Vizio E220VA User manual
E190VA / E220VA / E260VA – QUICK START GUIDE
RAZOR LED™LCD HDTV
PACKAGE CONTENTS
Cleaning Cloth Remote Control with
Batteries
User Manual and
Quick Start Guide
VIZIO Razor LED™LCD HDTV with Stand
Power/Standby
Input (Specific)
Closed Caption (CC)
Exit
Arrow Up
Arrow Right
Arrow Down
Channel
Up/Down
Mute
Number Pad
Info
Last
Volume Up/Down
Arrow Left
Menu/OK
Sleep
Wide
Input
USING THE REMOTE
Input: Change the input device. With each press of the
button, the TV will display a different input.
Input (Specific): Change the input device. Press the button that
corresponds to the input device you wish to
view.
Power/Standby: Turn the TV on or off.
Sleep: Activate the sleep timer. With each press of the
button, the sleep timer’s duration will change.
Wide: Change the displayed aspect ratio.
Closed Caption: Activate or deactivate closed captioning. Press
repeatedly to change the caption channel.
Exit: Close the on-screen menu.
Arrow : Navigate the on-screen menu and episode
guide.
Menu/OK: Display the on-screen menu or select highlight-
ed menu option.
Volume Up/Down: Increase or decrease the loudness of the TV’s
audio.
Channel Up/
Down:
Change the channel. With each press of the
button, the channel will increase or decrease by
one.
Mute: Turn the sound off or on. When mute is acti-
vated, the TV’s audio is turned off.
Last: Return to the channel last viewed.
Number Pad: Use the number pad to manually enter a chan-
nel.
Info: Display the Info Window.
Dash (-): Use with Number Pad to to manually enter a
sub-channel (18-1, 18-2, etc).
FIRST-TIME SETUP
1
Connect the TV’s power cable to an electrical outlet.
Complete your home theater experience! The VIZIO Blu-ray
Player with Wireless Internet Apps delivers full 1080p HD
video, 7.1 surround sound and has built-in 802.11n dual-band
wireless for easy access to movies, TV shows, music and more
from the Internet.
• Delivers Cinematic High-Denition Picture
• Exceptional Full HD 1080p Performance
• Streams Movies, Music, and More with
VIZIO Wireless Internet Apps
• Built-In Wi-Fi - 802.11n
• Up to 7.1 Channel Digital Audio
• Plays MP3s and JPEG Slideshows
Visit www.VIZIO.com to purchase online.
VIZIO RECOMMENDS
2
Connect your antenna or cable/satellite box to the coaxial port on
the back of the TV.
Initial Setup
Allow the VIZIO setup Wizard to
help you tune your channels.
Welcome
Next Exit
EXIT
3
Turn the TV on by pressing the Power/Standby button on the
remote.
The Setup App is displayed.
Press the Right Arrow button on the remote to go to the next
screen.
5
Initial Setup
Please select your language: English
Français
Español
Language
NextBack Select Exit
EXIT
4
Press the Up/Down Arrow buttons on the remote to highlight your
preferred language.
Press Right Arrow to go to the next screen.
Initial Setup
Please select your input location:
NextBack Select
Home
Retail
Mode Setting
Exit
EXIT
5
Press the Up/Down Arrow buttons on the remote to highlight
Home.
Press Right Arrow to go to the next screen.
Initial Setup
Please select your input source:
NextBack Select
Antenna
Cable
Tuner
Exit
EXIT
6
If the TV is connected to an external antenna, select Antenna, then
press Right Arrow and go to step 7.
If the TV is connected to a cable service without a set-top box
(cable is connected directly from the wall outlet) select Cable,
then press Right Arrow and go to step 7.
If the TV is connected to a cable or satellite set-top box, press the
EXIT button on the remote, then select the input to which your
set-top box is connected (HDMI, COMP, or AV).
Initial Setup
Please connect your cable or
antenna to the DTV/TV input
Scan
Skip Scan
Channel Scan
Next Exit
EXIT
Back Select
7
Press the Up/Down Arrow buttons on the remote to highlight
Scan.
Press Right Arrow to begin the channel scan.
Wait for the channel scan to finish.
When the channel scan is complete, the first-time setup is
complete.
VIZIO RECOMMENDS
CONNECTING YOUR DEVICES
To get the best high-resolution picture and sound on your new
VIZIO TV, connect your devices with an HDMI cable.
VIZIO High Speed HDMI Cables are manufactured to produce
the best picture on VIZIO TVs and feature:
• 1080p and for full HD video and future Ultra-HD video
• Great flexibility for thin wall mounts
• Stays securely connected at sharp angles
• Limited lifetime warranty
Visit www.VIZIO.com to purchase online.
1
Ensure your device has one of the above ports.
Turn your device and the TV off.
Connect your devices using the connection chart on the next
page. This chart shows the most common connections. If you
would like to see additional connection options, see
Connecting
Your Devices
in the user manual.
HDMI
Component
Composite AV
High Speed HDMI Cable
Composite AV Cable
Component Video Cable
Audio Cable
Y
CB/PB
CR/PR
L
R
L
R
VIDEO
HDMI
Y
CB/PB
CR/PR
L
R
L
R
VIDEO
HDMI
Good Picture
Best Picture
Better Picture
2
Blu-ray/DVD Player, Game Console,
or other Device
OR
CHOOSE ONE:
OR
HELP TOPICS
Products are often returned due to a technical problem rather than a defective product that may
result in unnecessary shipping charges billed to you. Our trained support personnel can often
resolve the problem over the phone. For more information on warranty service or repair, after the
warranty period, please contact our Support Department at the number below.
Customer support and quality service are integral parts of VIZIO’s commitment to service excellence.
For technical assistance contact our VIZIO Technical Support Department via email or phone.
Please have your VIZIO model number, serial number, and date of purchase available before your
call.
Phone:
Fax:
Email:
Web:
(877) 698-4946
(949) 585-9563
www.VIZIO.com
Hours of operation:
Monday - Friday: 6 am to 9 pm (PST)
Saturday - Sunday: 8 am to 4pm (PST)
The picture quality
seems low.
• View high-denition (HD) programs when possible.
• Ensure all cables are securely connected.
There is no power.
• Ensure the power cord is securely connected to the AC socket on the TV and a working electrical outlet.
• Press the Power/Standby button on the remote or on the right side of the TV.
• Try plugging the power cord into a different electrical outlet.
There is a picture,
but there is no sound.
• Press the Volume Up button on the remote or on the right side of the TV.
• Press the MUTE button on the remote to ensure Mute is off.
• Press MENU, then select TV Settings > Audio. Ensure TV Speakers is set to On.
