Step Four.
01 This step requires two adults. Lift the
table clean o the ground, turn it
around so the legs point down, then
place it down on the oor. Do not
lean it on its legs as this can damage
them. Now the table is ready, it’s time
to play!
Please do view our assembly guide video
on YouTube whilst you set up the table.
It’s sure to help make the process clearer.
https://youtu.be/Ivm-kA5VwoA
Step Three.
01 Attach legs 2A and 2B to the main
frame using handle bolt (#7), a bolt
(#8) and two washers (#10) for each
leg. The horizontal part of the legs
should point towards the outside of
the table, with the metal studs facing
the inside. Attach the leg using the two
innermost holes, leaving the third one
closest to the end of the table free. As
before, only screw the bolts in loosely.
02 Attach the two remaining leg panels
(#4 & #5) to the legs using the bolts
(#9), washers (#11) and nuts (#6) as
before. The thicker leg panel (#4)
goes on the vertical part of the legs,
closest to the table, with the logo
upside down and facing outwards.
The thinner leg panel (#5) goes on
the horizontal part of the legs, further
away from the table, with the logo
facing downwards and on the outside
edge. Screw all bolts in loosely.
03 Once all the panels are in place,
tighten all the bolts (#8 & #9) with the
Allen key and the handle bolts (#7)
with your hands.
