VEVOR GY-120 User manual
1
Important
1. Please read this manual carefully before using this product, and retain the instructions
for future reference.
2. Do not immerse in water or other liquid, nor 4rinse by dragon water directly.
Warning
1. Before connecting the power, please check the power supply voltage is equal to the
supply voltage which marked on the product or not.
2. This product is not intended for use by those persons (including children):
Deterioration of the body function or mental ability, or lack of experience and
knowledge. They need someone to supervise, or to instruct the operation before use.
3. When the machine is running, do not close, to avoid danger.
Security and maintenance
1、The voltage could be 110V or 220V, Please adjust the Shrapnel to to the appropriate
location before using.
2、This product with the plug wire is three core wires, one of which is the ground wire, so
please make sure the socket have ground wire to avoid electric shock.
The ways of cleaning
1、When cleaning, please turn off the power and pull the plug.
2、After use, please clean and wipe the body immediately.
GY-120
Model
GY-120
Size
350*300*355MM
Voltage
220Vor110V
Power
120W
Net weight
25kg
Timer
1-120S
Size of shaker cup
350-750ml
2
二、GY-1 20 Operating Instructions
A：Adjust the shrapnel to a appropriate location by usingM6
L-typehex wrench (The cup put on the cup holder, then push
the cup (with the cap) forward, if the shrapnel can press the
cup tightly, then the shrapnel is at the appropriate location)
A: When place the cup, place the cup bottom aligned the
cupholder
B：Push the cup (with the cap) forward
2、启动和停止 Start and stop
Adjustment and placed the cup
Emergency switch
Timer
1. After turning on the power supply, the power light is on, and the time indicator shows the
stop time. (Factory default 15 seconds)
2. Put the cup (with liquid and cover the lid) on the cup holder, push the cup toward the
machine.
3. The machine start working after pressing the start button, and it will stop when counting
down to 000. Please press the start button once again if you want to stop the machine
during working.
Press (aaa) button to set the stop time, time setting range 1-120 s.
Please keep the emergency switch OFF in the normal
working conditions.
Warning: Please check the emergency switch for the first time. The emergency switch
should be OFF, (If the machine start working after turning on the power supply, please
turn off the emergency switch)
Note: please check the emergency switch for the first use of the machine. The emergency
switch should be in the OFF state.(if the machine starts to work when it is on the power
supply, please turn off the emergency switch).
Fault Analysis and Treatment
Cases
Cause of issue
Check the
contents
Approach
After pressed the
start button, the
machine did not
work
Power problems
Check the power
Replacing the
power outlet
Plug and socket
connection is bad
Check the plug is
loose or not
Replace the plug
wire or socket
After pressed the
start button, the
timer lights but the
machine did not
work
The wiring was
loose inside the
machine
Open the
machine rear
plate to check the
wiring.
Reconnect the
loose wire
The belts was loose
Open the machine
rear plate to
check die wiring.
Tighten the belt or
replace the belt
After pressed the
start button, the
machine work but
can not stop
working.
The Timer is bad
Timer
Replace the Timer
Machine working
noise
Machine was put
instability
Check whether
the table and the
machine is flat
Replace the table
Shrapnel loose
Shrapnel should
be in close contact
with the cup
Adjust the
shrapnel
Cup was thrown
off
Shrapnel loose
Check the
shrapnel.
Tighten or
replace the
shrapnel
