！！！WARNING！！！
1. Failure to follow all manufacturers’ instructions could result in serious body injury
and/or property damage.
2. Some parts of this grill may have sharp edges—especially as mentioned in this
manual! Wear suitable protective gloves if necessary.
3. Only to be used outdoors.
4. Read the instructions before using the appliance.
5. Warning: accessible parts may be very hot. Keep young children away.
6. Do not move the appliance during use.
7. Turn off the gas supply at the gas container after use.
8. Any modification of the appliance may be dangerous.
9. Never mount the cylinder under the BBQ on the base shelf as this will result in
serious injury to the user.
10.If the ground temperature is above 50K, the surface needs protection.
TECHNICAL DATA
Total heat input: 17.2 kW (main burner: 14.0 kW + side burner: 3.2 kW)
Gas consumption: 1252 g/h (main burners: 1019 g/h + side burner: 233 g/h)
Gas bottle: standard cylinder.
Make sure the gas cylinder is lower than the gas connection/gas inlet
Always place gas cylinder/bottle on a flat level surface DO NOT fix on trolley. Care should be taken so the gas
hose and gas cylinder do not come in contact with hot surfaces or sharp edges, and should not pass under the
barbecue
Pressure reducer: comply with EN16129 (Flow rate: max. 2.0 kg/h)
Gas hose: comply with EN standard or local market standard (max. 1.5m, max. FI 1.2m)
Gas system information:
Gas Category Category I3+ (28~30/37) Category I3B/P(30) Category I3B/P(37) Category I3B/P(50)
Gas Type Butane at (28~30)
mbar/ Propane at 37
mbar;
G30(Butane),G31
(Propane) or their
mixtures at
(28~30) mbar
G30(Butane),G31(
Propane) or their
mixtures at 37
mbar
G30(Butane),G31
(Propane) or their
mixtures at 50
mbar
Injector Size (Dia.
mm) Grill burner: 0.91
Hotplate burner: 0.86
Grill burner: 0.91
Hotplate burner:
0.86
Grill burner: 0.87
Hotplate burner:
0.81
Grill burner: 0.80
Hotplate burner:
0.76
Destination of
Countries
BE, FR, IT, LU, LV,
IE, GB, GR, PT, ES,
CY,
CZ, LT, SK, CH, SI
LU, NL, DK, FI,
SE, CY, CZ, EE,
LT, LV, MT,
SK, SI, BG, IS,
NO, TR, HR, RO,
IT, HU
PL AT, DE, SK, CH,
LU
This appliance has been made with regard to the European Gas Appliance Standard EN498 and EN484 and
bears the CE certification
Which gas category or gas type will be used, please check the detail information on the appliance.
