U-Line Combo CO29 User manual

Features Beneﬁts

8900 North 55th Street • Milwaukee, Wisconsin 53223 • Phone: 414-354-0300 • Fax: 414-354-7905

www.u-line.com

COMBO ICE MAKER/

REFRIGERATOR MODEL CO29

Capacity: 2.1 cubic feet of refrigeration;

approximate daily ice production 18 lbs/storage 13 lbs

Defrost Type: Manual Defrost

Colors: Black, White

Feature Benefit

High ice production and storage Produces up to 18 lbs of ice per day and stores 13 lbs

No drain required • Easy and inexpensive to install

• Only needs a 1/4" outside diameter water line

Conserves on water Only 2-1/4 gallons of water to produce approximately 18 lbs

of ice

Built-in or freestanding • Provides custom look

• No additional clearance around sides, top or rear for

ventilation. Do not obstruct the front grille.

Two tempered glass shelves • Generous amount of shelf space

• Contains spills, easy to clean

Door will accept a 1/4" panel Ability to match surrounding décor and cabinets

Field-reversible door Flexible installation options

Integrated door handle Will not add depth to cabinet when built-in

In-door storage 2-1/2 shelves provide easy access.

Adjustable dial temperature

control

Ability to adjust the refrigerator temperature

Vinyl-clad cabinet Textured, rich look. More resistant to scratching, peeling or

flaking

Flat recessed grille Blends with the other Origins models and integrates with

surrounding cabinetry

imensions Speciﬁcations

8900 North 55th Street • Milwaukee, Wisconsin 53223

Phone: 414-354-0300 • Fax: 414-354-7905 • www.u-line.com

Combo Ice Maker/Refrigerator Model CO29

Specifications Capacities

(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.

Optional in 220/230 voltage 50/60 Hz.

On 220 volt models, amps are decreased by approximately 50 percent.

For left-hand hinged door allow 145° door opening to remove the ice bucket.

Please visit www.U-Line.com for Installation Guide.

All specifications subject to change without notice.

*ON BACK OF UNIT INCHES (CENTIMETERS)

20-13/16

(52.9)

*WATER LINE

*POWER

CORD

3-5/16

(8.4)

3-5/16

(8.4) 1-7/16

(3.7)

1-9/16

(4)

28-1/2

(72.4)

4-1/2

(11.4)

WATER INLET VALVE

(61)

21-7/16

(54.5)

Shipping Weight: 97 lbs (44 kg)

(1) Running Amps 2.5

(1) Maximum Start-up Amps 18.0

Refrigerator volume 2.1 cubic

feet

Freezer volume N/A

Approximate daily ice production Up to 18 lbs

Ice storage 13 lbs
