Valor 1400MN User manual

WARNING:

FIRE OR EXPLOSION HAZARD

Failure to follow safety warnings

exactly could result in serious

injury, death, or property damage.

Do not store or use gasoline or other

ﬂammable vapors and liquids in the

vicinity of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS

▪Do not try to light any appliance.

▪Do not touch any electrical switch; do

not use any phone in your building.

▪Leave the building immediately.

▪Immediately call your gas supplier from

a neighbor’s phone. Follow the gas

supplier’s instructions.

▪If you cannot reach your gas supplier,

call the ﬁre department.

Installation and service must be

performed by a qualiﬁed installer, service

agency or the gas supplier.

Hot glass

will cause burns.

Do not touch glass

until cooled.

Never allow children

to touch glass.

A barrier designed to reduce

the risk of burns from the hot

viewing glass is provided with this

appliance and must be installed for

the protection of children and

other at-risk individuals.

DANGER

4009372-01

Homeowner’s Manual

Direct Vent Gas Fireplaces

natural gas 1400MN

propane gas 1400MP

The information contained in this manual is believed

to be correct at the time of printing. Miles Industries

Ltd. reserves the right to change or modify any

information or speciﬁcations without notice. Miles

Industries Ltd. grants no warranty, implied or stated,

for the installation or maintenance of your heater,

and assumes no responsibility for any consequential

damage(s).

Designed and manufactured for Miles Industries Ltd.

Valor Fireplaces

190–2255 Dollarton Highway

North Vancouver, BC, Canada V7H 3B1

T 604.984.3496 F 604.984.0246

valorﬁreplaces.com

This appliance may be installed in an

after-market permanently located,

manufactured (mobile) home where

not prohibited by local codes. This

appliance is only for use with the type

of gas indicated on the rating plate.

This appliance is not convertible for

use with other gases, unless a certiﬁed

kit is used.

INSTALLER: Leave this manual with the

appliance.

CONSUMER: Retain this manual for

future reference.

Massachusetts:

The piping and ﬁnal gas connection must be

performed by a licensed plumber or gas ﬁtter

in the State of Massachusetts. Also, see Carbon

Monoxide Detector requirements in the ﬁreplace

installation manual.

WARNING

This product can expose you to chemicals including Benzene,

which is known to the State of California to cause cancer and

birth defects or other reproductive harm.

For more information go to www.P65Warnings.ca.gov.

Note: Natural gas, in its original state, contains Benzene.

Homeowner: Please read this manual before

operating this appliance, and save for future

reference.

Thank you for purchasing a Valor Fireplace.We

appreciate your business and wish you many happy

years enjoying your new ﬁreplace.

Your new radiant gas heater is a technical appliance

that must be installed by a qualiﬁed dealer. Each

Valor®ﬁreplace is fully tested during the production

process for your safety and comfort.

Your unit has been professionally installed by:

Dealer Name: ___________________________________

Phone: _________________________________________

If you experience any problems, call your dealer

immediately. To avoid injury or damage to your

ﬁreplace, do not try to repair the unit yourself.

Your valor ﬁreplace

Here are some important details about your Valor

ﬁreplace, should you need to contact your dealer.

Model: _________________________________________

Serial: __________________________________________

Options: ________________________________________

________________________________________________

Please ask your installer for these details if they are

not already provided, or see page 7.

Welcome to Valor®

Contents

Safety and your ﬁreplace ..........................................4

Child safety and your ﬁreplace................................. 6

Getting started............................................................7

First time operation...................................................... 7

Locating ﬁreplace and lighting information ............. 7

Parts of your ﬁreplace................................................ 8

Operating your ﬁreplace ...........................................9

Fireplace control devices............................................. 9

Preventing inadvertent ignition ...............................10

Replacing batteries................................................... 11

Replacing light bulbs ................................................12

Annual service and maintenance........................... 13

Cleaning your ﬁreplace ............................................14

Remove Window......................................................... 14

Reinstall and check window......................................16

Checking pilot and burner ﬂames.......................... 18

Frequently asked questions....................................19

Valor®warranty.........................................................21

Valor®outdoor installation warranty....................22

Appendix A—Remote control operation ..............23

Appendix B—Wall switch operation ......................30

Important—Register your warranty

Registration of your Valor is highly

recommended, and can be completed by

scanning the QR code on the serial number

label placed on the ﬁreplace's installation

manual cover by the installer or by visiting

valorﬁreplaces.com/warranty.

Completing your registration enables us to

properly address any warranty or service-related

concerns that you may have. This information

is strictly for customer service and warranty

purposes, and will never be shared with any third

party.

This manual contains very important information about the safe operation and maintenance of your ﬁreplace.

Read and understand all instructions carefully before operating your ﬁreplace. Failure to follow these

instructions may result in possible ﬁre hazard and will void the warranty.

Replacement manuals are available by contacting Valor Customer Service at 1-800-468-2567, or by visiting

valorﬁreplaces.com.

Safety and your fireplace

Do not put

furniture or other objects

in this space in front of

WKHȴUHSODFH

36” [0.9 m]

)LUHSODFH

Hearth

Do not put

furniture or other objects

in this space in front of

the replace:

36” (0.9 m)

Fireplace

Hearth

WARNING: Extremely Hot!

Heat and ﬂammability

• Some parts of your ﬁreplace are extremely hot, par-

ticularly the glass window. Use the provided barrier

screen and a gate to reduce the risk of severe burns.

• The glass windows can exceed temperatures of

500°F at full capacity.

• Always keep the appliance clear and free from com-

bustible materials, gasoline, and other ﬂammable

vapors and liquids.

• Be aware of hot wall surfaces. The wall directly above

the ﬁreplace can get very hot when the ﬁreplace

heats. Although safe, it may reach temperatures in

excess of 200ºF depending on choice of trims or

optional accessories. Do not touch!

• Be aware of hot surfaces in front of the ﬁreplace

windows. A shelf directly in front of the ﬁreplace can

get very hot when the ﬁreplace heats. Although safe,

they may reach temperatures in excess of 200ºF

depending on elevation of the shelf. Do not place

anything on it.

• Some materials or items, although safe, may dis-

color, shrink, warp, crack, or peel due to the heat

produced by the ﬁreplace. Avoid placing candles,

paintings, photos and other combustible objects

sensitive to heat or furniture within 36 inches (0.9m)

around the ﬁreplace.

• Solid wood ﬂooring in front of the ﬁreplace (if al-

lowed) may shrink during the heating season due

to heat.

• Due to its high temperature, the appliance should be

located away from high-traﬃc areas, furniture, and

draperies.

• Clothing or ﬂammable material should not be placed

on or near the appliance.

Barrier screen and safety

• A barrier designed to reduce the risk of burns from

the hot viewing glass is provided with this appliance

and shall be installed for the protection of children

and other at-risk individuals.

• Children and adults should be alerted to the hazards

of high surface temperature and should stay away to

avoid burns or clothing ignition.

• Young children should be carefully supervised when

they are in the same room as the appliance. Tod-

dlers, young children, and others may be suscep-

tible to accidental contact burns. A physical barrier

is recommended if there are at-risk individuals in

the house. To restrict access to a ﬁreplace or stove,

install an adjustable safety gate to keep toddlers,

young children, and other at-risk individuals out of

the room and away from hot surfaces.

• Any safety screen, guard, or barrier removed for ser-

vicing an appliance must be replaced prior to operat-

ing the appliance.

Safety and your fireplace

Front outlet

WARNING

Optional HeatShift

System:

Do not cover or

place items in

front of outlet!

Top outlet

Sides outlets

Glass window

• The glass window fronts must be in place and sealed

before the unit can be placed into safe operation.

• The glass fronts must only be replaced as complete

units, as supplied by the ﬁreplace manufacturer. No

substitute material may be used.

• Do not use abrasive cleaners on the glass front as-

sembly. Do not attempt to clean the glass front when

it is hot.

Venting

• This unit must be used with a vent system as de-

scribed in the installation manual. No other vent

system or components may be used.

• Never obstruct the ﬂow of combustion and venti-

lation air. Keep the front of the appliance clear of

all obstructions for optimal operation and ease of

servicing.

• This unit must be vented directly outside and must

never be attached to a chimney serving a separate

solid fuel burning appliance. Each gas appliance

must use a separate vent system. Common vent

systems are prohibited.

Intended use

• This appliance is designed and approved as a supple-

mental heater to be used while attended. The use of

an alternate primary heat source is advisable.

• This unit is not for use with solid fuel.

• Do not use this heater as a temporary source of heat

during construction.

WARNING

Do not operate this appliance with the

glass front removed, cracked, or broken.

Do not strike or slam the glass front.

Replacement of the glass front should

be performed by a licensed or qualiﬁed

service person.

Initial and annual inspection

• Installation and repair should be performed by

a qualiﬁed service person. The appliance should

be inspected before use and at least annually by a

professional service person. More frequent clean-

ing might be required due to excessive lint from

carpeting, bedding material, etc. It is imperative that

control compartments, burners, and circultaing air

passageways of the appliance be kept clean.

• Do not use this appliance if any part has been under

water. Immediately call a qualiﬁed service technician

to inspect the appliance and to replace any part of

the control system and any gas control that has been

under water.

Maintenance

• Keep the unit’s control compartment, burner, and

circulating air passageways clean to enable adequate

combustion and ventilation air.

• Inspect the external vent cap on a regular basis to

ensure that no debris, plants, trees, or shrubs are

interfering with air ﬂow.

A heating gas appliance does require safe handling. For this reason, we very strongly recommend children not be

allowed to touch the ﬁreplace or its controls.

Read and carefully follow all safety warnings and operating instructions contained in this manual, and follow

these important child safety precautions and recommendations:

• Parts of your Valor Fireplace become extremely

hot while in operation. The glass window tempera-

ture can exceed 500º F at full capacity.

• Do not let children touch the glass or any parts

of your ﬁreplace even after it is turned oﬀ, as the

surfaces will remain hot for some time.

• Even momentary contact with a hot glass surface

can cause a severe burn, including when the ﬁre-

place is operating at reduced heating capacity.

• The glass window will remain hot for an extended

period of time after the ﬁreplace has been turned

oﬀ. Make sure that children do not touch the ﬁre-

place during the cool down period.

• Children and adults should be alerted to the haz-

ards of high surface temperature and should stay

away to avoid burns or clothing ignition.

• Young children should be carefully supervised

when they are in the same room as the appliance.

Toddlers, young children, and others may be sus-

ceptible to accidental contact burns.

A physical barrier is recommended if there are

at-risk individuals in the house. To restrict access

to a ﬁreplace or stove, install an adjustable safety

gate to keep toddlers, young children, and other

at-risk individuals out of the room and away from

hot surfaces.

• Keep the remote control handset out of reach of

children at all times. A child safety lockout feature

is included with your remote control, see Operating

your ﬁreplace on pages 9-10 for details.

• Make sure that the ﬁreplace, including the pilot

light, is completely turned oﬀwhen children are

present and close supervision is not available—see

pages 9 for details.

• If the ﬁreplace is not going to be used for an ex-

tended period of time, remove the batteries from

the remote control handset and battery holder un-

der the ﬁrebox. It is recommended that batteries

are replaced annually —see page 11 for details.

Child safety and your fireplace

Hot glass

will cause burns.

Do not touch glass

until cooled.

Never allow children

to touch glass.

A barrier designed to reduce

the risk of burns from the hot

viewing glass is provided with this

appliance and must be installed for

the protection of children and

other at-risk individuals.

DANGER

First time operation

When operating your new ﬁreplace for the ﬁrst time,

some vapors may be released due to the burning of

curing compounds used during manufacturing. They

may cause a slight odor and could cause the ﬂames

to be the full height of the ﬁrebox, or even slightly

higher, for the ﬁrst few hours of operation.

It is also possible that these vapors could set oﬀany

smoke detection alarms in the immediate vicinity.

These vapors are quite normal on new ﬁreplaces.

We recommend opening a window to vent the

room. After a few hours of use, the vapors will have

disappeared and the ﬂames will be at their normal

height.

Valor automatic gas shut-oﬀ

For your safety, Valor ﬁreplaces are ﬁtted with a

ﬂame supervision device which will shut-oﬀthe gas

supply if, for any reason, the pilot ﬂame goes out.

This device incorporates a ﬁxed probe, which senses

the heat from the pilot ﬂame. If the probe is cool,

the device will prevent any gas ﬂow unless manually

lighting the pilot. See the full Fireplace and Lighting

Information card attached to the ﬁreplace or as

reproduced in Appendix A of the Installation Manual.

Locating ﬁreplace and lighting information

The Fireplace and Lighting Information is located on a

card, behind the removable panel, at the right below

the window.

To access the card, remove the barrier screen,

both side doors and bottom removable panel. See

diagrams at right.

The card contains important information on both

sides of the card. It must be left with the ﬁreplace

when you are done.

Getting started

WARNING

Do not attempt to access the card while

the ﬁreplace is hot! Let the ﬁreplace cool

ﬁrst before touching it!

Fireplace

model

Serial

number

Parts of your fireplace

Here are the major components of your installed fireplace, with the protective barriers installed. Your

individual fireplace may appear differently depending on your installed options.

Barrier Screen

Window

Frame

Liner Panels

Side Doors

Fuel Bed

Burner Plaque

Trim

Window Frame

Window

Latch

Decorative Lighting

Info Card Here

Gas ValveReceiver Window Latches Handle

Window

Latch

Window

Latch

Window

Latch

Trim

Operating your fireplace

ON:

parallel

to pipe

OFF:

perpendicular

to pipe

Fireplace control devices

There are two ways to control your ﬁreplace.

1. Thermostatic Remote Control turns ﬁre and

lights ON and OFF, controls ﬂame height and can

be programmed to function automatically.

2. Wall Switch turns ﬁre ON and OFF, and controls

ﬂame height.

Turn your ﬁreplace ON

Press and hold:

- button on remote, or

- ON-OFF button on wall switch

until 8 short beeps conﬁrm the start sequence has

begun; release button.

The pilot lights up, followed by the ﬁreplace.

If you are using the handset, it displays a pilot ﬂame

symbol ( ) during the ignition sequence.

If you need to light up the pilot manually, see the

Fireplace and Lighting Information card attached to

the ﬁreplace - see page 7 to learn how to access it.

Also, a copy of this card is reproduced in Appendix A

of the Installation Manual.

Turn your ﬁreplace OFF (including pilot)

Press and hold:

- button on remote, or

- ON-OFF button on wall switch

If the ﬂames or pilot are on, they will go out and you

will hear the valve motor wind down. You will hear

a clunk and a beep indicating that the valve has

received the signal from the remote control.

In the unlikely event that you cannot turn oﬀyour

ﬁreplace with the remote control handset, use the

wall switch. If the wall switch malfunctions and

will not turn oﬀthe ﬁreplace, wait 3 hours and the

ﬁreplace will automatically go to pilot. You can then

access the controls inside your ﬁreplace, once it has

cooled.

Alternatively, you may turn oﬀthe house gas supply.

In all cases, call your dealer for service assistance.

To use additional functions of your Remote

Control such as temperature or program

settings, see Appendix A—Remote control

operation on page 28 of this manual or visit

valorﬁreplaces.com/remotes

WARNING

Risk of severe burns! Surface of the

ﬁreplace are very hot during operation!

Ensure ﬁreplace has cooled oﬀbefore

accessing control.

Remote Control Wall Switch

WARNING

STOP IF YOU SMELL GAS! DO NOT LIGHT!

See cover page immediately!

Operating your fireplace

Child prooﬁng your handset

Your remote control can be locked to prevent

operation by children.

To turn child prooﬁng ON:

1. Press and hold the and buttons

simultaneously.

2. is displayed on the handset screen making

the handset inoperable, with the exception of the

OFF function.

To turn child prooﬁng OFF:

1. Press and hold the and buttons

simultaneously.

2. disappears from the handset screen and the

handset is returned to full functionality.

Preventing inadvertent ignition

You can use one of the following two methods

to ensure that your ﬁreplace will not turn on

unexpectedly.

• On gas valve, turn dial from ON position to MAN

position as shown. Turning dial to MAN will ensures

that main burner cannot come on. The pilot will

remain on if lit.

• Alternately, remove all batteries from the battery

holder next to wall switch and the handset.

Automatic shut-oﬀ(in certain conditions)

Your ﬁreplace’s remote control is equipped with an

automatic shut-oﬀmechanism which is activated in

certain conditions. See Appendix A—Remote control

operation on pages 23-29 or go to valorﬁreplaces.

com/remotes for a description

of this feature.

Battery

holder

& wall

switch

Fireplace

Receiver Gas valve

Receiver and gas valve located on bottom of ﬁreplace

under removable panel. Battery holder located next to

wall switch.

Gas valve

This manual suits for next models

Table of contents

Other Valor Indoor Fireplace manuals

Valor

Valor PORTRAIT 530IN User manual

Valor

Valor 479MP User manual

Valor

Valor LEGEND 739JLN Logs Operating instructions

Valor

Valor Black Beauty Unigas II 473 User manual

Valor

Valor 1430FFK User manual

Valor

Valor 1500IN Operating instructions

Valor

Valor L1 Series User manual

Valor

Valor HORIZON 534XAN Installation instructions

Valor

Valor Legend 739ILN Manual

Valor

Valor Inspire 1000FS Instructions for use

Valor

Valor LX2 CORNER User manual

Valor

Valor Valorflame 450 User guide

Valor

Valor Vogue 1300IRN Manual

Valor

Valor 530SAN Installation instructions

Valor

Valor 500 PALERMO Assembly instructions

Valor

Valor L1 Series Operating instructions

Valor

Valor 530ILN Manual

Valor

Valor Retrofire RF24IDN Installation instructions

Valor

Valor LT2 Series User manual

Valor

Valor 719 Assembly instructions

Valor

Valor Legend G4 785XNGK User manual

Valor

Valor LINEAR SERIES User manual

Valor

Valor 739-72ILN Operating instructions

Valor

Valor 1440 User manual

Popular Indoor Fireplace manuals by other brands

Brigantia

Brigantia 35-DVRS31N-2 User's installation, operation and maintenance manual

Nordpeis

Nordpeis Bergen Installation and user manual

Superior

Superior BCT2536TMN Installation and operation instructions

Quadra-Fire

Quadra-Fire 5100I-GD-B owner's manual

Renaissance

Renaissance RUMFORD 1000 user manual

Lacunza

Lacunza IV-800 Instruction book

Baxi

Baxi 940 Installer and owner guide

Dru

Dru Maestro 60/2 Tall RCH installation manual

Diamond Fireglass

Diamond Fireglass SS-O22 General assembly, installation, and operation instructions

HearthStone

HearthStone Windsor Bay 8830 Owner's manual and installation guide

Napoleon

Napoleon ASCENT B42 quick start guide

Enviro

Enviro E33GI owner's manual

Smeg

Smeg L30 FABE Installation & user's instructions

KEDDY

KEDDY K700 Installation instructions care and firing instructions

Godin

Godin 3451 manual

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Installation and operation instructions

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 operating manual

Desa

Desa CCFPDFT Owner's operating & installation manual
