ViewSonic PJD5483s User manual

XGA resolution, 3000lm lumens, 15000:1 contrast, up to 7000 hours lamp life

The Best Value Short Throw Projector Enables Presentation for Small-Medium

Rooms

Overview

ViewSonic’s new short throw projection model,the PJD5483s, requires merely 0.76 meter for a 72” image

projection. It is perfect for use in limited room space. Boasting BrilliantColor™ technology, 3,000 lumens, and

a 15,000:1 contrast ratio, the PJD5483s delivers clear, crisp images and vividly accurate colors to best meet

the environment requirements of any presentation. This budget-friendly option features DynamicEco

Technology allowing it to automatically adjust lamp brightness, extending the lamp life to 7000 hours. The

HDMI connection and multiple video input options in the PJD5483s provide ﬂexible connections to a variety of

media devices while the integrated speaker saves the effort of connecting external speakers. The Off-to-Go

mode, vertical keystone correction, and 144Hz/3D ready functions allow the operation of this projector series

to be simple and efﬁcient, making presentations easier than ever.

Features

Short Throw projection

The PJD5483s adopts a cutting-edge short throw lens

that requires 0.76 meters for a 72” image projection. The short

throw facilitates a more comfortable presentation experience by

eliminating distractions from shadows on the screen, as well as

eyestrain and glare from the projector’s blinding light.

For more product information, visit us at www.viewsoniceurope.com

trademarks are the property of their respective companies. E&EO. All prices and

eciﬁcations are sub

ect to chan

e without written notice. Ima

es are for illustrative

ose onl

. Terms & Conditions A

1／5

XGA resolution, 3,000 lumens, and 15,000:1 contrast

ratio

The PJD5483s supports 3,000 lumens brightness and

15,000:1 contrast, ensuring image quality will remain crystal clear

and vivid even in bright environments.

BrilliantColor™ technology HDMI 1.4 Input

ViewSonic integrates BrilliantColor™ technology into the

PJD5483s to construct digital colors that deliver

stunning, vibrant images. The advanced 6-segment color wheel

speciﬁcally enriches the performance of yellow and further

augments overall color reproduction to ensure a deﬁned picture

quality. Along with HDMI 1.4, the PJD5483s offers

connectivity to a versatile range of HD devices, projecting superior

images for a large screen experience.

7000-hours high performance long-life light bulbs

The The energy-saving mode on the PJD5483s automatically

adjusts the brightness to optimize performance, extending the lamp

life to up to 7,000 hours and saving maintenance costs.

DynamicEco Technology makes excellent energy conservation

ViewSonic’s proprietary DynamicEco technology will automatically

adjust lamp brightness to prolong projector lamp life and conserve

up to 70% power consumption.

For more product information, visit us at www.viewsoniceurope.com

trademarks are the property of their respective companies. E&EO. All prices and

eciﬁcations are sub

ect to chan

e without written notice. Ima

es are for illustrative

ose onl

. Terms & Conditions A

2／5

Mac®

Physical (mm)

3D projection ready

The 3D DLP® Link technology brings presentations to life by

supporting an image update frequency of 144Hz, allowing the

projected images to be displayed with a 3D stereoscopic effect.

Off-to-Go Mode saves your time

The efﬁcient Off-to-Go mode on the PJD5483s enables quick

shutdown and turn-on, saving every second of your valuable time.

The PJD5483s takes only 3 seconds to turn on and shuts down

instantly, requiring zero power consumption to cool down the

projector.

Easy vertical keystone correction

When projectors are tilted, the projection image aspect ratio may

display rectangular images in a trapezoidal shape, resulting in image

distortion. The PJD5483s offers +40°/-40° keystone correction to ﬁx

image distortion issues easily and quickly.

Ultra-low power consumption in standby mode

The PJD5483s consumes only 0.5W in standby mode, saving

ownership cost and practicing environmental friendliness.

Technical Speciﬁcations

1024 x 768 @ 60Hz (Native)

1024 x 768 @ 75Hz

294 x 202 x 95(W × D × H)

COMPATIBILITY

DIMENSIONS

For more product information, visit us at www.viewsoniceurope.com

trademarks are the property of their respective companies. E&EO. All prices and

eciﬁcations are sub

ect to chan

e without written notice. Ima

es are for illustrative

ose onl

. Terms & Conditions A

3／5

Physical (in)

Speaker

Frequency

Computer and

Video

Audio Out

S-Video Input

HDMI (input)

RS-232

Audio Input

USB

Component-In

Composite Input

RGB Input

RGB Output

Voltage

Consumption

Contrast Ratio

Display size

Aspect Ratio

Throw Distance

Throw Ratio

Brightness

Color Wheel

Keystone

Correction

11.57” x 7.95” x 3.74”(W × D × H)

ROHS, REACH, SVHC, WEEE, ErP

1.8 Meter Power Cord *1, 1.8 Meter VGA Cable *1, Remote

Control *1 with AAA Battery, Quick Start Guide (one sheet

version) *1, ViewSonic CD Wizard (with user manual) *1,

Warranty Card & Sticker (only for China) *1

2W *2

Horizontal: 31 ~ 100 kHz

Vertical: 48 ~ 120 Hz

NTSC M (3.58 MHz), 4.43MHz

PAL (B, D, G, H, I, M, N, 60)

SECAM (B, D, G, K, K1, L)

480i and 576i

480p and 576p

720p,1080i, 1080p

3.5mm mini- Mono Jack *1

Mini-Din 4 pin *1

1.4 *1

DB-9 *1

3.5mm mini- Mono Jack *2

Mini Type B

Share with RGB *2

RCA *1

DB-15 *2

DB-15 *1

100V ~ 240Vac 50 / 60Hz

315W (Max.)

15,000:1

40" ~300” (diagonal)

4:3

0.5m ~ 4m

0.62

3,000 lm

6-Seg RGBCYW

+40 ~ -40

REGULATIONS

PACKAGE

CONTENTS

AUDIO

INPUT SIGNAL

CONNECTOR

POWER

DISPLAY

For more product information, visit us at www.viewsoniceurope.com

trademarks are the property of their respective companies. E&EO. All prices and

eciﬁcations are sub

ect to chan

e without written notice. Ima

es are for illustrative

ose onl

. Terms & Conditions A

4／5

Lamp life ( Normal

/ Eco / Dynamic

Eco )

Resolution

Lamp

Lens

Net

Humidity

Temperature

Altitude

3,500 /5,000 /7,000 hours

1024 (H) x 768 (V)

OSRAM

English, France, Spanish, Thai, Korea, Germany, Italian, Russian,

Swedish, Dutch, Polish, Zech, T-Chinese, S-Chinese, Japanese,

Turkish, Portuguese, Finnish, Indonesian, India, Arabic

4.71lbs (2.14kgs)

10 ~ 90% (non- condensation)

32° ~ 104° F (0° ~ 40° C)

0 ~ 6,000 ft.

TI DMD 0.55

ViewSonic® Limited Warranty

ViewSonic provides customers with the security of a manufacturers warranty against defected

products. The type and duration of the applicable warranty service varies by product type,

country of purchase and can also vary on an individual basis according to customer

requirements agreed at time of purchase. The warranty will expire after the end of the warranty

period.

LANGUAGE

WEIGHT

OPERATING

CONDITIONS

CHIPSET

For more product information, visit us at www.viewsoniceurope.com

trademarks are the property of their respective companies. E&EO. All prices and

eciﬁcations are sub

ect to chan

e without written notice. Ima

es are for illustrative

ose onl

. Terms & Conditions A

5／5
