ViewSonic VG511s User manual

Model No. VLCDS27955-3W/4W

15” Color TFT LCD Display

Service Manual

ViewSonic VG511s/VG512s

ViewSonic

381 Brea Canyon Road, Walnut, California 91789 USA - (800) 888-8583

(VG511s/VG512s_SM_742 Rev. 1aApr.2004)

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or

computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,

manual or otherwise, without the prior written permission of ViewSonic Corporation.

Disclaimer

ViewSonic makes no representations or warranties, either expressed or implied, with respect to the

contents hereof and specifically disclaims any warranty of merchantability or fitness for any particular

purpose. Further, ViewSonic reserves the right to revise this publication and to make changes from time

to time in the contents hereof without obligation of ViewSonic to notify any person of such revision or

changes.

Trademarks

ViewSonic is a registered trademark of ViewSonic Corporation.

All other trademarks used within this document are the property of their respective owners.

Optiquest is a registered trademark of ViewSonic Corporation.

Revision History

Revision Date Description Of Changes Approval

ViewSonic CorporationConfidential

Do Not Copy VG511s

1a 04/14/04 Initial Release DCN-3756 Angela Lu

VG512s

TABLE OF CONTENTS

2. Specification

3. Front Panel Function Control Description

4. Circuit Description

6. Trouble Shooting Flow Chart

9. Block Diagram

10. Schematic Diagrams

7. Recommended Spare Parts List

1. Precautions and Safety Notices

5. Adjusting Procedure

8. Exploded Diagram And Spare Parts List

11. PCB Layout Diagrams

ViewSonic CorporationConfidential

Do Not Copy VG511s

VG512s

Prior to using this manual, please ensure that you have carefully followed all the procedures outlined in the user manual

for this product.

Read all of these instructions.

Save these instructions for later use.

Follow all warnings and instructions marked on the product.

Do not use this product near water.

This display should be installed on a solid horizontal base.

When cleaning, use only a neutral detergent cleaner with a soft damp cloth. Do not spray with liquid or aerosol cleaners.

Do not expose this display to direct sunlight or heat. Hot air may cause damage to the cabinet and other parts.

Adequate ventilation must be maintained to ensure reliable and continued operation and to protect the display from

overheating. Do not block ventilation slots and openings with objects or install the display in a place where

ventilation may be hindered.

Do not install this display near a motor or transformer where strong magnetism is generated. Images on the display

will become distorted and the color irregular.

Do not allow metal pieces or objects of any kind fall into the display from ventilation holes.

Slots and openings in the cabinet and the back or bottom are provided for ventilation, to ensure reliable operation of

the product and to protect it from overheating, those openings muse not be blocked or covered.

The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.

This product should never be placed near or over a radiator or heat register.

This product should not be placed in a built-in installation unless proper ventilation is provided.

1. Precautions and Safety Notices

ViewSonic CorporationConfidential

Do Not Copy VG511s

VG512s

2.1. PRODUCT SPECIFICATIONS

LCD panel type 15.0” TFT (15.0” Diagonal)

Displayable resolution XGA 1024 x 768 maximum

Pixel dimension 0.297 mm horizontal x 0.297 mm vertical

LCD display color 16.8M Colors Max.

OSD control AUTO CONFIG, BRIGHTNSS,

CONTRAST, COLOR (R, G, B, BLACK LEVEL ADJUST),

POSITION(H-POSITION, V-POSITION ),IMAGE (PHASE,

CLOCK ),

SETUP MENU (RESET,OSD POSITION, SYSTEM INFO )

Manualcontrolbuttons MENU, Select, Adjust(up,down), Power.Mute,+,-

Viewing angle Horizontal: ±60 , Vertical: -45~+55.

Tilt +20°, -5°.

Contrast ratio 450:1 (typ) , 300:1 (min)

Brightness 250 cd/m2 (typ), 200 cd/m2 (min)

Response time 16ms (typ) tr+tf , 23ms (max) tr+tf

Active display area 304.1 mm (H) x228.1mm (V)

AC/DC adapter Input: AC 100 ~ 240V, 50 ~ 60 Hz

Output: +12 V DC.

Input signal Video: Analog 0.7 Vp-p. 75 ohms

Sync. : TTL Level, Positive/ Negative, Separate Sync.

Input connector 15 Pin D-Sub.

Power management yes

Dimensions ( WxHxD ) 34.6 cm x 35.5 cm x 15.6 cm.

Weight 2.7 kgs. (LCD Module only)

3.4kgs. (unit)

Accessory VGA cable, AC/DC adapter, power cord.

Temperature Operation : 0 ~ 50°C

Storage : -20 ~ 60°C

Color temp (white) White x 0.313±0.03 , white y 0.329±0.03

2. Specification

ViewSonic CorporationConfidential

Do Not Copy VG511s

VG512s

2.2. FACTORY SUPPORTING MODES

Prim

Factory Preset Modes

ary Preset VESA 1024 x 768 @ 60 Hz

1. 640 x 350 @ 70Hz, 31.5kHz

2. 640 x 480 @ 60Hz, 31.5kHz

3. 640 x 480 @ 67Hz, 35.0kHz

4. 640 x 480 @ 75Hz, 37.5kHz

5. 640 x 480 @ 72Hz, 37.9kHz

6. 720 x 400 @ 70Hz, 31.5kHz

7. 800 x 600 @ 56Hz, 35.1kHz

8. 800 x 600 @ 60Hz, 37.9kHz

9. 800 x 600 @ 75Hz, 46.9kHz

10. 800 x 600 @ 72Hz, 48.1kHz

11. 800 x 600 @ 85Hz, 53.7kHz

12. 832 x 624 @ 75Hz, 49.7kHz

13. 1024 x 768 @ 60Hz, 48.4kHz

14. 1024 x 768 @ 70Hz, 56.5kHz

15. 1024 x 768 @ 72Hz, 58.1kHz

16.1024 x 768 @ 75Hz, 60.0kHz

2.3. D-SUB CONNECTOR

This section describes the pin assignment of the LCD’s video connector.

Pin NO. Signal Connector

1 Red Video Signal

2 Green Video Signal

3 Blue Video Signal

4 N.C.

5 Ground

6 Ground

7 Ground

8 Ground

9 +5V

10 Ground

11 N.C.

12 DDC data

13 Horizontal sync signal

14 Vertical sync signal

15 DDC clock

It is called 15 Pin Mini D-sub Connector.

ViewSonic CorporationConfidential

Do Not Copy VG511s

VG512s

Table 3.1: 15 pin D-sub connector pin assignment

Pin Number Pin Function

1 Red video input

2 Green video input

3 Blue video input

4 No Connection

5 Ground

6 Red video ground

7 Green video ground

8 Blue video ground

9 +5V

10 Ground

11 No connection

12 (SDA)

13 Horizontal sync (Composite sync)

14 Vertical sync

15 (SCL)

Table 3.2: 24 pin DVI-D connector pin assignment

Pin No. Signal Name Description

1 RX2- TMDS negative differential input, channel 2

2 RX2+ TMDS positive differential input, channel 2

3 GND Logic Ground

4 Reserved 4 Reserved. No connection

5 Reserved 5 Reserved. No connection

6 DDC-CLK DDC2B Clock

7 DDC-DAT DDC2B Data

8 Reserved 8 Reserved. No connection

9 RX1- TMDS negative differential input, channel 1

10 RX1+ TMDS positive differential input, channel 1

11 GND Logic Ground

12 Reserved 12 Reserved. No connection

13 Reserved 13 Reserved. No connection

14 VCCX Power

15 GND Logic Ground

16 SENS SENSE Pin, Pull High

17 RX0- TMDS negative differential input, channel 0

18 RX0+ TMDS positive differential input, channel 0

19 GND Logic Ground

20 Reserved 20 Reserved. No connection

21 Reserved 21 Reserved. No connection

22 GND Logic Ground

23 RXC+ TMDS positive differential input, reference clock

24 RXC- TMDS negative differential input, reference clock

ViewSonic CorporationConfidential

Do Not Copy VG511s

VG512s

3.1 Location of Controls

3. Front Panel Function Control Description

ViewSonic CorporationConfidential

Do Not Copy VG511s

VG512s

To confirm the current selection. It also used for go back to previous menu for sub-menu,

and the change data will be save to memory.

To scroll up in sub menu or to increase value of selected item.

4) ADJUST ▲:

To scroll down in sub menu or to decrease value of selected item

5) POWER SWITCH

Pushing the power switch will turn the monitor on. Pushing it again to turn the monitor off.

6) POWER INDICATOR

The LED will light with green color in normal on state, and will

light with orange color in power saving mode.

7) BRIGHTNESS/CONTRAST:

Press button UP/DOWN

8)AUTOIMAGEADIUST:

press button [2]

9) OSD LOCK AND UNLOCK:

press two buttons [1] & [UP] simultaneously for 10 seconds

10)POWER LOCK AND UNLOCK:

press two buttons [1] & [DOWN] simultaneously for 10 seconds

11) ALL RESET:

First,power off the monitor, un-plug the AC cord, then press [2] key at the same time and plug

12) FACTORY MODE:

First,power off the monitor, un-plug the AC cord and be sure the signal cable is connected (D-sub

connected),then press [ ] key at the same time and plug the AC cord.

13) RUN-IN MODE:

First ,power off the monitor, up-plug the AC cord and be sure the cable is not connected(D-Sub

not connected),then press [1] key at the same time and plugthe AC cord.

14) AUTO COLOR:

press three buttons [1] & [up] & [down], this function only use for 1024x768 60hz patten 42/of

Chroma 2135 signal generator.

NOTE:

chroma Patten 42

2) SELECT:

ADJUST ▼:

▲

the AC cord

1) MENU:

Enter to the OSD adjustment menu. It also used for go back to previous menu for sub-menu,

and the change data don’t save to memory.

ViewSonic CorporationConfidential

Do Not Copy VG511s

VG512s

WORKING THEOREM

A. DC-DC CONVERTER

This brick converts the 12V input voltage to 5V for panel use and 3.3V for controller use.

It consists of a PWM IC (AP1501), flywheel Diode (D1), buck choke (L2), and capacitor (C70,71).

AP1501 is a PWM generator working at 150Khz.

Self protection features include a two stage frequency reducing current limitfor the output

switch and an over temperature shutdown for complete protection under fault condition.

B. A/D converter

The MST 9030A is a highly integrated TFT LCD controller chip with the latest MST advanced imageprocessing technology

and an integrated ADC/PLL. The MST 9030A has advanced programmable non-linear parametric

cubic based scaling engine with proprietary sharpness adjustment and text enhancement. MST9030A supports both analog

and digital interfaced inputs with an internal ADC/PLL.

The MST9030A has robust handling of a wide variety of TFT LCD panels and strong support of standard

or non-standard input timings.

. Integrated high speed triple 8-bit ADC/PLL support up to 140MHz for XGA-75Hz

. Advanced image processing with proprietary non linear parametric cubic based scaling engineSupport dual interface

with an integrated ADC/PLL

. Robust auto configuration for input mode detection and clock frequency and phase recovery for standard or

nonstandard input timing

. Support video processing with on-chip 2D de-interlacing and color space conversion

. Support programmable Gamma Correction

. GPIO pins for flexible system design

D. MCU:

The MTV312MV64AJ micro-controller isan 8051 CPU core embedded device speciallytailored toLCD monitor

applications. It include an 8051 CPU core, 1024-byte SRAM, 14 built-in PWM DACs, VESA DDC interface,

4 channel 6bit A/D converter, a 64 K-byteinternal program Flash-ROM .

4. Circuit Description

ViewSonic CorporationConfidential

Do Not Copy VG511s

VG512s

This manual suits for next models

Table of contents

Other ViewSonic Monitor manuals

ViewSonic

ViewSonic VA2762-4K User manual

ViewSonic

ViewSonic VG150m-1 User manual

ViewSonic

ViewSonic VX2779-HD-PRO User manual

ViewSonic

ViewSonic VX2240W - 22" LCD Monitor User manual

ViewSonic

ViewSonic VA503B - 15" LCD Monitor User manual

ViewSonic

ViewSonic ViewBoard IFP50 Series User manual

ViewSonic

ViewSonic OP1710 User manual

ViewSonic

ViewSonic G773 - 17" CRT Display User manual

ViewSonic

ViewSonic VA2406m-LED User manual

ViewSonic

ViewSonic G90FB User manual

ViewSonic

ViewSonic VA1912WB - 19" LCD Monitor Manual

ViewSonic

ViewSonic VX2462-HD-2 User manual

ViewSonic

ViewSonic ViewBoard IFP9850-3 User manual

ViewSonic

ViewSonic VS10772 Quick start guide

ViewSonic

ViewSonic VA2735-h User manual

ViewSonic

ViewSonic VX2776-4K-mhdu User manual

ViewSonic

ViewSonic ViewPanel VA800 User manual

ViewSonic

ViewSonic VS13518-1W User manual

ViewSonic

ViewSonic VA2407h User manual

ViewSonic

ViewSonic ViewPanel VG191 User manual

ViewSonic

ViewSonic va720-1 User manual

ViewSonic

ViewSonic VP2365WB - 23" LCD Monitor User manual

ViewSonic

ViewSonic VG930M - 19" LCD Monitor User manual

ViewSonic

ViewSonic VA2855Smh User manual

Popular Monitor manuals by other brands

Linear Acoustic

Linear Acoustic LQ-1000 user guide

AOC

AOC I2579V user manual

Gateway

Gateway FPD1520 user guide

Furuno

Furuno Mu 120c Operator's manual

Asus

Asus VB171D - 17" LCD Monitor Service manual

Dell

Dell S2230MX Setting up

Philips

Philips 107C64 user manual

Dell

Dell S2409WFP user guide

EverFocus

EverFocus EN-7517E instruction manual

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Service manual

Dell

Dell Precision 7680 Connection guide

LG 50PM1M - - 50" Plasma Panel Service manual

Bosch

Bosch DDU 9 manual

Acer

Acer A231HL user manual

Philips

Philips 86BDL4152T user manual

NEC

NEC AccuSync LCD5V user manual

Emay

Emay SleepO2 user manual

IBM

IBM 6360 Product support manual
