Viking RVGC3305BSS User manual

Easy Operation and Cleanup

•Permanently sealed burners – spills cannot enter burner box

•One-piece, extremely durable steel top with separate spill

collection areas

•Durable metal die-cast knobs with child-proof, push-to-turn

safety feature

•Customer-removable knobs, grates, and burners/caps for

easy cleaning

•Continuous grate design for easy movement of pots and pans

•Overall/burner box dimensions designed to fit majority of

similarly sized cooktop cutouts

Installation Accessories

•LP conversion kit (RDLPKC)

•Natural conversion kit (RDNFC)

Finish

• Available in Stainless Steel (SS)

–Finish designates top; all units have black porcelain grates

and burner caps

Warranty Highlights

•Three-year full – complete product

•Ninety-day full – cosmetic parts such as glass, painted items,

and decorative items

•Lifetime limited – stainless steel exterior

•Five-year limited – surface burners

GAS COOKTOPS

RVGC330-5B – 30” WIDE

RVGC336-5B – 36” WIDE

Features and Functions

•Wide variety of BTU ratings to accommodate all types

of surface cooking needs

–30” wide model – 5 burners

•Left front – 9,100 BTU

•Left rear – 9,100 BTU

•Center – 17,000 BTU (dual stacked burner)

•Right front – 12,000 BTU

•Right rear – 5,000 BTU

–36” wide model - 5 burners

•Left front – 9,100 BTU

•Left rear – 9,100 BTU

•Center – 17,000 BTU (dual stacked burner)

•Right front – 12,000 BTU

•Right rear – 5,000 BTU

•Sealed burners with aluminum flame ports and porcelainized,

cast-iron burner caps

• Exclusive – SureSpark™Ignition System

–Automatic electronic spark ignition/re-ignition surface burners

light at any position on the knob and re-light if extinguished,

even on lowest setting

36” Wide Gas Cooktop

30” Wide Gas Cooktop

F60258

Viking Range, LLC | 1-888-845-4641 or 662-455-1200

For detailed product information, model numbers, or to request a quote visit vikingrange.com

0713

DESCRIPTION GAS 30”AND 36” WIDE COOKTOPS

RVGC330-5B RVGC336-5B

Overall Width 30 3/4” (78.1 cm) 36 3/4” (93.3 cm)

Overall Height 4 3/8” (13.7 cm)

Overall Depth 21" (53.3 cm)

Cutout Width 29 1/4” (74.3 cm) minimum

29 7/8” (75.9 cm) maximum

35 1/4” (89.5 cm) minimum

35 7/8” (91.1 cm) maximum

Cutout Height 3 1/8” (7.9 cm)

Cutout Depth 20” (50.8 cm) minimum; 20 1/4” (51.4 cm) maximum

Gas Requirements Ships Natural or LP/Propane; Field convert with conversion kit (purchased separately); accepts standard residential

1/2” (1.3 cm) ID gas service line.

Electrical Requirements 120VAC/60Hz; 4 ft. (121.9 cm), 3-wire cord with grounded 3-prong plug attached to product

Maximum Amp Usage 2.0 amps

Surface Burner Rating

Left Front – 9,100 BTU

Left Rear – 9,100 BTU

Center – 17,000 BTU

Right Front – 12,000 BTU

Right Rear – 5,000 BTU

Left Front – 9,100 BTU

Left Rear – 9,100 BTU

Center – 17,000 BTU

Right Front – 12,000 BTU

Right Rear – 5,000 BTU

Approximate Shipping

Weight 49 lb. (22.0 kg) 74 lb. (33.3 kg)
