Vimar ELVOX Pixel Up Series User manual

Installation and wiring manual

PIXEL UP

40404 - 40424

Panel with Due Fili Plus audio and audio/video electronic unit, display and alphanumeric keyboard

Video entrance panel with Due Fili Plus audio and audio/video elec-

tronic unit, display and alphanumeric keyboard

The instruction manual is downloadable from the site www.vimar.com

1.1 Description

Outdoor video entryphone unit with call from contacts list.

The panel has a hole (size 40x40mm), for tting an access control reader.

The device is supplied with a display and keyboard used to make calls using the contacts list or by directly entering the extension

number to be called.

2 EN

PIXEL UP: 40404 - 40424

1.2 Technical characteristics

• Operating temperature: -25° C / +55° C.

• IP54 degree of protection

• IK08 degree of protection against impact

The audio and audio/video module is distinguished by:

- Power supply from Due Fili Bus, via terminals B1 and B2: 28VDC nominal.

- Minimum voltage on terminals B1 and B2: 21Vcc

- Local power via terminals E+, E- if the electronic unit needs to be powered via an additional power supply unit.

The additional power supply unit should be installed if the system's maximum consumption exceeds the power

supply unit's capacity.

- Absorption from Bus or from additional power supply unit:

• in Stand by 120 mA

• in communication 280 mA

• lock activation + 50 mA

• maximum 330 mA

- Video signal output 16 dBm (in the case of video operation)

The 3.5” display has

- 320 x 480 pixels, 65K colours, 500 lux.

- power supply from audio-video module.

The keyboard has:

- 2 congurable relays. The rst relay acts by default as an actuator opening the lock (together with S+ S- in the

audio/video unit). By default the second opens when a “Stair light” or “Aux1” command is given.

- power supply from audio-video module.

PIXEL UP: 40404 - 40424

Interface module

41030UP

Terminal functions

CA- Input programmable using conguration

software (e.g. lock release command, door

open signal sensor, command of actuator

available in system). Note: connect to an

isolated SELV voltage free-contact.

CA+

Terminal functions

OUT1

NO Relay output with NO and NC contacts cho-

sen by the installer.

The contact can control resistive loads exter-

nally powered with maximum current 1 A and

maximum voltage 60 Vdc (maximum voltage

permitted by 60950-1 for the SELV).

OUT2

NO Relay output with NO and NC contacts cho-

sen by the installer.

The contact can control resistive loads exter-

nally powered with maximum current 1 A and

maximum voltage 60 Vdc (maximum voltage

permitted by 60950-1 for the SELV).

Terminal functions

B2 Due Fili Bus

E+ Additional external power supply, from power supply unit

6923 (output +U).

E-

CA+ Lock control additional button (Default).

Alternatively (if congured via SaveProg), sensor input

to signal “Door Open”.

CA-

S+

Electric lock output

Note: S+/S- outputs. The entrance panel supplies a

current peak IT>1A for 10ms after which there follows a

maintenance current IM=200mA for the entire duration of

the lock command (see lock time).

S-

40404 audio/video entrance panel rear view

4 EN

PIXEL UP: 40404 - 40424

Due Fili Plus

audio video unit

41005UP

Display

41018UP

Alphanumeric

keyboard

41019UP

Terminal block for connection tot he audio/video unit

Terminal block for connection to display

Terminal block for connection to keyboard

Hole (size 40x40mm), for tting

an access control reader

Interface module

41030UP

Terminal functions

CA- Input programmable using conguration

software (e.g. lock release command, door

open signal sensor, command of actuator

available in system). Note: connect to an

isolated SELV voltage free-contact.

CA+

Terminal functions

OUT1

NO Relay output with NO and NC contacts cho-

sen by the installer.

The contact can control resistive loads exter-

nally powered with maximum current 1 A and

maximum voltage 60 Vdc (maximum voltage

permitted by 60950-1 for the SELV).

OUT2

NO Relay output with NO and NC contacts cho-

sen by the installer.

The contact can control resistive loads exter-

nally powered with maximum current 1 A and

maximum voltage 60 Vdc (maximum voltage

permitted by 60950-1 for the SELV).

Terminal functions

B2 Due Fili Bus

E+ Additional external power supply, from power supply unit

6923 (output +U).

E-

CA+ Lock control additional button (Default).

Alternatively (if congured via SaveProg), sensor input

to signal “Door Open”.

CA-

S+

Electric lock output

Note: S+/S- outputs. The entrance panel supplies a

current peak IT>1A for 10ms after which there follows a

maintenance current IM=200mA for the entire duration of

the lock command (see lock time).

S-

Display

41018UP

Alphanumeric

keyboard

41019UP

Terminal block for connection to display

Terminal block for connection to keyboard

Hole (size 40x40mm), for tting an access control

reader

40424 audio entrance panel rear view

MVideo signal input for external CCTV camera

(V= coaxial core, M=earth)

Outdoor video camera connection terminal block

(only for 40424)

Due Fili Plus

41002UP audio

unit

Morsettiera di collegamento alla unità audio/video

PIXEL UP: 40404 - 40424

1.3 Installation

1. Install the ush-mounted or external surface mounting box at a height of approx. 1.65 m or 1.20 m for accessibility for the disabled, from the

upper edge of the box to the oor.

2. Connect the terminal block of the electronic unit to the system.

3. Having connected the device it will work with the default parameters. If special congurations are required, refer to the relative Programming

manual.

4. Close the panel, xing the front cover plate to the box using the screws.

1.8

(83°)

1,65m1,20 m

2,6 m (104°)

H angle (opening at 1m) 104° (2.6m)

V angle (opening at 1m) 83° (1.8m)

Diagonal angle 129°

1.3.1 Videocamerainstallationheightandeldofview.

1.8 m

(83°)

1,65m1,20 m

2,6 m (104°)

6 EN

PIXEL UP: 40404 - 40424

1.3.2 Installationwithushmountingbox

1.3.3 Installationwithexternalsurfacemountingbox

PIXEL UP: 40404 - 40424

Remove the support brackets from the box

and turn them downwards to the horizontal po-

sition. Hook the panel to the brackets through

the slots on the side of the metal frame.

1.4 Wiring diagram

D - Audio-video entrance panel with display and keyboard 40404

F - System power supply unit 6922.1

P - Electric lock

L - Additional lock control button

X - Twisted cable 732H.E, 732I.E

PRI

B22

1B1

CA+

CA-

S-

S+

E-

E+

41005UP

41019UP

41018UP

41030UP

CA-

CA+

OUT2 OUT1

Video entryphone/entryphone riser

Mains

6922.1

8 EN

PIXEL UP: 40404 - 40424

PRI

-+U+I

PRI

B22

1B1

CA+

CA-

S-

S+

E-

E+

41005UP

41019UP

41018UP

41030UP

CA-

CA+

OUT2 OUT1

Video entryphone/entryphone riser

Mains Mains

6922.1

6923

Note: If the distance between the additional power supply unit 6923 and the power supply is more than 3m, use the lter code 41021 installed

near the audio/video module and inside the box”.

Caution: observe the correct polarity when connecting.

D - Audio-video entrance panel with display and keyboard 40404

F - System power supply unit 6922.1

F1 - Additional power supply unit 6923

P - Electric lock

L - Additional lock control button

X - Twisted cable 732H.E, 732I.E

PIXEL UP: 40404 - 40424

1.4.1 Version of wiring additional power supply with power supply unit 6923

Caution: The camera must be equipped with its own power supply unit with suitable characteristics. Check that the type of power supply unit

and the connections do not cause any interference with the operation of the electronic unit. Otherwise an insulation lter such as art. 692G

can be used.

D - Audio-video entrance panel with display and keyboard

40425

F - System power supply unit 6922.1

F3- Power supply unit for external CCTV camera

P - Electric lock

L - Additional lock control button

X - Twisted cable 732H.E, 732I.E

ConnectionvariantforAudiopanel41425withexternalCCTVcamera

We recommend you insert a 100 Ohm termination at the video input of the entrance panel if the camera does not play back any video.

10 EN

PIXEL UP: 40404 - 40424

PRI

B22

1B1

CA+

CA-

S-

S+

E-

E+

41005UP

41019UP

41018UP

41030UP

CA-

CA+

OUT2 OUT1

PRI

6922.1

Video entryphone/entryphone riser

Mains Mains

This manual suits for next models
