VeriFone T650p User manual

T650p

Quick Start

Guide

Getting started

You can also power your terminal

o󰀨 and on using the power button

on the side of the terminal.

Terminal will power up

Your terminal will

start up and load the

payment screen.

TIP

Get connected

If your terminal connects to the internet via mobile data with

a SIM card, you can start processing transactions. If not,

you will need to connect via Wi-Fi or your internet router.

SET UP YOUR PASSCODES

For your security, the refund functionality on your

T650p is protected by passcodes. To set up your

passcodes, call our Technical Helpdesk on 0800

EFTPOS (0800 338 767, option 2).

NOTE: You must be the listed authority on your

Eftpos NZ account to set up passcodes.

T650p Charging Only Base (for Wi-Fi and mobile terminals)

Set up base

Your new Verifone T650p terminal comes with either a charging only base for mobile / Wi-Fi

terminals OR a full feature base with Ethernet connectivity.

T650p Full Feature Base

Connect to the internet

Via Wi-Fi

Plug one end of the Ethernet cable provided into the port labelled with the icon on your T650p

Full Feature base. Plug the other end of the Ethernet cable into a free LAN port on your router.

11.30 AM

Connect to Wi-Fi

Swipe down from the

notication bar at the top

if the screen and tap and

hold the Wi-Fi icon.

Find your network

Select your network from

the available networks list.

11.30AM

Enter your password

Enter your Wi-Fi

password and tap

‘CONNECT’. Press the

HOME BUTTON

to navigate back to the

Payment screen.

Via your internet router

If your terminal is set up for Ethernet connection, it will automatically connect to the base via Bluetooth.

Once your base is connected to your router, the terminal doesn’t have to be on the base to take payment.

TIP

11.30AM

Process a transaction

Your customer taps, inserts, or

swipes their card or mobile wallet

and enters their PIN if prompted

3 4

Customer selects how they would like

to receive their receipt. Learn more:

eftpos.co.nz/android-receipts

Enter the purchase

amount and tap Purchase.

TIP: You can tap on the icon to add

a reference to the transaction

Terminal will display

Approved or Declined

Discover solutions that will enhance your customer

experience, reduce costs, and help you run your business.

eftpos.co.nz/value

VALUE ADDS

Get to know your T650p

Card swipe

Card insert

Paper roll cover

USB-C charging port

Headphone jack

Contactless card

reading area

Notication bar

Volume buttons

Power / Accessibility

mode button

Navigation keys

To wake the T650p

Press Power button

To save power, your T650p goes into sleep mode when you are not using it.

Wake the T650p

The Notication bar at the top of the screen displays status icons on the right side and notication

alerts on the left. Swipe down from the Notication bar to see notication cards and the Quick Settings

panel.

STATUS ICONS

Bluetooth

connected to base

Aeroplane mode

Cellular signal

Wi-Fi

SIM card

Battery level

Battery charging

NAVIGATION KEYS

Recent items

Payment screen

Back

More options

Expand

Collapse

Add reference

NOTIFICATION ICONS

Warning / attention

Important information

Download / update

in-progress

QUICK SETTINGS ICONS

App launcher

Torch

Auto rotate

Edit

Settings

Icons on the T650p

Changing the paper roll

Remove used paper roll. Insert

new roll so the paper feeds from

the top, leaving a length of paper

sticking out of the terminal

Open paper roll cover as

shown above. There are small

slots to aid opening if required

Close the printer door,

pressing down gently until

it clicks shut

Order more paper

rolls online at

eftpos.co.nz/t650p-paper

Charging the T650p

Using a Base

• Make sure the power supply is connected to the T650p base and plugged in (see page 1)

• Place the T650p on the base

• Look for this icon to make sure your T650p is charging

Using the USB Adapter

• Insert USB cable into USB adapter

• Insert USB adapter into wall socket

• Insert USB-C end into the USB-C charging port on the left side of the terminal

• Look for this icon to make sure your T650p is charging

NEED HELP?

Get step-by-step instructions for using your new terminal at

support.eftpos.co.nz/android-user-guide
