Urmet domus Max 1717/31 Instruction manual

DS1717-014 LBT20097

MONITOR IP 7'' TOUCHSCREEN

IP 7'' TOUCHSCREEN MONITOR

MONITEUR IP 7'' A ÉCRAN TACTILE

MONITOR IP 7'' PANTALLA TÁCTIL

7''-IP-TOUCHSCREEN-MONITOR

IP-MONITOR 7'' TOUCHSCREEN

Sch./

Ref.

1717/31

GUIDA RAPIDA PER L’UTILIZZO

QUICK USER'S GUIDE

GUIDE RAPIDE D'UTILISATION

GUÍA RÁPIDA DE USO

KURZANLEITUNG

SNELGIDS

Mod.

1717

8 DS1717-014

ENGLISH

FUNCTIONS

HOW TO TURN ON THE SCREEN AND ACCESS THE VARIOUS FUNCTIONS

Tap the screen at any point, or

Press the centre button (4) at the bottom of the screen to bring up the Home Page.

The default Home Page is the Video Door Phone application,

which gives access to the following video door phone functions:

Recording short audio messages (Post-It)

Calling the switchboard

Activating an auxiliary function, e.g. turning on the stair lights (if the IPerVoice system is

adequately pre-set).

Opening a driveway or garage gate.

Opening the door

To change the default application tap the icon , provided in the top left corner, to access the Top

Page, then tap the Set-up icon and finally the Home Page menu.

DS1717-014 9

The other navigation icons in the top bar can be used to:

View footage from the cameras present in the system

View recorded audio-video messages (video door phone messaging

system)

Display the Phone Book and the call log

Send text messages (Chat)

Change the audio/video screen settings

The navigation icons in the bottom bar can be used to:

Return to the previous page.

Return to the Home Page.

Go to the page that lists the recently opened applications.

Send a panic alarm signal (function enabled if the IPerVoice system

includes a suitably configured concierge switchboard service).

Mute the call (Mute) to the monitor for a user-settable period of time.

Change the volume of the call.

Set the following device states:

In-house / Answering Machine / Remote (only one active at a time).

HOW TO INTERPRET THE REPORTS

The bar at the top of the screen shows status information.

Micro SD Card in.

Presence of an unread text message (Chat).

New contact request.

New Post-it not yet listened to.

10 DS1717-014

Missed Call.

Video message not yet viewed.

Panic Alarm sent/cancelled.

Automatic door opening (if this feature is enabled).

In-house / Answering Machine / Remote (only one active at a time).

Active WiFi or 2nd LAN connection (only one active at a time).

LAN connections to IPerVoice network.

Time.

HOW TO NAVIGATE BETWEEN APPLICATIONS

The various applications are accessible from the Top Page, by tapping the special icon.

Video Door Phone

Applications

Yokis

IPerHome

MIFARE

Android App

Example of Top Page

To return to the Home Page from any screen page, tap the icon in the middle of the bottom bar.

HOW TO TURN OFF THE SCREEN

To turn off the screen press the centre button (4) of the 1717/31 Monitor or wait for the timeout set in the

Configuration menu.

DS1717-014 11

HOW TO ANSWER AN EXTERNAL CALL

When the 1717/31 Monitor receives an outdoor door phone video call, it rings and the screen lights up from

its default switched-off state.

The image of the caller shows up on the screen, unless there are other 1717/31 Monitors (or other VoIP

terminals) in the apartment or the "Remote" option is turned on (for more information, check the IPerVoice

manual on www.urmet.com)

By tapping the various icons you can:

Reject the call.

Answer the call and begin a hands-free conversation.

Open the door.

Open a driveway or garage gate.

Store a snapshot of the outdoor image displayed on the screen.

Enlarge or shrink the image, also changing its format from 4:3 to 16:9.

Turn the 1717/31 Monitor microphone off and then back on, to prevent the caller hearing what you

are saying. When the microphone is turned off, the corresponding icon is crossed out. The icon

will only be active after the call has been answered.

Activate an auxiliary function, e.g. turning on the stair lights (if the IPerVoice system is adequately

pre-set).

Close the call. The screen goes off. The icon will only be active after the call has been answered.

Main call module

12 DS1717-014

Change the audio volume in the calling point-to-1717/31 Monitor direction.

HOW TO ACTIVATE A YOKIS CONTROL

From the Top Page press the button to reach Yokis Home Automation:

From here, select your required control or controls, or access the scheduling page.

To schedule a control for one or more weekly occurrences press .

In the new screen the button can be used to create a new scheduling.

The next screen will open where you can set the activation times and days (scheduling):

For more information scan the QR Code below with your smartphone or tablet:

New

DS1717-014 33

34 DS1717-014

DS1717-014 35

36 DS1717-014

LBT20097

DS1717-014

Area tecnica

servizio clienti +39. 011.23.39.810

http://www.urmet.com

e-mail: info@urmet.com

URMET S.p.A.

10154 TORINO (ITALY)

VIA BOLOGNA 188/C

Telef. +39. 011.24.00.000 (RIC.AUT.)

Fax +39. 011.24.00.300 - 323
