V-tech CareLine SN6166 User manual

CareLine™

w w w.v t e c h p h o n e s .c o m

User’s manual

Models:

SN6166/SN6167 BC

Congratulations

on purchasing your new VTech product. Before using this pendant,

please read Important safety instructions on pages 21-22 of

this manual.

This manual has all the feature operations necessary to install and

operate your new pendant. Please review this manual thoroughly to

ensure proper installation and operation of this innovative and feature

rich VTech product. For support, shopping, and everything new at

VTech, visit our website at www.vtechphones.com. In Canada, visit

www.vtechcanada.com.

Telephones identiﬁed with this logo have reduced noise and

interference when used with most T-coil equipped hearing aids and

cochlear implants. The TIA-1083 Compliant Logo is a trademark of the

Telecommunications Industry Association. Used under license.

Compatible with

Hearing Aid T-Coil

TIA-1083

Visit www.vtechphones.com.

Registration

Product news

Learn about the latest VTech products.

Parts checklist

Your package contains:

User’s manual•

Pendant charger with charger adapter•

Pendant belt clip•

Pendant with lanyard•

Pendant charger installation

Install the pendant charger as

shown below.

1. Switch on the pendant.2.

Place the pendant in the pendant charger to charge.3.

Pendant charger

power adapter

Electrical outlet not

controlled by a wall

switch

Turns red when charging.

Turns green when fully charged.

Pendant battery charging

The pendant status light indicates the battery status. If necessary, place

the pendant in the pendant charger to charge. For best performance,

keep the pendant in the pendant charger when not in use. The battery

is fully charged after three hours of continuous charging.

If the pendant status light ﬂashes red and you hear “Low battery,”

you need to charge the pendant without interruption to give it enough

charge to use for a short time. When the battery is low, the pendant

status light ﬂashes red. If you are on a call in low battery mode, the

pendant plays short beeps to alert you.

Battery indicators Battery status Action

The pendant status light

ﬂashes red.You hear “Low

battery” when there is only

30 minutes talk time left.

You hear an alert tone every

minute.

The battery has very

little charge.

Charge without

interruption.

The pendant status light is

solid red.

The battery has

enough charge to be

used for a short time.

Charge without

interruption.

Pendant attachment

Pendant lanyard:

The pendant lanyard is already attached to the pendant.You can

adjust the length of the lanyard for comfortable wearing, or remove the

necklace when necessary.

Pendant belt clip:

Remove the necklace of the pendant lanyard or the whole pendant

lanyard before you use the pendant belt clip.

Press down on the push

button slider to adjust the

length of the lanyard for

comfortable wearing.

Necklace

Press down the tabs on both

sides of the lanyard clip to

remove the necklace of the

lanyard.

Push the pendant into the belt clip until it clicks in place.

Add and register a pendant

When ﬁrst purchased, charge the pendant in the pendant charger.You

hear three beeps every 10 seconds when the pendant is not registered.

The new pendant should be charged without interruption for at least

30 minutes before registering it to the telephone base.

Make sure the pendant is out of the pendant charger and turned on.

To register a pendant to your SN1157/SN1197/SN6147/SN6197

telephone base:

Press MENU on the telephone base when idle.

Scroll to Settings, then press SELECT.

Scroll to Registration, then press SELECT.

The telephone base shows Registering...

Please wait.

Put the pendant in the pendant charger.

The pendant status light ﬂashes red and green to indicate the

registration is in progress. Then PENDANT Registered appears

on the telephone base, and both devices beep. The pendant is now

registered with the telephone base. It takes up to 60 seconds to

complete registration.

If you have already set the photo speed dial keys 1and 2, the

telephone base displays Copied Photo Speed Dial 1 to Pendant

Memory 1. Press NEXT, then the telephone base displays Copied

Photo Speed Dial 2 to Pendant Memory 2. Then press OK.

-OR-

If you have not set the photo speed dial keys 1and 2, see To

set photo speed dial in the SN1157/SN1197/SN6147/SN6197

Abridged user’s manual to set them.

If registration fails, the telephone base displays Registration failed and

you hear an error tone. Start again from Step 1 above.

Add and register a pendant

To register a pendant to your SN6127/SN6187 telephone base:

Press and hold /FIND HANDSET at the side of

the telephone base until the IN USE light turns

solid red.

Put the pendant in the pendant charger. The

pendant status light ﬂashes red and green to

indicate the registration is in progress. The pendant

beeps. Then it is registered with the telephone

base. It takes up to 60 seconds to complete

registration.

If registration fails, you hear an error tone.

Start again from Step 1 above.

Deregister all devices

If you want to replace a device, or reassign the designated handset

number of a registered handset, you must deregister all devices that are

registered to the telephone base. Then register each device individually.

To make deregistration easier, read all of the instructions on this and the

next page before you begin.

To deregister all devices from your SN1157/SN1197/SN6147/

SN6197 telephone base:

Press and hold FIND HS at the side of the

telephone base for about 10 seconds until the

telephone base shows Registering... Please

wait followed by Deregister all devices?, then

release FIND HS.

You cannot register a pendant if any other system device is in use.

If the pendant is not registered and you press or VOICE, you will hear,

“Not registered.”

•

Immediately press YES or FIND HS. Then all devices are

deregistered. The deregistration process takes about 10 seconds

to complete.

To conﬁrm deregistration, switch on the pendant and press . When the

pendant has been successfully deregistered, you hear “Not registered.”

To deregister all devices from your SN6127/SN6187

telephone base:

Press and hold /FIND HANDSET at the side of the telephone base

for about 10 seconds until the telephone base IN USE light turns

solid red and then ﬂashes red, then release /FIND HANDSET.

Immediately press /FIND HANDSET. Then all devices are

deregistered. The deregistration process takes about 10 seconds

to complete.

To conﬁrm deregistration, switch on the pendant and press . When the

pendant has been successfully deregistered, you hear “Not registered.”

You cannot deregister all devices if any system device is in use.

Deregister all devices

Pendant overview

Press to answer or end a call.

Pendant status light

Stays solid red when the pendant is charging.

Flashes red when the pendant is in low

battery.

Stays solid green when the pendant is fully

charged.

Flashes red and green when the base is paging

the pendant.

Flashes quickly in red and green during pendant

registration.

Flashes orange three times when the pendant is

not registered.

Pendant light (ring around )

On steady when the pendant is in use.

Flashes quickly when there is an

incoming call.

Flashes twice every three seconds when

another telephone system device is

in use.

•

Press to call speed dial 1.

VOL- and VOL+

Press to adjust the listening volume during

a call or message playback.

Press to adjust the pendant ringer volume

while in idle mode.

Press to call speed dial 2.

ON and OFF switch

Switch to turn the pendant on or off.

VOICE

Press to use the voice command feature.

•

Pendant overview
