Vauxhall 2012 Agila User manual

AGILA

©Copyright by Vauxhall Motors Ltd., England.

Reproduction or translation, in whole or in parts, is not

permitted without prior written consent from Vauxhall Motors

Ltd.

All rights as understood under the copyright laws are explicitly

reserved by Vauxhall Motors Ltd.

All information, illustrations and specifications contained in this

manual are based on the latest production information

available at the time of publication.

The right is reserved to make changes at any time without

notice.

Edition: July 2006.

TS 1525-A-07

AGILA

Operation, Safety and Maintenance

Owner’s Manual

TS1649-A-07.qxd 15/06/2006 07:10 Page 1

VAUXHALL Agila

Owner’s Manual

Data specific to your vehicle

Please enter your vehicle’s data here to keep it easily accessible.

Thisinformation is available under the section "Technical data" as well as on the vehicleidentification plate and in the Service Booklet.

Fuel

Designation

Engine oil

Grade

Viscosity

Tyre pressure

Tyre size Tyre pressure 3persons with full load

Summer tyres Front Rear Front Rear

Winter tyres Front Rear Front Rear

Weights

Permissible Gross VehicleWeight

– ECkerbweight

=Loading

Your Agila

Developed in accordance with thelatest findings of vehicle research, it offers technical sophistication and exceptional comfort.

Your vehiclerepresents an intelligent synthesis of advanced technology, outstanding safety, environmental compatibility and

economy in operation.

It now lies with you to drive your vehicle safely and to see it performs perfectly.

ThisOwner’sManual provides you with all the necessary information to that end.

Make sure your passengersare aware of the possible risk of accident and injury which may result from improper use of the vehicle.

TheOwner’sManual should always be kept in the vehicle: ready to hand in the glove compartment.

Make use of the Owner’s Manual:

zIts"In brief" section will give you an initial overview.

zThe table ofcontentsatthe beginning ofthis owner’s manual

and within the individual chapterswill show you where everything is.

zItsindex will help you find what you want.

zIt will familiariseyou with the sophisticated technology.

zIt will increase your pleasurein your vehicle.

zIt will help you to handleyour vehicle expertly.

The Owner’sManual is designed to be clearly laid-out and easily understood.

This symbol signifies:

6Continue readingon next page.

3The asterisk signifies: equipment not fitted to all vehicles

(model variants, engine options, models specific to one country, optional equipment,Genuine Vauxhall Parts and Accessories).

Yellow arrows in the illustrations serve as points of reference or indicatesome action to be performed.

Black arrowsin the illustrations indicate a reaction or a second action to be performed.

Thank you for choosing a Vauxhall. Wewish you many hours of pleasurable driving.

Your Vauxhall Team

9Warning

Text m arked 9Warning provides information on risk of accident or injury.Disregard of the

instructions may lead to injuries or endanger life.

Inform your passengers accordingly.

Contents Commitment tocustomer

satisfaction:

Our aim: to keep you happy with your

vehicle. All Vauxhall Authorised Repairers

offer first class service at competitive

prices. Experienced, factory-trained

technicianswork according to factory

instructions.Your Authorised Repairer can

supply you with GENUINE VAUXHALL-

APPROVED PARTS, whichhave undergone

stringent qualityand precision checks, and

of course usefulandattractive

VAUXHALL-APPROVED ACCESSORIES.

Our nameisyour guarantee!

For details of the

Vauxhall Authorised Repairer Network

pleaseringthis number; 01582 - 427200

In Brief ........................................................ 2

Instruments ............................................. 18

Keys, Doors, Bonnet ............................... 28

Seats, Interior .......................................... 39

Safety systems ........................................ 50

Lighting ................................................... 66

Windows, Sun roof ................................. 69

Climate control ....................................... 72

Driving Hints ........................................... 82

Savingfuel,

Protecting the environment ............... 84

Fuel consumption,

Fuel, Refuelling ................................... 86

Catalytic converter, Exhaust gases ...... 88

Brakes ...................................................... 92

Wheels, Tyres .......................................... 96

Roof racks,

Caravan and trailer towing ............ 102

Self-help ................................................ 106

If you have a problem .......................... 128

Maintenance,

Inspection System ............................. 130

Vehicle care .......................................... 140

Technical Data ..................................... 144

Index ...................................................... 158

2InBrief

In Brief Key numbers,

Codenumbers

Remove key number from keys.

The keynumber is specified in the vehicle

documents and in theCar Pass 3.

Alloy wheels 3: make a note of the key

identifier code.

Electronic immobiliser, infotainment

system 3: The code numbers are specified

in the Car Pass.

Donotkeepthe CarPass inthe vehicle.

6 Further information – pages 28, 29,

vehicle recommissioning – page 139. Picture no:14088h.tif

To unlock the vehicle and

open the doors:

With key in lock

turn key towards front of

vehicleor

pressbutton con the remote

control 3,

pull door handle and open door

Radio remote control 3: Press button c

once - only driver’sdoor is unlocked; press

button ctwice - all doors are unlocked.

To unlockthe doors from inside:

Pull up on lock button.

6 Door locks – page 30,

electronic immobilizer – page 29,

radio remote control 3– page 31,

central locking system 3 – page 33,

anti-theft locking system 3– page 33.

3In Brief

Picture no: 13471h.tif

To unlock and open

theluggagecompartment:

Turn the key anticlockwise to

horizontal position and back

to the vertical position

Alternativelypress button conthe remote

control 3twice,press button andopen

tailgate

6Mechanical unlocking – page 30,

radio remotecontrol 3 – page 31,

central locking system 3 – page 33,

tailgate – page 30.

Picture no: 13457h.tif

Front seatadjustment:

Pull handle,

slide seat,

release handle,

audiblyengageseat in position

Never adjust theseat whiledriving.It could

move in anuncontrolled manner when the

handle is pulled.

6 Seat position – page 39,

storage tray under seat 3– page 46.

Picture no:13458h.tif

To adjust the front seat

backrest:

Turn the handwheel

Moveseatbackrestto suitseatingposition.

Do not lean on seat backrest whilst

adjusting it.

6Seat position – page 39,

folding the front passenger seat – page 42.

9Warning

Donotsit nearer than 10 inches (25 cm)

from the steering wheel, to permit safe

airbag deployment.

4InBrief

Picture no: 13459h.tif

To adjust height 3

of front seat:

Pull lever on side

Lift leverand relievesomeweight from seat

to raise it or press down on seat with body

weight to lower it.

Neveradjustthe seatwhile driving. It could

move in an uncontrolled manner when the

handle is pulled.

6Seat position – page 39.

Picture no: 15137h.tif

To adjust the height of

front seathead restraints:

Tiltforward to unlock, hold firmly

and adjust height, release

6 adjusting

rear seat head restraints – page 40,

head restraint position – page 39,

head restraint removal – page 39.

Picture no:12246h.tif

Adjusting interior mirror:

Swivel mirror housing

Swivel lever on underside ofmirror housing

to reducedazzle at night.

9Warning

Do not sit nearer than 10inches(25 cm)

from the steering wheel, to permitsafe

airbag deployment.

5In Brief

Picture no: 12247h.tif

To adjust exterior mirrors:

Manually - press

edge of relevant

mirror;

Electrically 3- using four-way

switch indriver’s door

Four-way switch 3: Move rocker switch to

the left or right - thefour-way switch

adjusts the corresponding mirror.

Theexterior mirrors can be retracted (e.g.

when parking in tight spaces) through

slight pressure on the mirror housing.

Reposition the mirrors before starting off.

6Further information – page 65.

Picture no: 13461h.tif

Fitting seat belt:

Draw seat belt smoothly from

inertia reel, guide over shoulder

and engage in buckle

The belt must not betwisted at any point.

The lap belt must lie snuglyagainst the

body. Thebackrestmust not be tilted back

too far (recommended tilting angle

approx. 25 °).

To release belt, press red button on belt

buckle.

6 Seat belts – pages 50, 52,

airbag systems 3– page 56,

seat position – page 39.

Picture no:15678t.tif

Disengaging steering column

lock:

To release the lock,

move the steering wheel slightly

and turn the key to position 1

Positions:

0 = Ignition off

1 = Steering released,ignition off

2 = Ignition on,

Starting – page 15,

electronic immobiliser – page 29.

Remove key and lock steering wheel –

page16.
