TV as shown.

Using a philips-head screwdriver, attach the base to the TV by

inserting and tightening the 4 included screws.

Move the TV with attached stand into an upright position and

place on a ﬂat, level, and stable surface.

FIRST-TIME SETUP

Connect the power cord to the back of the TV.

Plug the power cord into an electrical outlet.

Remove the battery cover by pressing gently and

pushing it away from the remote.

Insert the batteries. The +and -symbols on the batteries

must correspond to the +and -symbols inside the battery

compartment.

Replace the battery cover by gently sliding it back into place.

If you have an external antenna or a cable connection that

extends from a wall outlet, connect it to the TV with an

RF/Coaxial cable and the included RF Adapter.

Turn the TV on by pressing the Power/Standby button on the

remote or on the side of the TV.

The Setup App is displayed.

Initial Setup

Allow the VIZIO setup Wizard to

help you tune your channels.

Welcome

Next Exit

EXIT

Press the Up/Down Arrow buttons on the remote to highlight

your preferred language.

Press Right Arrow to go to the next screen.

Press the Up/Down Arrow buttons on the remote to highlight

Home.

Press Right Arrow to go to the next screen, then enter your time

zone and daylight savings information.

Initial Setup

Please select your language: English

Français

Español

Language

NextBack Select Exit

EXIT

Initial Setup

Please select your input location:

NextBack Select

Home

Retail

Mode Setting

Exit

EXIT

If the TV is connected to an external antenna, select Antenna, then press

Right Arrow and go to step 7.

If the TV is connected to a cable service without a set-top box (cable is

connected directly from the wall outlet) select Cable, then press Right Arrow

and go to step 7.

If the TV is connected to a cable or satellite set-top box, press the EXIT button

on the remote, then select the input to which your set-top box is connected

(HDMI, COMP, or AV).

Press the Up/Down Arrow buttons on the remote to highlight

Scan.

Press Right Arrow to begin the channel scan.

Wait for the channel scan to ﬁnish.

When the channel scan is complete, the ﬁrst-time setup is

complete.

Initial Setup

Please select your input source:

NextBack Select

Antenna

Cable

Tuner

Exit

EXIT

Initial Setup

Please connect your cable or

antenna to the DTV/TV input

Scan

Skip Scan

Channel Scan

Next Exit

EXIT

Back Select

CONNECTING YOUR DEVICES

Ensure your device has one of the above ports.

Turn your device and the TV off.

Connect your devices using the connection chart on the next

page. This chart shows the most common connections. If you

would like to see additional connection options, see

Connecting

Your Devices

in the user manual.

HDMI

Component

Composite AV

VIZIO RECOMMENDS

To get the best high-resolution picture and sound on your new

VIZIO TV, connect your devices with an HDMI cable.

VIZIO High Speed HDMI Cables are manufactured to produce

the best picture on VIZIO TVs and feature:

•1080p and for full HD video and future Ultra-HD video

•Great ﬂexibility for thin wall mounts

•Stays securely connected at sharp angles

•Limited lifetime warranty

Visit www.VIZIO.com to purchase online.
