Uplus Lighting MINI740 User manual

User manual

MINI 740

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions………………………………………………………………………………3-4

Technical Specifications……………………………………………………………………………4

Control Menu …………………………………………………………………………………………5

DMX Channels ……………………………………………………………………………………6-8

Dimension ……………………………………………………………………………………………9

Trouble Shooting……………………………………………………………………………………0

Fixture Cleaning………………………………………………………… …………………………10

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces. Be sure that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always

by taking its base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher

than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before

replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any

repairs yourself. In the unlikely event your unit may require service, please contact your nearest

dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

fixed to avoid vibration and slipping while operating. And make sure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also

always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people.

2.Technical Specifications

Voltage: AC100V～240V 50-60HZ

Rated Power: 350W

LED Source: 7*40W RGBW 4-in-1 LED

Zoom angle: 4.5°-45°

Strobe: 0-25Hz

Control: DMX512/Auto Run/Master-Slave/Music

DMX Channels: 17/21/21/29channel

Dimmer: 0-100% linear dimmer

Pan: 540°+16 bit fine

Tilt: 270°+16 bit fine

Display: LCD colorful display

IP: IP20

Dimension:340*273*170mm ; NW:5.75 kgs

3.Control Menu

Menu Operation

Main Menu

Second

Third

Fourth

Dmx Address

000 - 512

Fixture

Dmx Mode

BAS1 7 CH/ BAS2 1 CH/ EXT2 1 CH/ EXT2 9 CH

Run Mode

DMX / Host / Sound

Pan Invert

Close / Open

Tilt Invert

Close / Open

No Dmx Signal

Clear / Hold

Sound Control

0 -- 99

Manual

Pan

000 - 255

Pan Fine

000 - 255

Tilt

000 - 255

Tilt Fine

000 - 255

⁞

Information

Time

Current Time

xxxH

Total Time

xxxH

Sensor

Pan

FALSE / TURE

Tilt

FALSE / TURE

Zoom

FALSE / TURE

Te m p

FALSE / TURE

Fan

FALSE / TURE

Te m p e r a t u r e

Head Temp

xxxC

Software Version

Panel

Vx . xx

Factory

Password

000 - 255

Pan

000 - 255

Tilt

000 - 255

Zoom

000 - 255

Red

000 - 255

Green

000 - 255

Blue

000 - 255

White

000 - 255

Fixture Reset

Motor Reset

Cance / Run

Factory

Cance / Run

Display

Language

CH / EN

Display Flip

Normal / Reverse

Display Mode

6 0 s / Show

4.DMX Channels

17 CH Mode

Channel

Features

value

Function

CH1

Red

0--255

Red 0- 100% dimmer, from dark to bright

CH2

Green

0--255

Green 0- 100% dimmer, from dark to bright

CH3

Blue

0--255

Blue 0- 100% dimmer, from dark to bright

CH4

White

0--255

White 0- 100% dimmer, from dark to bright

CH5

CTO

0--255

8500K-2800K CT linear contro

CH6

Macro color

0--255

Macro color change

CH7

Strobe

0--3

4--103

Regular Strobe, Slow To Fast

104--107

Open

108--207

Pulse, Slow To Fast

208--212

Open

213--225

Random Slow Strobe

226--238

Random Middle Speed Strobe

239--251

Random Fast Strobe

252--255

Open

CH8

Dimmer

0- 100% linear dimmer

CH9

Dimmer fine

CH10

Pan

0--255

Pan movement control

CH11

Pan Fine

0--255

Pan fine control

CH12

Tilt

0--255

Tilt movement control

CH13

Tilt Fine

0--255

Tilt fine control

CH14

Zoom

0--255

zoom

CH15

Color cross fade

0--255

multiple color cross fade

CH16

Function

0--255

CH17

Reset

0--250

No function

251--255

Wait 5 seconds to auto reset

21 CH Mode (basic)

Channel

Features

value

Function

CH1

Red

0--255

Red 0- 100% dimmer, from dark to bright

CH2

Red fine

0--255

Red fine

CH3

Green

0--255

Green 0- 100% dimmer, from dark to bright

CH4

Green fine

0--255

Green fine

CH5

Blue

0--255

Blue 0- 100% dimmer, from dark to bright

CH6

Blue fine

0--255

Blue fine

CH7

White

0--255

White 0- 100% dimmer, from dark to bright

CH8

White fine

0--255

White fine

CH9

CTO

0--255

8500K-2800K CT linear contro

CH10

Macro color

0--255

Macro color change

0--3

4--103

Regular Strobe, Slow To Fast

CH11

Strobe

104--107

Open

108--207

Pulse, Slow To Fast

208--212

Open

213--225

Random Slow Strobe

226--238

Random Middle Speed Strobe

239--251

Random Fast Strobe

252--255

Open

CH12

Dimmer

0- 100% linear dimmer

CH13

Dimmer fine

CH14

Pan

0--255

Pan movement control

CH15

Pan Fine

0--255

Pan fine control

CH16

Tilt

0--255

Tilt movement control

CH17

Tilt Fine

0--255

Tilt fine control

CH18

Zoom

0--255

zoom

CH19

Color cross fade

0--255

multiple color cross fade

CH20

Function

0--255

CH21

Reset

0--250

No function

251--255

Wait 5 seconds to auto reset

21 CH Mode (extender)

Channel

Features

value

Function

CH1

Red Circle

0--255

Red Circle 0- 100% dimmer, from dark to bright

CH2

Green Circle

0--255

Green Circle 0- 100% dimmer, from dark to bright

CH3

Blue Circle

0--255

Blue Circle 0- 100% dimmer, from dark to bright

CH4

White Circle

0--255

White Circle 0- 100% dimmer, from dark to bright

CH5

Red Centre

0--255

Red Centre 0- 100% dimmer, from dark to bright

CH6

Green Centre

0--255

Green Centre 0- 100% dimmer, from dark to bright

CH7

Blue Centre

0--255

Blue Centre 0- 100% dimmer, from dark to bright

CH8

White Centre

0--255

White Centre 0- 100% dimmer, from dark to bright

CH9

CTO

0--255

8500K-2800K CT linear contro

CH10

Macro color

0--255

Macro color change

CH11

Strobe

0--3

4--103

Regular Strobe, Slow To Fast

104--107

Open

108--207

Pulse, Slow To Fast

208--212

Open

213--225

Random Slow Strobe

226--238

Random Middle Speed Strobe

239--251

Random Fast Strobe

252--255

Open

CH12

Dimmer

0- 100% linear dimmer

CH13

Dimmer fine

CH14

Pan

0--255

Pan movement control

CH15

Pan Fine

0--255

Pan fine control

CH16

Tilt

0--255

Tilt movement control

CH17

Tilt Fine

0--255

Tilt fine control

CH18

Zoom

0--255

zoom

CH19

Color cross fade

0--255

multiple color cross fade

CH20

Function

0--255

CH21

Reset

0--250

No function

251--255

Wait 5 seconds to auto reset

29 CH Mode (extender)

Channel

Features

value

Function

CH1

Red Circle

0--255

Red Circle 0- 100% dimmer, from dark to bright

CH2

Red Circle fine

0--255

Red Circle fine

CH3

Green Circle

0--255

Green Circle 0- 100% dimmer, from dark to bright

CH4

Green Circle fine

0--255

Green Circle fine

CH5

Blue Circle

0--255

Blue Circle 0- 100% dimmer, from dark to bright

CH6

Blue Circle fine

0--255

Blue Circle fine

CH7

White Circle

0--255

White Circle 0- 100% dimmer, from dark to bright

CH8

White Circle fine

0--255

White Circle fine

CH9

Red Centre

0--255

Red Centre 0- 100% dimmer, from dark to bright

CH10

Red Centre fine

0--255

Red Centre fine

CH11

Green Centre

0--255

Green Centre 0- 100% dimmer, from dark to bright

CH12

Green Centre fine

0--255

Green Centre fine

CH13

Blue Centre

0--255

Blue Centre 0- 100% dimmer, from dark to bright

CH14

Blue Centre fine

0--255

Blue Centre fine

CH15

White Centre

0--255

White Centre 0- 100% dimmer, from dark to bright

CH16

White Centre fine

0--255

White Centre fine

CH17

CTO

0--255

8500K-2800K CT linear contro

CH18

Macro color

0--255

Macro color change

CH19

Strobe

0--3

4--103

Regular Strobe, Slow To Fast

104--107

Open

108--207

Pulse, Slow To Fast

208--212

Open

213--225

Random Slow Strobe

226--238

Random Middle Speed Strobe

239--251

Random Fast Strobe

252--255

Open

CH20

Dimmer

0- 100% linear dimmer

CH21

Dimmer fine

CH22

Pan

0--255

Pan movement control

CH23

Pan Fine

0--255

Pan fine control

CH24

Tilt

0--255

Tilt movement control

CH25

Tilt Fine

0--255

Tilt fine control

CH26

Zoom

0--255

zoom

CH27

Color cross fade

0--255

multiple color cross fade

CH28

Function

0--255

CH29

Reset

0--250

No function

251--255

Wait 5 seconds to auto reset

5.Dimension

6.Trouble Shooting

ollo

ing

few

oble

y occu

uring

ope

tion

. He

tion

leshooting

The

does

work

, no

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

If th

nd no

espons

el,

che

ess

etti

s a

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

. One

the

cha

ing

tep

moto

dam

the

nect

to th

PCB

oken.

oto

’

ive

PCB

ndition

7.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,

smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.

Other manuals for MINI740

Table of contents

Other Uplus Lighting Lighting Equipment manuals

Uplus Lighting

Uplus Lighting BAR 6 LASER User manual

Uplus Lighting

Uplus Lighting 4020 IP User manual

Uplus Lighting

Uplus Lighting 750 BSWF User manual

Uplus Lighting

Uplus Lighting BSW 350 User manual

Uplus Lighting

Uplus Lighting 300 MZ-SPOT PR User manual

Uplus Lighting

Uplus Lighting PF350 User manual

Uplus Lighting

Uplus Lighting 200 LED BSW User manual

Uplus Lighting

Uplus Lighting IR 1210 PAR User manual

Uplus Lighting

Uplus Lighting RETRO 360 User manual

Uplus Lighting

Uplus Lighting 200 LED RETRO User manual

Uplus Lighting

Uplus Lighting DUAD540 STROBE User manual

Uplus Lighting

Uplus Lighting 250 BEAM User manual

Uplus Lighting

Uplus Lighting IP 300Z SPOT-WW User manual

Uplus Lighting

Uplus Lighting IP MATRIX 5 User manual

Uplus Lighting

Uplus Lighting W1925 User manual

Uplus Lighting

Uplus Lighting IP-L360 User manual

Uplus Lighting

Uplus Lighting 200 BLINDER User manual

Uplus Lighting

Uplus Lighting 200 MZ-SPOT PR User manual

Uplus Lighting

Uplus Lighting 460LED BSW User manual

Uplus Lighting

Uplus Lighting LED PROFILE FIX User manual

Uplus Lighting

Uplus Lighting 37X15ZWASH User manual

Uplus Lighting

Uplus Lighting LED PROFILE MZ User manual

Uplus Lighting

Uplus Lighting 360 BEAM User manual

Uplus Lighting

Uplus Lighting BL6 User manual

Popular Lighting Equipment manuals by other brands

Brizo

Brizo 8SP-MU-4 manual

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 installation instructions

IKEA

IKEA BJÖRKSPIREA manual

Laserworld

Laserworld Evolution Series ES-400RGB manual

Alien

Alien RG STAR user manual

EuroLite

EuroLite LED B-40 user manual

Qazqa

Qazqa Suplux SL 3 Black 103062 instruction manual

Commercial Electric

Commercial Electric 54568141 Use and care guide

CREE LIGHTING

CREE LIGHTING 304 Series installation instructions

Goobay

Goobay 49867 user manual

ECOMAN ITALIA

ECOMAN ITALIA LED T8 instruction manual

Alkalite

Alkalite Krypton KT-81 user manual

Clas Ohlson

Clas Ohlson GU10 manual

DTS

DTS DELTA 10 F user manual

ring

ring Solar Steplight manual

One Stop Gardens

One Stop Gardens 57696 Owner's manual & safety instructions

Chauvet DJ

Chauvet DJ COREpar UV120 ILS user manual

SIREM

SIREM Swimeo A2 instructions
