VeriFone VX 520 Series User manual

Verifone Vx520

Terminal Setup Guide

8/5/2019

In the Box

The Verifone VX 520 terminal comes with a power adapter, phone cable, and a roll of thermal paper.

Connecting the Terminal

Before anything else, connect the VX 520 via ethernet (LAN) or phone line. The terminal requires either

an internet or phone connection to be able to run transactions and communicate with the processor.

1. Remove the cover from the bottom of the terminal.

2. Connect an ethernet cable to the ETH port and / or a phone line to the telephone port.

3. Plug the other end of the ethernet cable into an open port on the router / modem. If you are

using a telephone line, connect the other end of the phone cable to a wall jack preferably not

shared with another device.

4. Connect the power cord to the round port.

5. Plug the power adapter into a power outlet. This will turn the terminal on automatically.

6. Replace the terminal’s back cover.

7. When the terminal displays COMMSERVER and SOFTPAY-FDMS press the F3 button to get to the

main menu.

Load the Paper

1. Lift the latch to open the printer cover.

2. Drop the paper into the tray with the leading edge feeding down from the bottom of the

roll.

3. Close the cover on the paper and be sure to have some sticking out from under the cover.

Your terminal is now ready to take transactions.
