Vestfrost VLS 054 SDD User manual

CORPORATEPRESENTATION

Instructions

VLS054SDDCorrectiveandPreventiveService

VestfrostSolutions

CORPORATEPRESENTATION

Warning!

Before any repair jobbe aware offollowing!

WARNING:

Beforeservicingorcleaningtheappliance,disconnectitfrom

powersource.

WARNING:

Dangerriskoffireorexplosion.Flammablerefrigerantused.

Toberepairedonlybytrainedpersonnel.

(R600a)

CORPORATEPRESENTATION

Repair andpreventive actioninthefield

1. Thermostat repositioning

2. Sealing ofcable guide– rubbergrommet

Use below order when performing theserviceupgrade

After servicehasbeen completet,make suretheappliance iscleaned

inside thevaccinecompartment andoutside.

CORPORATEPRESENTATION

ThermostatRepositioining

Howtoget accestothe

motorcompartment.

Use ascrewdriver to

remowe grill

Unluck all4clamps

Pull thecompressor grill

CORPORATEPRESENTATION

ThermostatRepositioining

Thethermostat isplaced intheleft

corner ofthecompressor

compartment ontheterminal

bracket

Top

Side

Back

Front/Screen

CORPORATEPRESENTATION

ThermostatRepositioining

1:Dismount 5wires

fromECU

2:Loosen 4screws for

thermostat/fanbracket

Use anose plier

tograbthewire

socket andgently

pull

Use theflexible

socket wrench

size 7mm

CORPORATEPRESENTATION

ThermostatRepositioining

3:Gently pull out

thethermostat

bracket,bytilting

outfrombottom

4:Pushclip onleft and

rightsideandpull out

thermostat

CORPORATEPRESENTATION

ThermostatRepositioining

5:Unplugconnector

fortemperature

probe

6:Use asmall

screwdriver toloosen

ONLY redandblack

powercables from

thermostat socket.

6:Bend thebracket

forthermostat to

theright

CORPORATEPRESENTATION

ThermostatRepositioining

7:Use theblack +

redwireandthe

plug &play cable

joint,inorder to

extend thepower

wires

8:Opencable

jointsocketand

connectred

wiretored

extensionand

blackwireto

blackextension.

CORPORATEPRESENTATION

ThermostatRepositioining

9:Exchangethe

wires2xpurple

wiresandthe2x

black sensorwires

incl.socket 1/1to

newthermostat

10:Enterthewires

into the

thermometer

bracket

11:Place

thermostat in

bracket slot
