Uniden WDECT 2355+2 User manual
WDECT
2355
+
2
Wide Band Digital
Technology provides
the clearest sound
and the best privacy.
Guide
Quick Start
UP354BH(WDECT2355+2) OM 5/14/04 12:04 PM Page a
[ i ]
INSTALLATION & SAFETY
• This symbol
indicates important
operating and
servicing instructions.
• The earcap of this
telephone may attract
and retain small
metallic objects.
3
AVOID -
connecting
more than
phones as ringing
may be impaired
AVOID -
multi power boards.
CHARGE -
the new phone
for 15 - 20 hrs.
AVOID -
Moisture
Don’t -
overload the
power outlet.
AVOID -
moisture
AVOID -
Television sets and
other electronic
appliances AVOID -
Microwave ovens
AVOID -
Computers
AVOID -
other cordless
telephones
CHOOSE -
a central location
Note: Ringing will not be impaired by
adding extra cordless handsets.
Choosing the best location for your phone.
When choosing a location for your phone there are a number of appliances the phone
should not be near, and areas you should avoid.
UP354BH(WDECT2355+2) OM 5/14/04 10:48 AM Page i
[ ii ]
QUICK START GUIDE
This page is a very condensed version of the Owner’s
Manual. It is designed to allow you to get your phone
installed and operating as quickly as possible -
however it does not attempt to explain any of the
advanced features of the WDECT2355 series.
1) Connect the AC adapter to the DC IN 9V jack
and to a standard AC wall outlet.
Make sure the AC
Adapter/s remains
switched ON at all
times. Use only the
Uniden AC Adapter/s
supplied with this unit.
Start
Here!
Installing the Base Unit
2) Connect the telephone line cord to the
TEL LINE jack and to a telephone socket
on the wall.
For wall mounting, see “Mounting the
Base Unit on a Wall” on page 6.
UP354BH(WDECT2355+2) OM 5/14/04 10:48 AM Page ii
[ iii ]
Installing the battery pack
1) Press down on the battery cover release and slide the
cover down until it comes off.
2) Connect the battery plug to the socket at the rear of the
battery compartment. The RED and BLACK battery wires
must match the RED and BLACK dots on the phone case for
the plug to fit properly. Press firmly until it clicks
into place.
3) Securely close the battery compartment cover by sliding it
up until it snaps into place.
Red
Wire
Black
Wire
3) Set the base on a desk or tabletop.
4) Raise the antenna to a vertical position.
Connecting the charger
1) Connect the AC adapter into the charging cradle
and to a AC wall outlet.
2) Set the charger on a desk or tabletop.
• Charge the handset
battery pack for at
least 15-20 hours
before using your
new cordless
telephone for the
first time.
• Use only the Uniden
rechargeable battery
pack (BT-446)
supplied with your
cordless telephone.
UP354BH(WDECT2355+2) OM 5/14/04 10:48 AM Page iii
[ iv ]
Charging the handset(s)
1) Place the handset(s) in the main base unit or charging
cradle with the keypad facing forward.
2) Make sure the charge LED illuminates. If the LED does not illuminate, check to see
that the AC adapter is plugged in and that the handset makes good contact with the
base charging contacts.
• After installing the batteries in the handset, charge your handset at least 15-20 hours.
During a power cut
or if the AC adapter
is switched off,
this telephone
will not operate.
Recharge your phone
on a regular basis by
returning the handset
to the base after
each phone call.
UP354BH(WDECT2355+2) OM 5/14/04 10:48 AM Page iv
[ v ]
CONTENTS
INSTALLATION & SAFETY i
QUICK START GUIDE ii
CONTENTS v
GETTING STARTED 1
Controls and Functions 1
Uniden Company Philosophy 3
Welcome 3
Features 4
Checking the Package Contents 5
Terminology 5
Mounting the Base Unit on a Wall 6
Battery Maintenance 7
Installing the Beltclip 8
Headset Installation (Optional) 9
Display and Icons 9
About the Menu Options 10
Setting up the Menu 14
BASICS 22
Making and Receiving Calls 22
Keypad Lock 23
Placing a Call on Hold 23
Redialing a Call 24
Adjusting the Handset Ringer,
Earpiece and Speaker Volume 25
Do Not Disturb (DND) 26
Mute Microphone 26
Tone Dialing Switch-Over (Australia Only) 27
Traveling Out-of-Range 27
Clarity Booster 27
Privacy Mode 28
3-way Conferencing 28
Find Handset 29
Flash and Call Waiting 29
New Message LED 29
PHONEBOOK 30
Phonebook 30
Storing Phone Numbers, Names,
Distinctive Rings, and Speed Dial 30
Steps for Entering Names and Special Characters 32
Viewing the Phonebook 34
Making Calls Using the Phonebook 35
Speed Dialing 35
Editing or Erasing a Stored Name,
Phone Number, Distinctive Ring, and Speed Dial 36
Chain Dialing 37
Memory Dialing (Base Only) 37
CALLER ID 38
Caller ID 38
Viewing the Caller ID List 39
Deleting a Caller ID Message 40
Using the Caller ID Message List 41
THE INTEGRATED ANSWERING DEVICE 42
The Integrated Answering Device 42
Turning the Answering System On/Off 43
Setting up your Answering System 44
Using your Answering System 50
Remote Operation 53
EXPANDING YOUR PHONE 56
Expanding your Phone 56
Register the Handset 57
Using Two Way Communication between the
Handsets Anywhere without the Base (DirectLink) 58
Room Monitor 58
4-Way Conferencing 59
Intercom/Call Transfer Feature 59
Replacing the Base 60
ADDITIONAL INFORMATION 61
Changing the Digital Security Code 61
TROUBLESHOOTING 62
INDEX 65
WARRANTY 66
UP354BH(WDECT2355+2) OM 5/14/04 2:20 PM Page v
GETTING STARTED
[ 1 ]
CONTROLS AND FUNCTIONS
2
1
3
5
4
6
7
8
9
10
11
12
22
15
13
18
19
16
20
21
17
14
Repeat Key
Delete Key Stop Key
Play Key
Skip Key
Select/ Key
1. Handset Antenna
2. Headset Jack Cover
3. Beltclip Hole
4. Hands-Free Speaker
5. Handset Battery Compartment
6. New Message LED
7. Handset Earpiece
8. LCD Display
9. /del Key
10. /vol/ / Key
a. ringer volume control
b. scroll keys for display screen
11. Key
12. redial/pause Key
13. speaker Key
14. Key
15. Key
16. Key
17. Key
18. Key
19. phonebook Key
20. /transfer/int’com Key
21. Handset Microphone
22. Handset Charging Contacts
Handset Remote Operation (P. 54)
(Review ITAD messages from handset)
UP354BH(WDECT2355+2) OM 5/14/04 10:48 AM Page 1
[ 2 ]
33
34
35
36
37
38
39
46 47 48
49 50
23 24 25 26 27 28 29 30 3231
40
41
42
43
44
45
23. Base Speaker
24. Clock/MENU Key
25. repeat/SELECT Key
26. delete Key
27. Charge LED
28. Message Counter Display
29. In use LED
30. play/stop Key
31. skip/SELECT Key
32. SET Key
33. Memo record Key
34. Ans on/off Key
35. Greeting Key
36. Mem Key
37. Redial/p Key
38. Flash Key
39. Base Charging Contacts
40. Intercom Key
41. Mute/find handset Key
42. Hold Key
43. /volume / Key
44. Key/speaker LED
45. Base Antenna
46. Do not disturb Key/DND LED
47. Key
48. Microphone
49. DC IN 9V Jack
50. TEL LINE Jack
51. Charging Contacts
52. Charge LED
53. DC IN 9V Jack
51
52
53
Charger Base
Main Base
UP354BH(WDECT2355+2) OM 5/14/04 10:48 AM Page 2
Congratulations on your purchase of the Uniden Multi-Handset Cordless System telephone. This unit is
different from conventional cordless telephones. When the base unit is connected to AC power and a
telephone line, it can support up to 4 handsets. Using extra handsets, you can establish a 3-way conference
call (2 handsets and an outside line), while two other handsets are making an intercom call. You can now
place a fully featured cordless handset anywhere in your home or office where AC power is available to
connect the handset chargers.
Note: The illustrations in this manual are intended as a guide and may differ from actual unit.
WELCOME
[ 3 ]
To bring outstanding wireless communication products to people’s lives throughout the world.
UNIDEN COMPANY PHILOSOPHY
UP354BH(WDECT2355+2) OM 5/14/04 10:48 AM Page 3
[ 4 ]
Great features of this cordless phone include:
• Designed and Engineered in Japan
• Wide Band Digital Technology
• Multi (4) Handset Capable
• Digital Duplex Speakerphone on Handset
Advanced Alpha Display Caller ID Features:
• Alpha Memory Dialling
• POP ID - Caller Name Identification*
• 20 Individual Caller Allocations
• 100 Caller ID* Memories with Phonebook
• 3 Line Backlit Full Dot Matrix LCD Display with Clock
• Maxi-Sound - Extra Loud Handset Volume Control
• Intercom/Announce Call Transfer
• Handset Conferencing (2 Handsets + Outside Call)
• Two-Way Communication between Handsets Anywhere without the Base
• Dual Keypad at Base
• Integrated Answering Device
• DND Feature (Do Not Disturb)
• Remote Message Retrieval
• Personal or Factory Pre-recorded Greeting Message
• And More!
FEATURES
* Caller ID and POP ID features work only if you subscribe to the service provided by your local telephone company.
There is usually a fee for this service.
#Range may vary depending on environmental and/or topographical conditions.
UP354BH(WDECT2355+2) OM 5/14/04 10:48 AM Page 4
