Vivitar Vivicam 5B User manual

Quickstart Guide

Vivicam

5 B

数码说明书之家

WWW.54GG.COM

2005.09.04

1. General Precautions .................................................... 2

2. Vivicam 5BIntroduction .............................................. 3

3. The Vivicam 5B.............................................................. 5

4. Taking Images ..............................................................10

5. Installing the Driver and Application Software..........13

6. Transferring Images to Your Computer .................... 16

7. Using The Vivicam 5Bas a PC/Web Camera ............ 20

CONTENTS

Camera Precautions

Follow these guidelines when using your Vivicam 5B:

Keep the camera from the following environments

-High temperature places such as direct sunlight or

extreme heat.

-Excessive humidity, dust, vibration.

Do not use the camera outdoors if it is raining or snowing.

If the lens or the viewfinder gets dirty, clean them

with a lens brush or soft cloth. Never touch the lens with your

fingers.

Do not open the camera case

or attempt your own repairs,

it may create arisk of the electrical shock.

Do not open the battery compartment when the camera

power is on.

Be sure to download your images before replacing or

removing the batteries in order to avoid losing your images

2. Vivicam 5Blntroduction

2.1 Specifications

Resolution:

Digital Camera mode : 640 x 480 pixels (VGA)

320 x 240 pixels (CIF)

PC Camera mode : 640 x 480 pixels

320 x 240 pixels

160 x 120 pixels

Range of Focus : 2 feet to infinity

24 bit full collor

Memory : Built-in 8MB SDRAM

File Format : JPEG or BMP (depending upon Twain AP)

Power : AAA alkaline battery x 1

Interface : USB

Auto Power Off : 20 seconds

2.2 Accessories

1. Camera Cradle

2. One AAA alkaline battery

3. Camera necklace

4. Camera driver and application software CD

5. USB cable

6. Quick Start Guide

The

Vivicam 5

3.1 General

(Face Plate is interchangeable )

Front Back

3.2 LCD Panel indicators

Image Counter

: The number of images remaining (to be taken)

: Power off

: Higher Image Quality -Disable

compression (Default

value with no compression)

: Lower Image Quality -Enable compression -

for more

images

: 50Hz lighting environment

: 60Hz lighting environment

(Default frequency is 60Hz)

PC Connection

: PC Connect (Pop-

up when running U/I application)

Continuos capture

: For Video clipsat 320x240 pixels (CIF resolution)

Self-timer

: Self timer -to capture an image in10 secs.

Resolution:

: 320 x 240 pixels (CIF resolution)-

Low-Resolution

: 640 x 480 pixels (VGA resolution)-

High-Resolution (Default value)

Image Delete

: Delete all the images from memory.

: Delete last image in from memory.

uImportant:

When the the LCD is blinking continuously, it indicates

low battery power

3.3 Status LCD panel icon:

Press the mode key to select a mode or function -

3.4 Tips & Trouble Shooting

To stabilize the cradle on adesk,

insert the barrel of USB

cable into the base of cradle as

shown

The cradle can be also

placed on the top of a

laptop LCD panel.
