028-5010-08_LIT-R810-E06-EN Oct-20 4
Important Notice:
These instruments have undergone rigorous tests
and verifications prior to shipment to ensure proper
and reliable operation in the field. However, like
other such products, they are subject to failure. It is
therefore the responsibility of the installer / user /
electrical panel designer to incorporate safety
features and devices ( such as relays, flow switch,
thermal protections, etc.. ) to protect the entire
system from catastrophic failure.
Specifications
Drawing and Dimensions
R810 Heatsink Length Shipping Weight (lbs)
California Proposition 65
CALIFORNIA PROPOSITION 65
This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Failure to follow these instructions can result in birth defects or other reproductive harm.
Viconics Technologies Inc.
7262 Marconi | Montreal | Quebec | Canada | H2R 2Z5
Tel.: 514.313.8885 | Toll free: 1 800.563.5660
Operating Conditions:
0°C to 80°C ( 32°F to 176°F )
0 % to 95 % R.H. non-condensing
See power derating curves document
Power supply:
4-32 Vdc time proportioning signal into 2K
Ω
