Universal Remote Control MX600 User manual

Meet the MX-600

“The Most Reviewed

Remote in History”

With “No More Pointing” RF Control!

The IR/RF MX-600 inherits it’s hybrid LCD screen

and hard button layout from the acclaimed MX-500

(IR only) remote control. The MX-600 broadcasts

radio frequency (RF) signals as well as infrared (IR).

Using the MRF-100 RF Base Station, the MX-600

can control infrared A/V components without

pointing the remote at all, through walls,floors,

and cabinet doors,indoors or outdoors.

50-100' RangeThrough Walls and Cabinet

Doors, Indoors and Outdoors

Programs Using Internal IR Command

Database or Learning

Replaces Up to Ten Remote Controls

Macro Capability: 15 Macro Buttons of 20

Steps Each and 50 Favorite Channel

Macro Buttons of 10 Steps Each

Clone Programming from One

MX-600 to Another MX-600 in

Less than 3 Minutes

Bright Backlighting for Both the

LCD Screen and Buttons

MX-600™

IR/RF Learning Remote

and MRF-100 RF Base Station

Ultimate Customization Optimum Ergonomics

MRF-100 Radio Frequency (RF) Base Station

MX-600/MRF-100 IR/RF Learning Remote

Fast On-Board Programming

Automation Using Macros and Favorites

The powerful memory of the MX-600 offers up to

15 potential Macro buttons and an additional 50

Favorite Channel buttons. Each of these macros can

play back a sequence of programmed commands

that completely automates a complex system with

one button press. A Macro button can record and

play back up to 20 steps, while a Favorite Channel

button can play back up to 10 steps.

Replaces Ten Remote Controls

The MX-600 controls up to 10 components. Each of

the 10 components can be programmed with up to 2

pages of LCD screens plus the 33 hard buttons. The

MX-600 allows you to edit the text on each LCD

screen exactly as you prefer (up to 26 screens with

260 text buttons are available). Whether you prefer

single screen simplicity or total replacement of the

original remotes, the MX-600 will exceed your expectations.

Comprehensive Compatibility with Components

The MX-600’s internal database contains hundreds of “code

sets” of various brands, including hard to find and specific

discrete codes that allow for precise control of all system

components.The MX-600 also has the ability to learn up to 530

new commands.

Memory Back-Up

The MX-600 system features a smart flash memory back-up

system that will retain the programmed memory for up to ten

years, even with dead batteries.

One Hand Ergonomics – Easier to Use

than Original Component Remotes!

The optimized layout enables you to naturally reach

both the thumbpad and hard buttons to navigate

on-screen menus and the critical Transport, Channel

and Volume controls. You’ll quickly discover that you

prefer using the MX-600 to control all the special

features of your system (especially personal video

recorders, satellite receivers, DVD players, surround

sound receivers and digital cable boxes). There will

never be a reason to dig out the old remotes again.

Simplicity Via the RF Base Station

No More Pointing - Radio Waves Penetrate Walls,

Doors and Floors

The MRF-100 receives the RF signals of the MX-600

remote control from any direction.You no longer need

to point the remote control at any of your A/V

components. You can also place the components distracting

blinking lights and displays behind closed cabinet doors and/or

in another room!

trademark of Universal Remote Control, Inc. Entertainment Made Simple is a

trademark of Universal Remote Control, Inc.

The Ultimate In Control Simplicity!

Specifications

MX-600 Remote Control

RF Frequency: 418MHz

RF Range: 50 to 100 feet, depending upon the environment (the

structure of your house, the amount of interference etc.)

IR (Line of Sight) Range: 50-60 feet depending upon components

Weight: 8 oz. (with batteries)

Memory Capacity: 15 Macro Buttons of 20 Steps, 50 Favorite Channel

Macro Buttons of 10 Steps and up to 530 IR Commands with up to 26

Custom Labeled Screens.

Size: 9.0" x 3.0" x 1.3"

Batteries: Four AAA Alkaline batteries included

LCD Size: 1.4" x 2.1"

Warranty: One year Parts and Labor

MRF-100 Radio Frequency Base Station

Power Supply: 9V 300mA/110V 60Hz (included)

IR Flasher Line Outputs: 2.5mm Mono Mini Jack

RF Frequency: 418MHz

Size: 5 1/8" x 3.5" x 1.25" (4.5" antenna up)

Mounting Bracket and Six Emitter/Flashers included

500 Mamaroneck Avenue, Harrison, NY 10528

Phone: (914) 835-4484 Fax: (914) 835-4532

MX-600/MRF-100

IR/RF Learning Remote

www.hometheatermaster.com

3. Self-adhesive “Flashers” affix to

the Infrared sensors on the front

panels of your components. The

Flashers relay commands to

components out of sight of the

MRF-100’s Front Blaster. The

Flashers plug in to the MRF-100’s

rear flasher line outputs via their

10 foot cables.

1. The MX-600 remote control sends radio waves in every

direction, so you don’t have to point the remote anymore.

2. The MRF-100’s built-in Front Blaster

sends commands to components in the

same cabinet space as the MRF-100.
