U-Line H-1787 User manual
PAGE 1 OF 3 0421 IH-1787
H-1787
FOLDING HAND TRUCK
100 LB. CAPACITY
1-800-295-5510
uline.com
1. Position the truck as shown. (See Figure 1)
2. To extend handle, press top button and pull up
handle. (See Figure 2)
3. By pulling down the noseplate, both wheels will
automatically extend out. (See Figure 3)
4. Use bungee cord to secure cargo. (See Figure 4)
OPERATING INSTRUCTIONS
Figure 3
Figure 2
Figure 1
Figure 4
Para Español, vea página 2.
Pour le français, consulter la page 3.
PAGE 2 OF 3 0421 IH-1787
800-295-5510
uline.mx
DIABLITO PLEGABLE
45 KG (100 LBS)
DE CAPACIDAD
H-1787
1. Posicione el diablito como se indica. (Vea Diagrama 1)
2. Para extender el asa, presione el botón de la parte
de arriba y levante el asa. (Vea Diagrama 2)
3. Al bajar la placa, ambas llantas se extenderán
automáticamente. (Vea Diagrama 3)
4. Use la cuerda elástica para asegurar la carga.
(Vea Diagrama 4)
FUNCIONAMIENTO
Diagrama 3
Diagrama 2
Diagrama 1
Diagrama 4
PAGE 3 OF 3 0421 IH-1787
CHARIOT MANUEL REPLIABLE
CAPACITÉ DE 45KG (100LB)
1800295-5510
uline.ca
H-1787
1. Positionnez le chariot de la façon illustrée.
(Voir Figure1)
2. Pour déployer la poignée, appuyez sur le bouton
supérieur et soulevez la poignée. (Voir Figure2)
3. L'abaissement de la bavette déploiera
automatiquement les deux roues. (Voir Figure3)
4. Fixez la charge avec un tendeur élastique.
(Voir Figure4)
INSTRUCTIONS D'UTILISATION
Figure 3
Figure 2
Figure 1
Figure 4
