Vivo STAND-V000SC User manual

Clamp-on Aluminum Monitor Riser

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/stand-v000s

SKU: STAND-V000SC

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

PACKAGE CONTENTS

WARNING!

A (x1)

Clamp

B(x1)

Padding

C(x1)

Platform

If you do not understand these directions, or if you have any doubts about the safety of the installation,

please call a qualified technician. Check carefully to make sure there are no missing or defective parts.

Improper installation may cause damage or serious injury. Do not use this product for any purpose that is

not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or

injury caused by improper mounting, incorrect assembly or inappropriate use.

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

33lbs

(15kg)

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

S-A (x4)

M5x10

S-B (x1)

Magnet

TIPOVER WARNING

SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER:

• NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF MONITOR OR

STAND.

• USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL

USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIPOVER.

T-A (x1)

3mm Allen Wrench

ASSEMBLY STEPS

STEP 1

Clamp (A) comes preassembled to fit desktops with a thickness of 10-50mm. For desktops with a

thicknes between 40-85mm, Clamp (A) can be adjusted by removing screws in back of assembly using

4mm Allen Wrench (T-B) and and reassembling using the bottom two holes.

T-B

T-B (x1)

4mm Allen Wrench

STEP 2

Secure Clamp (A) to desktop by tightening knob.

STEP 3

Attach Platform (C) to Clamp (A) using M5x10

Screws (S-A) and 3mm Allen Wrench (T-A).

STEP 5

Place Padding (B) on top of Platform (C), taking care to align correctly. Loosen set screw in center post

of Clamp (A) using 3mm Allen Wrench (T-A) to adjust the height. Once you’ve reached the desired

position, retighten the set screw to secure. Place Magnet (S-B) under Platform (C) to store Allen

Wrenches (T-A, T-B) for future adjustments.

STEP 4

Remove adhesive backing from Padding (B).

Knob

S-A

T-A

T-B

S-B

LAST UPDATED: 11/12/2021

REV1.1

Open Monday - Friday 7:00am - 7:00pm CST,

our dedicated support team can oer immediate assistance with rapid response times. If any

parts are received damaged or defective, please contact us. We are happy to replace parts to

ensure you have a fully functioning product.

FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com

[email protected] AVG. RESPONSE TIME (within oice hrs): 1HR 8M

- 23% within < 15m

- 38% within < 30m

- 61% within < 1hr

- 83% within < 2hr

- 92% within < 3hr

Love your new VIVO setup and want to share?

Tag us in your photo! @vivo_us

AVG. RESOLUTION TIME (within oice hrs): < 15 M

www.vivo-us.com

Chat live with an agent!

AVG. RESOLUTION TIME (within oice hrs): 5M 4S

309-278-5303
