Uniden FP104 User manual
FP104
Operating Guide
SPECIAL
EDITION
PHONE
Loud Adjustable
Earpiece Volume
FP104
5
Precautions
Important Safety Instructions . . . . . . . . . 1
Caring for Your Telephone . . . . . . . . . . 1
Important Notes . . . . . . . . . . . . . . . . . . 2
Introduction
Welcome . . . . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . 3
Included In Your Package . . . . . . . . . . . 4
Installing and Adjusting your Phone
Installation . . . . . . . . . . . . . . . . . . . . . . 5
Wall Mounting . . . . . . . . . . . . . . . . . . . 6
Controls And Functions . . . . . . . . . . . . 7
Using Your FP104
Adjusting the Ringer Volume . . . . . . . . . 8
Adjusting the Ringer Tone . . . . . . . . . . . 8
Adjusting the Handset Volume . . . . . . . . 8
Placing a Telephone Call . . . . . . . . . . . . 9
Receiving a Telephone Call . . . . . . . . . 9
Accessing the Call Waiting Service . . . . 9
Placing a Call on Mute . . . . . . . . . . . . 10
Redial . . . . . . . . . . . . . . . . . . . . . . . . 10
Placing a Call on Hold . . . . . . . . . . . . 10
Memory Dial Numbers . . . . . . . . . . . . 10
Storing One-Touch Memories . . . . . . . . 11
Pause . . . . . . . . . . . . . . . . . . . . . . . . 11
Memory Storage Card . . . . . . . . . . . . . 11
Dialing Numbers from Memory . . . . . . 11
Troubleshooting . . . . . . . . . . . . . . . . . 12
Specifications . . . . . . . . . . . . . . . . . . . 13
Warranty . . . . . . . . . . . . . . . . . . . . . . 14
CONTENTS
CONTENTSOF YOUR OWNERS MANUAL
When using your telephone equipment, these basic safety precautions
should always be followed to reduced the risk of fire, electrical shock,
and injury to persons:
1. Read and understand all instructions.
2. Do not use the telephone during an electrical storm to reduce the
risk of electric shock.
3. Unplug this product from the wall outlet before cleaning, and
use a dry cloth, without liquid or aerosol cleaners.
4. Do not use this product near water; for example, near a bathtub,
washbowl, kitchen sink or laundry tub, in a wet basement or
near a swimming pool.
5. Do not place this product on an unstable cart, stand or table. The
telephone may fall, causing serious damage to the unit.
6. Do not allow anything to rest on the telephone cord. Do not
locate this product where the cord will be damaged by persons
walking on it.
7. Never push objects of any kind into this product through cabinet
slots, as they may touch dangerous voltage points or short out
parts that could result in a risk of fire or electric shock. These
slots and openings are provided for ventilation. Never spill liquid
of any kind on the product.
8. To reduce the risk of electric shock, do not disassemble this
product. Take it to qualified service personnel when service or
repair work is required. Opening or removing covers may expose
you to dangerous voltages or other risks. Incorrect reassembly can
cause electric shock when the appliance is subsequently used.
IMPORTANT SAFETY INSTRUCTIONS
1
The exclamation point within an equilateral triangle is
intended to alert the user of the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
PRECAUTIONSFOR YOUR PHONE
• Clean your telephone using a soft damp cloth.
• Do Not use solvents, detergents, sprays, abrasive pads, scouring
powder or other products that may damage your telephone.
• Do Not place the telephone in direct sunlight.
• Do Not use in extreme humidity.
Caution
You must not connect your phone to any of the following:
• Coin operated systems
• Party-line systems
• Most electronic key phone systems
We have designed your telephone to conform to local regulations,
and you can connect it to most telephone lines. However, each
device that you connect draws power from the phone line. We refer
to the power drawn as the device’s Ringer Equivalence Number
(REN or RN). This number is shown on the bottom of your
telephone. If you are using more than one phone or other device on
the line, add up all the REN’s. If the total is more than three (3)
your phones may not ring.
Please read before use and save these instructions
IMPORTANT NOTES
CARING FOR YOUR TELEPHONE
2
PRECAUTIONS
This unit is not waterproof. To reduce the risk of fire,
electrical shock or damage, DO NOT expose this product to
rain, water or any liquid or moisture.
Congratulations on the purchase of your Uniden FP104 Telephone.
The FP104 has been designed and engineered to exacting standards
for reliability, long life and outstanding performance.
To obtain the full benefit from your new telephone, please read this
Operating Guide thoroughly. For your future reference, please fill in
the panel below and attach your Purchase Receipt/Sales docket.
• Enhanced Handset Volume • Loud Ringing Tone
• Large Keypad Prints • 5 One Touch Memories
• Adjustable Handset Volume • Adjustable Ringer Tones
• Music on Hold • Mute
• Hearing Aid Compatible • Last Number Redial
• Hold & Mute Indicators • Bright Incoming Call Indicator
• Pause Button • Flash Button
• Wall Mountable • Advanced Build Quality
FEATURES
WELCOME
3
INTRODUCTION
TO YOUR NEW PHONE
Serial No.......................................................... Date of Purchase.........................
(found on the bottom of the phone)
Name and address of dealer .................................................................................
...............................................................................................................................
FP104
Operating Guide
SPECIAL
EDITION
PHONE
SPECIAL
EDIT
P
Loud Adjustable
Earpiece Volume
FP104
t
4
INTRODUCTION
INCLUDED IN YOUR PACKAGE
Base Unit
Wall Mounting
Bracket
Handset
Memory
Storage Card
●This Owner’s Manual
●Registration Card
Curly Cord Telephone Line Cord
(
*
Plug included in Australian models only)
Operating Guide 2 x Wall Mounting
Screws and Wall Plugs
To get the most
from your phone,
please read this
owner’s manual
thoroughly. Be sure
to complete and
mail the product
registration form.
If any of these items
are missing or
damaged, contact
your place of
purchase.
*
1. Plug one end of the
Handset Cord (curly) into
the Handset and the other
end into the jack on the
side of the telephone.
2. Plug one end of the line
cord (straight) into the
telephone line jack on
the back of the telephone
and the other end into the wall outlet.
●Never install telephone wiring during a lightning storm.
●Never touch uninsulated telephone wires or terminals
unless the telephone line has been disconnected.
●Use caution when installing or modifying telephone
lines.
Note: Most phone equipment available now uses modular jacks.
Phone cords are fitted with a molded plastic connector
which plugs into this type of jack. If you do not have a
modular phone jack, contact your local telephone company
for information about their installation.
INSTALLATION
5
INSTALLING
YOUR PHONE
WALL MOUNTING
You can mount your phone directly on a wall. Before mounting
your phone, consider the following:
• Select a location away from electrical cables, pipes or other items
behind the mounting location that could cause a hazard when
inserting screws into the wall.
• Make sure the wall material is capable of
supporting the weight of the telephone.
1. Use the screws (supplied) with anchoring devices
suitable for the wall material where the
telephone will be placed.
2. Gently pull and turn the Handset
Retainer Tab 180˚ and release.
3. Fit the Wall Mounting Bracket to
the Bottom of the telephone as
shown.
4. Place the Base Unit on the screws
and push down until it’s firmly
seated.
5. Follow steps in Telephone
Installation as shown on previous
page.
6
Be careful not to
insert the mounting
screws
into possible
electrical hazards
such as cables,
wiring, or pipes.
INSTALLING YOUR PHONE
CONTROLS & FUNCTIONS
7
CONTROLS & FUNCTIONS
Memory
Button
Ring Tone
Selector
Handset
Retainer
Pause
Button
Mute
Indicator
Hold
Indicator
Ring/Incoming
Call Indicator
Hold Button
Handset
Volume Control
Ringer
Volume Control
Redial
Button
Mute
Button
Flash
Button 5 One-Touch
Memories
KEYPAD
On-Hook/
Off-Hook Switch
Telephone
Line Jack
