Troy-Bilt 31AS6BN2711 Guide

IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND

FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .

Read and understand all instruction, warning and danger labels.

Need Help? Call 1-888-TO-HELP-U (1-888-864-3578)

Chute

Chute Control Rod

Wing Knobs

778-10555A© 2005 31AS6BN2711

Tighten wing knobs.

Pivot handle upward.

Remove ﬂat washer and hairpin clip.

Insert chute control rod into bracket as

shown. Secure with washer and clip.

Place chute over base and close ﬂange keepers (3).

Keepers will click into place when properly secured.

IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND

FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .

Read and understand all instruction, warning and danger labels.

Call 1-888-TO-HELP-U

Need Help?

(1-888-864-3578)

5

6

7

8

9

Gas Cap

Primer

Throttle

Key

Choke

10

Start

Button

Switch Outlet

Connect power cord to switch outlet on engine.

Fill tank with gas to within 1/2 inch of top of tank.

Check oil level and ﬁll if necessary.

Push key into ignition slot. Be sure

ignition key snaps into place.

Rotate choke control to full choke position. Push primer three times.

Move throttle control to fast (rabbit) position.

Press down on starter button for no more than

ﬁve seconds to start engine. Disconnect power

cord and move choke control to off after starting.

Do not turn key.

Oil
