Vivitar Vivicam 3610 User manual

Digital Camera

User Manual

020910

Preface

About this manual

This manual is designed to make using the Digital Camera as easy as

possible. Information in this document has been carefully checked for

accuracy; however, no guarantee is given to the correctness of the

contents. The information in this document is subject to change without

notice.

This document contains proprietary information protected by copyright.

All rights are reserved.

Trademarks

All trademarks and registered trademarks are the property of their

respective owners.

Photo Express,DVD PictureShow, Cool 360 and PhotoExplorer,

Presto! VideoWorks,Presto! Image Folio and Presto! Mr. Photo,

iii

TableofContents

Chapter 1 -Getting Started..............................................................1

Features ..................................................................................... 1

Safety Information.................................................................... 2

Included Components............................................................ 3

Camera Overview................................................................... 5

Front View.................................................................... 5

Back View.................................................................... 7

Bottom View..............................................................10

Install the Memory Card.......................................................11

Install the Batteries.................................................................13

Choose a Language.............................................................15

Set the Time and Date..........................................................16

Chapter 2 -Taking Pictures.............................................................18

Ready the Camera ...............................................................18

Select the Camera Mode....................................................19

Frame the Shot .......................................................................20

Zoom and Shoot.....................................................................21

Shut the Camera Down........................................................21

Chapter 3 -Reviewing Your Pictures .............................................22

Switch to Playback Mode....................................................22

Full-Screen Review ...................................................22

Thumbnail Review ....................................................23

Chapter 4 -Connecting to a Computer........................................24

Installing Software..................................................................25

Making the Connection .......................................................27

Copying Images to PC .........................................................28

Using as a PC Camera..........................................................29

Chapter 5 –Mode / Operation Guide...........................................30

Using Snapshot Mode ...........................................................30

Using Timer Mode...................................................................31

Using Preset Mode.................................................................32

Using Playback Mode...........................................................33

Using Setup Mode..................................................................35

Delete / Format ........................................................36

Quality........................................................................37

DPOF...........................................................................38

Date/Time..................................................................39

Language..................................................................40

Storage Media..........................................................40

TV Setting ...................................................................41

Chapter 6 –Using the LCD Display.................................................42

Icon Descriptions....................................................................43

Appendix 1 –Button Function Guide.............................................45

Appendix 2 –Troubleshooting........................................................46

Chapter1 -GettingStarted

Features

•Digital Zoom

•Up to 2048 x 1536 resolution

•Color LCD viewfinder screen

•Video Clip Recording (up to 1 minute)

•2 megapixel sensor resolution

•USB 1.1 interface

•Auto exposure, fixed focus

•Flash Modes: Auto / Red-Eye Reduction / OFF

•White Balance Modes: Auto/ Daylight / Shade /

Tungsten / Fluorescent

•10 second Timer mode

•Full screen or Thumbnail preview

Digital Camera User’s Manual

SafetyInformation

lDo not look at the sun through the viewfinder. Viewing the sun or other

strong light source through the viewfinder could cause permanent

visual impairment.

lDo not disassemble the camera. Touching the product’s internal parts

could result in injury. In the event of a malfunction, only a qualified

technician should repair the product. Should the product break open

as a result of a fall or other accident, remove the batteries and take

the product to an authorized service center for inspection.

lAvoid contact with liquid crystal. Should the LCD display break, care

should be taken to avoid injury due to broken glass and to prevent the

liquid crystal from touching the skin or entering the eyes or mouth.

lDo not use in the presence of flammable gas. Using electronic

equipment in the presence of flammable gas could result in explosion

or fire.

lObserve proper precautions when handling batteries. Uses only size AA

alkaline batteries. Batteries may leak or explode if handled improperly.

Remove the batteries and memory card from the camera if you intend

to store the camera for extended periods of time. Be sure the camera

is turned off before inserting or removing batteries. Do not insert

batteries backwards or upside down. Do not disassemble batteries. Do

not expose batteries to flame or excessive heat. Do not immerse

batteries in or expose to water. Discontinue use immediately if you

notice any change in the battery such as discoloration, deformation or

leakage.

lObserve caution when operating the flash. Do not use the flash close to

anyone’s eyes. This can cause temporary damage to eyesight.

Particular care should be observed when photographing infants –keep

the flash at a distance of at least 1 meter from infants’ eyes.

IncludedComponents

Your digital camera comes equipped with the following

components. Please check to make sure all items are

included.

Contact your retailer immediately if any of the following

components are broken or missing:

1. Digital Camera

2. User’s manual

3. Quick Reference Guide

4. USB cable

5. Two (2) AA alkaline batteries

Digital Camera User’s Manual

6. Installation CD-ROM

7. Soft carrying case

8. Hand strap

CameraOverview

The front view, rear view, bottom view and top view of

the digital camera are shown below. Please take a

moment to review these illustrations to familiarize yourself

with the terms used in the rest of this manual.

FrontView

Digital Camera User’s Manual

1. Shutter Button: Press to take photos and

select options from the menus.

2. Built-in Flash: The flash allows the camera to

take pictures in low light conditions and

can also be used as a fill-in flash for bright

conditions that may have unwanted

shadows.

3. Light Sensor: The digital camera can

automatically detect the ambient light

level and determine whether or not the

flash is needed. The light measurements are

made from this sensor. Take care not to

block the sensor with your finger while

taking a picture.

4. Viewfinder: The viewfinder can be used to

estimate what the picture frame will

include. The actual picture is taken from the

lens not the viewfinder.

5. Self-Timer LED: When the mode dial is set to

Self-Timer and a picture is taken, this LED will

blink for ten seconds and then the camera

will take a picture.

6. Lens: The lens focuses the light onto the

digital image capturing circuitry. For the

best picture quality, care should be taken

to make sure it remains free of dust,

fingerprints, and scratches.
