Tripp Lite TRAVELERC8 User manual
2 (C8) 2-prong connectors, in-line surge with
Tel/Modem/Ethernet Protection - Protect It! Surge
Suppressor
MODEL NUMBER: TRAVELERC8
Description
Tripp Lite's Traveler In-Line surge suppressor features a 306 joule rating to handle even the strongest surges.
In-line design, over current protection and 120/240V compatibility make this surge suppressor ideal for notebook
computers and PDAs. Integrated phone line protection allows you to safeguard tel/modem and AC connections with a single unit. "Protected" LED lets you
instantly know whether your wall jacks have potentially damaging signals. $50,000 Ultimate Lifetime Insurance (USA and Canada Only).
CONNECTORS: interfaces with C8 (2 conductor laptop type) cabling
ELECTRICAL: 120V and 240V AC, 50/60Hz
FORMAT: In-line design that puts surge protection between your notebook computer or PDAs' power adapter and the power cord leading to the wall outlet
SUPPRESSION: AC: 150V RMS Clamping/306 joules/900V UL1449 3rd Edition let-through rating
Features
In-line design places AC line surge protection between your notebook computer or PDAs' power adapter and the power cord leading to the wall outlet
120/240V compatibility operates on voltage worldwide, automatically switching between 120V or 240V AC power
Surge suppression rating: 306 joules
Includes two 2-prong (C8) connectors
Built-in LED confirms suppressor "protection present" (green)
1 line in/1 line out tel/modem/Ethernet combo
Single small push-button switch activates overcurrent detection circuit
$50,000 Ultimate Lifetime Insurance (USA and Canada Only) covers connected equipment
Specifications
Highlights
120V/240V compatible
306 joule rating Two 2-prong
(C8) connectors
1 in/1 out tel/modem/Ethernet
combo in-line design
Retractable Ethernet cable
Diagnostic LED
$50,000 Ultimate Lifetime
Insurance (USA, Puerto Rico &
Canada only)
Applications
Ideal for notebook computers,
PDAs or other electronics
requiring AC and tel/modem
safeguarding
Package Includes
TRAVELERC8 surge suppressor
Instruction manual with warranty
information
1 / 3
OVERVIEW
Intended Application Home/Office, Travel
OUTPUT
Frequency compatibility 50 / 60 Hz
Outlet quantity / type 2 (C8) 2-prong connectors
INPUT
Nominal Input Voltage(s) Supported 120V AC; 230V AC
Recommended Electrical Service 120V (110-125V), 230V (220-250V)
Input connection type Two 2-prong (C8) connectors
Input cord length details In-line
Voltage compatibility (VAC) 120; 230
Maximum Surge Amps 12000
LEDS ALARMS & SWITCHES
Switches Single small push-button switch activates over-current detection circuit
Diagnostic LEDs Built-in LED confirms suppressor "protection present" (green)
SURGE / NOISE SUPPRESSION
AC suppression joule rating 306
AC suppression response time < 1 ns
Clamping voltage (RMS) 150
UL1449 let through rating 900V - UL Verified
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection Yes
Telephone/DSL Protection Details 1 line
Cable (Coax) Protection No
Network (Ethernet) Protection Yes
PHYSICAL
Shipping Dimensions (HWD/in) 8.66 x 5.93 x 1.83
Shipping Dimensions (HWD/cm) 21.99 x 15.06 x 4.65
Unit Dimensions (HWD/in) 3.54 x 2.56 x 1.5
Unit Dimensions (HWD/cm) 8.99 x 6.5 x 3.81
2 / 3
Unit weight (lbs) .3
Unit weight (kg) 0.136
Material of construction Plastic
Style InLine
Form factors supported In-line
SPECIAL FEATURES
Appearance Ultra-compact portable in-line protector in an attractive, all black lightweight enclosure
CERTIFICATIONS
UL1449 3rd Edition (AC
Suppression) UL1449 3rd Edition
UL497A (Communications) UL497A
FCC Part 68 (Communications) FCC Part 68
WARRANTY
Product Warranty Period (Worldwide) Lifetime limited warranty
Connected Equipment Insurance
(U.S., Canada & Puerto Rico) $50,000 Ultimate Lifetime Insurance
© 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos may differ slightly from final products.
3 / 3
