TRONXY X5SA-500-PRO User manual
Thank you for choosing TRONXY products!
We will serve you whole heartedly!
Please read the instruction carefully
Please visit tronxy.com for more information
TEL：+86-755-89968500
Relevant information is stored in
SD card,please check
After- sale service：support@tronxy.com
Service nach dem Verkauf: support@tronxy.com
アフターサービス：support@tronxy.com
Послепродажное обслуживание: support@tronxy.com
Facebook QR CodeX5SA-500Pro Install
video QR Code
Aftersale contact
QR Code
Servicio postventa: support@tronxy.com
Serviço pós-venda: support@tronxy.com
판매 후 서비스 : support@tronxy.com
بع دعيبلا ：support@tronxy.com
Pay attention
Please read this instruction carefully and follow the
safety instruction.
When the 3D printer is working, it will produce high temperature.Do not
touch working parts or extruder directly.After printing, the working part
may still be in the high temperature state.Please wait patiently for the
working parts and the print model to cool down before removing the model
from the print platform.
Please use the 3D printer in a spacious and well-ventilated
environment.
The recommended ambient temperature for 3D printers is
8°C-40°C, and the humidity is 20%-80%. Using outside this
range may bring bad printing effects.
In case of emergency, could turn off the power of the
3D printer directly.
3D printers contain working parts that move at high
speeds, so be wary of pinching your hands.
When removing the model from the print platform, be careful
not to swipe sharp objects at your finger.
Assemble the 3D printer or polish the model. suggest Wear
goggles.
Please pay attention to the protection of 3D printer
against rain and moisture.
Keep children away from the machine when it running
It is not recommended to run a 3D printer when left
unattended.
Use wires must be connected to the earth
Catalogue
1. Machine parameter ………………………………………1
2. Introduction to machine structure …………………2
3. Packing list ……………………………………………………3
4. Installation instructions …………………………………4
5. Interface operation and printing …………………17
6. Slice software ………………………………………………20
7. Fault cause analysis ………………………………………23
Print parameters
Print principle
: FDM (Fused deposition molding)
Print size
: 500×500×600 (mm3)
Print accuracy
: 0.1-0.4 mm
Positioning accuracy
:X/Y0.00625mm，Z 0.0125mm
Nozzle quantity
: 1
Nozzle size
: 0.4 mm
Print speed
: 20~100mm/s (suggest 60mm/s)
Moving speed
: 100mm/s
Filament
: PLA, TPU, ABS, wood etc.
Temperature parameters
Environmental temp:
8°C - 40°C
Nozzle temp:
Max260℃
Heat bed temp:
support
Software
Slice software:
Cura
Input format:
.STL .OBJ
Output format:
GCode
Connection:
TF card, USB cable(Suitable for skilled users
)
Power supply
Power input:
110V/220V AC, 50/60Hz
Power output
：24V/21A DC
Physical parameter
Machine size:
810mm×812mm×915mm
Machine weight:
~28.5kg
1. Machine parameter
1
2. Introduction to machine structure
④
⑤
①
②
③
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑮
⑭
⑯⑰
⑱
⑲
⑳㉑
2
1.Power Supply 2.Stainless steel pipe 3.Heatbed 4.Y axis switch
6.Y-right guide rail
5.Y- right skateboard 7.Xmotor
9. Y-left guide rail 10.Y- right skateboard 11. extruder head
13.lead screw
12.polish rod
14.Z2motor 16.power switch
17.Z1motor 18.TF interface 19.USB interface
15.aluminum frame
20.Titan extruder
21.filament run-out detection
8.Ymotor
3. Packing list
2
040
aluminum
profile
630mm 2PCS
660mm 2PCS
2020aluminum
profile
740mm 2PCS
4040aluminum profile
780mm 4PCS
Stainless steel pole
2PCS
OSG External double
axis guide rail
-Y
axis
670mm 2PCS
OSG External double
axis guide rail
-X
axis
650mm 1PCS
beams/footlock
2pcs
left and right
sliding parts
polished rod
760MM 4PCS
lead screws
665MM 2PCS
left /right belt pulley
parts X/Y axis motors
Zaxis motor
parts
Titan extruder
component bag
controller + touch
screen belt bag
filament
+seal
（
Color random
）
Power Supply
print head
aluminum plate with
balck sticker heat bed
screws bag 4PCS
Corner code bag
1PCS
shovel
（
Color
random）
USB cable+ power line
Tools bag reader+TFcard
Yswitch parts
1PCS
filament run out
detection parts
1PCS
Double limit plate
2pcs
3
After receiving the goods, please
check the accessories according to
the packing list. If you have any
questions, please contact customer
service.
4. Installation instructions
Step 1：base frame assembly
Assembly material specification and quantity
：
aluminum1
40*40*780 4PCS
aluminum2
40*20*660 2PCS
aluminum3
40*20*630 2PCS
Corner code
20PCS
screws M4*8
40PCS
gasket M4
40PCS
boat nuts M4
40PCS
screws M5*45
8PCS
12-aluminum1
4
1-aluminum2
M5*45
M5*45
2-aluminum3
Four countersunk
holes facing upward
on the surface
M4*8 M4 gasket boat nuts
Corner codes can be installed with
20 standby codes at a time
32-aluminum1
M5*45
M5*45
2
Note:
Installation
corner codes
should be kept
parallel and
vertical between
each aluminium
profile without
clearance.
Adjustment of
M5*45 can be
loosened slightly
before locking.
Slightly lock M5*45 screw for
easy follow-up adjustment
M6 threaded
hole Upward
M6 threaded hole
Upward
M6 threaded
hole Upward
M6 threaded hole
Upward
Installation corner codes in the connection of aluminium
profiles, it is necessary to keep the vertical and parallel
locking angle codes between the various aluminium
profiles.
The first step is to install the frame. After the
installation, the frame is assembled with the
second step, as shown in the figure.
Assembly material specification and quantity
：
base frame
1pcs
aluminum4
20*20*740 2PCS
L skateboard 1PCS
Y left guide 1PCS
R
skateboard
1PCS
Y right guide 1PCS
screwsM6*25
16PCS
Step 2: Sliding plate assembly
Take out the Y-axis guide rail and penetrate into
the left component and the right component of
the slide, respectively, as shown in the figure.
1The screw M6*25 is slightly locked on the Y-axis
guide rail to facilitate subsequent adjustment.
Direction Reference
Point for Installation
of Guideway
5
2aluminum
4
8-M6*25
Note: The installation position of Aluminum
Profile 4 and the bottom Aluminum Profile 3 (with
countersunk head holes) are in the vertical
direction. Do not misfit them.
2
Note: The left and right skateboards
penetrate the guide rail.
Please install in the right direction
according to the drawing.
(Refer to Y-axis guideway bag
Letters, L to L, R to R)
38-M6*25
When installing Y-axis guide to the frame, please
note that M4 screw holes are in the same direction,
and use this to determine the front of the 3D printer.
M4 screw
hole
Aluminum profile 4 aligns bottom frame, slightly
locking M6*25 screw, no locking is needed to
facilitate subsequent adjustment and installation.
