Vitek VTM-LCD152 User manual
VTM-LCD152
(888) VITEK-70 | WWW.VITEKCCTV.COM
9970 Glenoaks Blvd. Sun Valley, CA 91352 | Local: (818) 771-0300 Fax: (818) 771-0400
VTM-LCD152
•15” LCD Display Panel
•VGA & Composite Video Inputs
•Optimal Resolution of 1024 x 768
•Dimensions With Stand: 14.58” x 13.87” x 8.08” /
Without Stand: 14.58” x 12.3” x 2.37”
•Wireless Remote Control Included
•Integrated Speakers With RCA Left + Right And
3.5mm Stereo Mini Jack IN/OUT
FEATURES
BLACKYELLOWMAGENTACYAN
15” LCD Monitor
15” LCD Monitor
Remote Control
(888) VITEK-70 | WWW.VITEKCCTV.COM
9970 Glenoaks Blvd. Sun Valley, CA 91352 | Local: (818) 771-0300 Fax: (818) 771-0400
BLACKYELLOWMAGENTACYAN
Panel Size
Pixel Pitch
Viewing Angle
Contrast Ration
Brightness
Color Filter
Frequency
Video Bandwidth
Resolution
Display Colors
Display Area
PC Input Signal Sync
PC Input Connection
AV Video Connections
AV Audio Connections
Internal Speaker
Plug and Play
Tilt Range
Power Source
Power Consumption
Power Saving
Operating Temperature
Dimensions (W x H x D)
Weight (Net / Gross)
15” Diagonal
0.297mm x 0.297mm
65˚ (Left/Right) / 55˚ (Up/Down)
400:1
250cd/m2
RGB Vertical Stripe
30 ~ 62 KHz (Horz.) / 50 ~ 75 Hz (Vert.)
80 MHz
1024 x 768 @ 75Hz (Max)
16 Million
304.1mm x 228.1mm
H/V Separate (TTL)
15 Pin Mini D-Sub (Analog RGB)
BNC IN/OUT (Looping)
RCA Left + Right, 3.5mm Stereo Mini Jack IN/OUT
2W (Left 1W & Right 1W)
VESA DDC Compatable
5∫Forward / 30∫Backward
100~240 VAC, 50/60 Hz (Auto Switching)
26W
EPA, VESA DPMS, Nutek Compliant
50˚ ~ 104˚
With Stand: 14.58” x 13.87” x 8.08” (370mm x 352mm x 205mm) /
Without Stand: 14.58” x 12.3” x 2.37” (370mm x 312mm x 60mm)
9.26 Lbs. / 12.1 Lbs.
Detailed Specifications
VTM-LCD152
VTM-LCD152 15” LCD Monitor
15” LCD Monitor
