Videx 3000 Series User manual

TECHNICAL SUPPORT

Tel: 0191 224 3174

Fax: 0191 224 4938

Email: tech@videxuk.com

Web: www.videxuk.com

SERIES

3000

3117

3000 Series Audiophone

QUICK GUIDE

ART. 3117

3000 Series full base "4+1" and intercommunication audiophone

incorporating an adjustable electronic call tone, "door open" push button

and 4 additional buttons for intercommunicating.

For use on intercommunicating systems or traditional "4+1" audio

systems that require an electronic call tone including the following audio

kits: traditional VR audio systems, 4K series, 8K series, VR4K series and

VR120DK series kits.

Call tone adjustment: 3 level (low, medium and high) call tone switch.

Additional buttons: 4 intercommunicating call buttons (numbered 1 - 4).

QG_3117_V.1.0_03/17

Door Open button Handset speaker

Handset

microphone

Audiophone

Handset

Handset cord

Front cover

retaining

screw

OVERVIEW

Intercommunicating call

buttons

3 level (low,

medium and high)

call tone volume

adjustment

All manuals and user guides at all-guides.com

all-guides.com

ANSWERING A CALL (FROM THE OUT DOOR STATION)

TO OPEN THE DOOR

To answer an incoming call

pick up the handset.

With the handset lifted a

conversation with the caller

can begin.

To end the call replace the

handset back on the cradle.

During a conversation, with the handset lifted, press the lock

button to operate the lock.

To end the call replace the

handset back on the cradle.

During a

conversation

CALL TONE VOLUME ADJUSTMENT

In every situation

Move the volume switch to the lower

position to set the call tone volume

to low, to the middle position to set

the call tone volume to medium and

to the upper position to set the call

tone volume to high.

12 3

TECHNICAL ADVICE

For further technical advice and assistance on the

installation of this product please contact Videx technical on

tel: 0191 224 3174.

For any sales advice and assistance please contact Videx

sales on tel: 0191 238 8324.

To download a copy of this quick guide visit the Videx

website: www.videxuk.com

During a call

MAKING AN INTERCOMMUNICATING CALL (BETWEEN AUDIOPHONES)

In standby

Pick up the handset. Press the call

button (1 - 4) for the required phone

to be called.

When the phone which is called

rings, it can be answered and a 2 way

conversation between the caller and

receiver can begin.

To end the call/conversation

between the phones replace the

handsets back on the cradle.

12 3
