Viking VRCO1240DRSS User manual

OUTDOOR—REFRIGERATION

Undercounter/Freestanding

24”W. Refrigerator

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1- -VIKING1

All models include

• Agency certified for outdoor use

• Electronic controls with digital

temperature readout

oInside temperature can be adjusted

from 33 – 39ºF

oFactory set at 34ºF

oSabbath mode

oTemperature can be displayed in

either Fahrenheit or Celsius

• Capacity—5.3 cu. ft. (150.0 L)

• Two full-extension adjustable wire

shelves

o75 lbs. capacity

oRemovable and adjustable

• Solid doors with keyed door lock

• LED display lighting

• Forced air cooling system with

powerful 700 BTU compressor

• Tru-Flush™design allows unit to fit

flush in 24” deep cutout

• Energy Star qualified

• Undercounter or freestanding

installation

• Self-closing door

• Super quiet 32-39 db sound rating

• Stainless steel kickplate

• Adjustable leveling legs

• Must be ordered right or left hinge

(As you face unit, RIGHT has hinge on

right side and handle on left side; LEFT

has hinge on left side and handle on

right side.)

VRCO 240D

Professional

FINISH DETAILS FOR VRCO MODELS

• Solid door

oStainless Steel (SS)

oStainless Steel interior

oFinish codes designate door front.

Stainless steel handle with chrome-plated

brackets and stainless steel exterior

cabinet.

Standard Features & Accessories

ORDERING INSTRUCTIONS

First specify model number, then specify hinge preference (“R” for right or “L” for left), and then color code (VRCO1240DRSS).

R E L E A S E D 1 1 / 1 / 1 1

Model Options

OUTDOOR—REFRIGERATION

Undercounter/Freestanding

24”W. Refrigerator

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1- -VIKING1

✪

Please see

Installation Notes &

Accessories

for important

information,

including handle

kits.

Dimensions & Specifications

VRCO1240D Overall width

23-7/8” (60.6 cm)

Overall height 34-1/4” (87.0 cm) min. to 3 ” (89.0 cm) max.

Overall depth (from rear

To front of handle 26-9/16” (67.5 cm

Approx. ship weight 21 lbs. (98.0 kg)

VRCO 240D

Professional

PRODUCT DIMENSIONS

R E L E A S E D 1 1 / 1 / 1 1

22-1/16”

(56.0cm)

24-1/16”

(61.1cm)

26-9/16”

(67.5cm)

34-1/4”

(87.0cm)

min.

35”

(89.0cm)

max.

23-7/8”

(60.6cm)

23-7/8”

(60.6 cm)

23-7/8”

(60.6cm)

30-1/8”

(76.5cm)

PROFESSIONAL

OUTDOOR—REFRIGERATION

Undercounter/Freestanding

24”W. Refrigerator

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1- -VIKING1

Dimensions & Specifications

DOOR SWING

R E L E A S E D 1 1 / 1 / 1 1

7-9/16”

(12.9 cm)

94.0 Swing

required for

pull-out shelf

clearance

2-27/32”

(5.6 cm) min.

clearance

from a corner

to achieve 94°

door swing

24-25/32”

(40.1 cm)

min. clearance

for door swing

Power cord 6-7/16”

(16.8 cm) off floor.*

50” (127.0 cm) area in which

electrical outlet must be located

PROFESSIONAL

VRCO 240D

Professional

OUTDOOR—REFRIGERATION

Undercounter/Freestanding

24”W. Refrigerator

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1- -VIKING1

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

• Three-wire cord

with grounded

three-prong plug

attached to

product

• 115V/60 Hz; 15

amp dedicated

circuit

• Maximum amp

usage—3.0

PLUMBING

Not applicable

Installation Requirements

34-1/2” (87.6 cm) min.

35-1/2” (90.2 cm) max.

24”

(61.0 cm)

24” (61.0 cm)

ACCESS REQUIREMENTS

All models

Cutout width 24” (61.0 cm)

Cutout height 34-1/2” (87.6 cm) min. to 3 -1/2” (90.2 cm) max.

Cutout depth 24” (61.0 cm)

R E L E A S E D 1 1 / 1 / 1 1

VRCO 240D

Professional

OUTDOOR—REFRIGERATION

Undercounter/Freestanding

24”W. Refrigerator

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1- -VIKING1

R E L E A S E D 1 1 / 1 / 1 1

Stainless Steel Cabinetry-Bases

• Stainless Steel (SS)

• For use with 24”W. Viking outdoor refrigeration products

•See individual product pages (storage section) for more information and additional specifications

Stainless Steel Cabinetry-Oven Towers

• Stainless Steel (SS)

• For installation of 24” refrigerator with oven

• See individual product pages (storage section) for more information and additional specifications

Compliance Information

WARRANTY SUMMARY*

• One-year full warranty—complete unit

• Five-year limited warranty—sealed refrigeration system (includes compressor, condenser,

dryer/strainer, evaporator, and connecting tubing)

• Ninety-day limited warranty—cosmetic parts such as glass, painted items, and decorative items

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

✪Installation Notes & Accessories

Model Description Approx. ship wt. lbs. (kg)

VURO3200 Base for 24”W outdoor refrigerator 125 (56.7

Model Description Approx. ship wt. lbs. (kg)

VERO3200 32”W. tower (for 24”W. refrigerator + smoker oven 271 (122.9

VGRO3200 32”W. tower (for 24”W. refrigerator + gas oven 271 (122.9
