Urmet domus II Series User manual

INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITYBASIC SYSTEM DIAGRAMS

sec.1f

−−−−

DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

INSTRUCTIONS FOR

URMET DOMUS DEVICE

INTERCHANGEABILITY

SECTION 1F

(REV.B)

Download from:

www.urmetdomus.com

Technical Manuals area

BASIC SYSTEM DIAGRAMS INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITY

−−−−

sec.1f DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITYBASIC SYSTEM DIAGRAMS

sec.1f

−−−−

DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

INTERCHANGEABLE DEVICES

Some devices replace previous models and may be used as spare parts.

The correspondence between versions is:

(*) Not available in Italy.

786/1 786/11 23

786/5A 786/15 4

786/14 786/11 or 786/12 (*) 23

787/4 786/4 7

789 789/1A 6

789 789/5B 6

789/1A 789/5B 6

1840/22 1090/850 7

4340/20 752/20 8

7073 789/1A 9

7073/1 789/1A 9

7073/2 789/1A 9

7073/5A 789/2 16

9006/1 786/11 12

9006/2 786/11 12

9006/3 786/3A 14

9006/5 786/15 5

9006/14 786/11 or 786/12 (*) 12

9006/22 786/11 or 786/12 (*) 12

9008/14 786/38A 14

788/1 788/51 16

788/5 788/52 17

788/4 788/54 19

788/8 788/58 18

788/11 788/52 15

788/21 788/52 15

788/30 788/52 17

4330/31 788/51 16

4340/11 788/52 15

4520/10 788/52 15

9330 (II series) 788/52 17

9332/1 788/51 16

9332/5 788/52 17

9332/8 788/58 18

9000/20 9000/230 or 9000/110 (*) 18

1201/1 Ranger 1702/1 Atlantico 20

1201/10 1702/1 Atlantico 20

1704/1 Sentry 1705/1 Artico 22

1704/1A Sentry+ 1705/1 Artico 22

1704/10 Sentry 1705/1 Artico 22

1704/10A Sentry+ 1705/1 Artico 22

1704/90 1704/102 22

1704/955 1704/102 22

4340/23 752/23 8

7081/1 Vedette 1704/20 Sentry+ 20

7091/1 Sentinel 1704/20 Sentry+ 20

7101/1 Explorer 1704/20 Sentry+ 20

5150/500 1128/500 14

PREVIOUS MODEL SEE PAGE

NEW MODEL

POWER UNITS

RELAY DEVICES

TRANSFORMERS

DOOR UNITS

APARTMENT

STATIONS

BASIC SYSTEM DIAGRAMS INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITY

−−−−

sec.1f DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

REPLACING RELAY POWER UNIT Ref. 786/5A AND Ref. 9006/5 WITH Ref. 786/15

The 786/15 relay power unit can replace the following obsolete models:

• Ref. 9006/5

• Ref. 786/38A

Follow the following diagrams according to the type of system in which the power unit is being replaced for correct connection.

ELECTRONIC CALL INTERCOM SYSTEMS AND DOOR UNIT

REPLACING RELAY POWER UNIT Ref. 786/5A AND Ref. 9006/5 WITH Ref. 786/15

29 SN235 PS SN1-J ~12~06 PS2781+ C14- C2

C1 SN21A ~12-P1P 2 C22P +-PSSN1-J 61 ~0 ~18

Ref.786/5A

Ref.786/15

With single calls from door unit and door phones without buzzer.

With single call from door unit and door phones with buzzer.

With single calls from door unit and door phones with buzzer (differential call)

Ref.786/5A

Ref.786/15

PS~02P -P SN11P 6 C2-1 SN2 ~181A 2 C1-J ~12+

6~121 + SN25 - PS C1C2 PS282 -J 7 SN139 ~04

Ref.786/15

Ref.786/5A

-J PS21 SN2+4 PS7- ~12 SN1~0 C2832 C195 6

C11A SN2C2--P+22P ~18~0-J 6 PS1P1 ~12 SN1

INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITYBASIC SYSTEM DIAGRAMS

sec.1f

−−−−

DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

REPLACING RELAY POWER UNIT Ref. 786/5A AND Ref. 9006/5 WITH Ref. 786/15

TRADITIONAL CALL INTERCOM SYSTEMS AND DOOR UNIT

With single calls from door unit and door phones with buzzer.

Ref.786/5A 1A ~0 C1 C2+ ~181~12-PS2-P62P SN1-J1P SN2

C2 SN1~014+- PS2 SN2PS C12675-J39 8 ~12Ref.786/15

1 ~01P +6 ~18SN262-62P ~12 SN1Ref.9006/5

C2 SN1~014+- PS2 SN2PS C12675-J39 8 ~12Ref.786/15

BASIC SYSTEM DIAGRAMS INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITY

−−−−

sec.1f DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

REPLACING VIDEO DOOR PHONE POWER UNIT Ref. 789 WITH Ref. 789/1A

REPLACING VIDEO DOOR PHONE POWER UNIT Ref. 789

AND Ref. 789/1A WITH Ref. 789/5B

REPLACING VIDEO DOOR PHONE POWER UNIT Ref. 789 WITH Ref. 789/1A

The 789/1A power unit can replace the obsolete 789 model.

The terminals correspond as follows:

REPLACING VIDEO DOOR PHONE POWER UNIT Ref. 789 AND Ref. 789/1A WITH Ref. 789/5B

The 789/5B video power unit has the following characteristics:

1) It must be powered at 230 V exclusively.

2) It can only be used in video door phone systems with electronic call system (it only has a PS output, no SN output).

3) It can power only two video door phones in stand-by mode (V2).

4) It can power up to 10 video distributors.

5) It is not provided with a -J output for intercom service.

It can therefore replace the Ref. 789 and Ref. 789/1A power units only in systems with the characteristics and limitations above.

In these cases, the terminals correspond as follows: SV102-1814B

Ref. 789 Ref. 789/1A

230

~12

-6

1/~

+TC

110

230

~12

-6

1/~

+TC

OUTPUTS

POWER

SE1

SE2

+6J

-J

SE1

+6J

SE2

-J

MAINS ~

VOLTAGE

UNIT

ELECTRONIC

UNIT

POWER SUPPLY

Ref.789/5B

(230V)

POWER SUPPLY

Ref.789(230V)

Ref.789/1

(110/230V)

INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITYBASIC SYSTEM DIAGRAMS

sec.1f

−−−−

DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

REPLACING DOOR PHONE POWER UNIT Ref. 1840/22 WITH Ref. 1090/850

REPLACING DOOR PHONE POWER UNIT Ref. 787/4 WITH Ref. 786/4

REPLACING DOOR PHONE POWER UNIT Ref. 1840/22 WITH Ref. 1090/850

The 1090/850 power unit can replace the obsolete 1840/22 model.

The terminals correspond as follows:

REPLACING DOOR PHONE POWER UNIT Ref. 787/4 WITH Ref. 786/4

The Ref. 786/4 power unit can replace the obsolete Ref. 787/4 model.

The terminals correspond as follows:

Ref. 1840/22 Ref. 1090/850

~230

~24

+ (12)

- (12)

~230

Not available

Vout

GND

OUTPUTS

POWER

Notes

(#)

(#) If a 24Vac output is needed, use a transformer with minimum output current of 0.2 Aac

(∗) because the device 1840/22 actually outputs approximate 14.3 Vdc

Remove the

jumper between

terminals

P1 and P2 (*)

Ref. 787/4 Ref. 786/4

110

230

~12

-6

-J

PS1

1/~

110

230

~12

-6

PS1

-J

1/~

OUTPUTS

POWER

BASIC SYSTEM DIAGRAMS INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITY

−−−−

sec.1f DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

REPLACING DOOR PHONE TWO-CHANNEL SYSTEM POWER UNIT Ref. 4340/20

WITH Ref. 752/20

REPLACING TWO-CHANNEL SYSTEM DOOR PHONE APARTMENT STATION

Ref. 4340/23 WITH Ref. 752/23

REPLACING DOOR PHONE TWO-CHANNEL SYSTEM POWER UNIT Ref. 4340/20 WITH Ref. 752/20

REPLACING TWO-CHANNEL SYSTEM DOOR PHONE APARTMENT STATION Ref. 4340/23 WITH

Ref. 752/23

The Ref. 752/20 power unit can replace the obsolete Ref. 4340/20 model.

The Ref. 752/23 two-channel door phone apartment station replaces the Ref. 4340/23 model.

The correspondence between device terminals is shown in the following diagram. SC101-0211B

(VX.014)

-/~

+/~

(V X.006)

(V D.007)

(VD.007)

(C 4.009)(C 4.009)(C 4.009)

(C 4.007)

~12

G/T

~12

G/T U4

G/T

G/T2

~12

ELECTRIC LOCK ELECTRIC LOCK ELECTRIC LOCK

twisted

coupled

wires

twisted

coupled

wires

twisted

coupled wires

To bulb

transformer

To bulb

transformer

To bulb

transformer

4340/27 PANEL

AND DOOR UNIT

KOMBI FREE-HANDS PANEL

AND DOOR UNIT

TO THE

FOLLOWING

MODULE

Name tag

lighting

PUSH

BUTTONS

MODULE

Loudspeaker

module

Microphone

module

INDOOR SET

Ref.4340/23

INDOOR SET

Ref.752/23

TO THE FOLLOWING INDOOR SETS

POWER SUPPLY

Ref.752/20

POWER SUPPLY

Ref.4340/20

MAINS ~MAINS ~

Lock

Release

TRANSFORMER

MAIN ~

Name tag

lighting

C4.009 - IMPORTANT Use cord pairs.

VD.007 =

Floor call button.

C4.007 - Sinthesi models only:

See instruction booklet provided with

product for connecting terminals G/T,

~0 and ~12 between modules.

VX.014 - Dusk switch or similar device

for switching lights on, where

relevant.

VX.006 - See the instruction book

provided with the product for fitting

the accessory in the device.

INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITYBASIC SYSTEM DIAGRAMS

sec.1f

−−−−

DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

REPLACING VIDEO DOOR PHONE POWER UNIT Ref. 7073, Ref. 7073/1

AND Ref. 7073/2 WITH Ref. 789/1A

REPLACING VIDEO DOOR PHONE POWER UNIT Ref. 7073, Ref. 7073/1 AND Ref. 7073/2 WITH

Ref. 789/1A

The Ref. 789/1 A power unit replace the previous Ref. 7073, Ref. 7073/1 and Ref. 7073/2 power units in all systems except for:

1) Systems with Vidicon camera: Mod. 789 power units are not provided with + LA, -LA outputs for powering lamps.

2) Continuously powered systems.

3) Systems with more than 20 video door phones monitors in stand-by: in this case use a 6 Vdc power unit providing suitable output current

considering that the average consumption of a video door phone in stand-by is 60 mAcc.

4) Systems with simultaneous operation of 2 or more video door phones: in this case, power each supplementary video door phone using local

power unit Ref. 789/2.

5) The Ref. 789/1 video power unit (110-230V) consists of two units connected using the speciﬁc wire and plugs (C).

The power unit Ref. is 789/101 (110-230V).

The electronic unit Ref. is 789/102.

Jumpers ~0, ~A and ~12, ~B are pre-ﬁtted.

POWER SUPPLY

Ref.789/1

(110/230V)

VIDEO

POWER SUPPLY

Ref.7073 OR

7073/1

VIDEO

POWER SUPPLY

Ref.7073/2

CALL

GENERATOR

Ref.787/1

VIDEO

POWER SUPPLY

Ref.7073/1

MAINS ~

BASIC SYSTEM DIAGRAMS INSTRUCTIONS FOR URMET DOMUS DEVICE INTERCHANGEABILITY

−−−−

sec.1f DOOR PHONE - VIDEO DOOR PHONE SYSTEMS: Installation Diagrams

REPLACING VIDEO DOOR PHONE POWER UNIT Ref. 7073, Ref. 7073/1

AND Ref. 7073/2 WITH Ref. 789/1A

SCOUT AND CAMERA SYSTEMS (CCD CAMERA ONLY)

The Ref. 787/1 tone generator is not used because it is replaced by a generator inside the Ref. 789/1 A power unit.

Connect jumpers SE1, ~12 during installation. SV102-0583A

SENTINEL, EXPLORER AND RANGER AND CAMERA SYSTEMS (CCD CAMERA ONLY)

SV102-0582A

POWER SUPPLY

Ref.789/1A

(110/230V)

MAINS ~ MAINS ~

VOLTAGE

UNIT

ELECTRONIC

UNIT

VIDEO

POWER SUPPLY

Ref.7073/1

LOCK

RELEASE

ELECTRIC

LOCK

CCD TV CAMERA UNIT

PUSH BUTTON

PANEL

L.U.

TV CAMERA UNIT

TONE

GENERATOR

Ref.787/1

POWER SUPPLY

Ref.789/1A

(110/230V)

MAINS ~

VOLTAGE

UNIT

ELECTRONIC

UNIT

VIDEO

POWER SUPPLY

Ref.7073/1

LOCK

RELEASE ELECTRIC

LOCK

CCD TV CAMERA UNIT

PUSH BUTTON

PANEL

L.U.

TV CAMERA UNIT

This manual suits for next models

Table of contents

Other urmet domus Intercom System manuals

urmet domus

urmet domus SIGNO 1740/1 Instruction Manual

urmet domus

urmet domus 2VOICE 1083 User manual

urmet domus

urmet domus IPerVoice 1716 System manual

urmet domus

urmet domus 6025/401 User manual

urmet domus

urmet domus 2voice Sinthesi 1083/9 User manual

urmet domus

urmet domus 1043/550 User manual

urmet domus

urmet domus 5VOG 5W 1760 User manual

urmet domus

urmet domus 1722 User guide

urmet domus

urmet domus Brave NUDV S2 Troubleshooting guide

urmet domus

urmet domus 1150/35 User manual

urmet domus

urmet domus elekta steel 1060 User manual

urmet domus

urmet domus 1051 User manual

urmet domus

urmet domus Miro 1722 Guide

urmet domus

urmet domus 1722/71 Instruction Manual

urmet domus

urmet domus 1172 User manual

urmet domus

urmet domus 1723 User manual

urmet domus

urmet domus IPerCom VOG 7 1761 Series Installation and operation manual

urmet domus

urmet domus 1033/470 User manual

urmet domus

urmet domus VOG7 1760/31A Installation and operation manual

urmet domus

urmet domus mikra2 1060/21 Quick start guide

urmet domus

urmet domus DIGIVOICE 1138 User manual

urmet domus

urmet domus 1726 Quick guide

urmet domus

urmet domus DUO 752 User manual

urmet domus

urmet domus IPerCom VOG 7 1761 Series Installation and operation manual

Popular Intercom System manuals by other brands

Bticino

Bticino LINEA 3000 Installation

MSI

MSI MSI-140 owner's manual

golmar

golmar Stadio Plus instruction manual

CyberData

CyberData 011211 series Installation quick reference

Vidos

Vidos duo M1021 user manual

Vimar

Vimar ELVOX 7539/E Installation and operation manual

SSS Siedle

SSS Siedle BTSV 850-03 operating instructions

Dahua

Dahua VTO Series quick start guide

Elvox

Elvox 5651 Wiring instructions

Videx

Videx VIDEOKIT Series owner's manual

Rocom

Rocom Doortello Business FW T2.05W2.04 user guide

Viking

Viking E-35-EWP product manual

Safeguard Supply

Safeguard Supply LRA-EX1000 user manual

SSS Siedle

SSS Siedle BFCV 850 Series operating instructions

GRD

GRD MAX V2 user manual

Alecto

Alecto ADI-250 user manual

Aiphone

Aiphone IE-8MD Installation & operation manual

Perel

Perel EDB4 user manual

urmet domus II Series User manual

Popular Intercom System manuals by other brands
