Tripp Lite TLP1008TELTV User manual
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: TLP1008TELTV
Protect It! Surge Suppressor
Highlights
10 outlets / 8-ft. cord
1 in/2 out tel/modem surge protection
1 in/1 out coaxial surge protection
3345 joule rating
$150,000 Ultimate Lifetime Insurance (USA & Canada only)
Description
Tripp Lite's TLP1008TELTV offers economical AC surge suppression for protection of workstations, PCs, telecom systems, home electronics and
other sensitive equipment. The TLP1008TLTV features 10 outlets, an 8-ft. cord with a space-saving right-angle plug, and diagnostic LEDs to warn of
suppressor damage. The unit has a surge suppression rating of 3345 joules to shield equipment from line noise and the strongest surges. Built-in
RJ11 jacks prevent surges from damaging your modem/fax/phone equipment. Built-in coax jacks prevent surges from damaging your cable/satellite
equipment. $150,000 Ultimate Lifetime Insurance (USA & Canada only)
PLUG/OUTLETS: Input: NEMA5-15P/Output: 10 NEMA5-15R/8-ft. AC line cord
ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA5-15R wall receptacle)
FORMAT: Corded multi-outlet strip with 5 transformer-spaced outlet
SUPPRESSION: AC: 150V RMS Clamping/3345 joules/330V UL1449
Applications
Ideal for protecting TVs, DVDs, satellites, stereos and other entertainment systems
Package Includes
TLP1008TELTV surge suppressor
6-ft. RJ11 cable
1 set nickel-plated coax connectors
Instruction manual and warranty information
Features
10 outlets with child safety covers
8-ft. cord with space-saving right-angle plug
Built-in RJ11 jacks prevent surges from damaging your modem/fax/phone equipment built-in splitter protects two devices sharing a single
line; 6-ft. telephone cord included
Surge suppression rating: 3345 joule protection
EMI/RFI noise filtering
15 amp resettable circuit breaker
Diagnostic LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
Includes full normal mode (H-N) and common mode (N-G/H-G) line surge suppression
Can accommodate up to 5 transformers without blocking remaining outlets
Built-in coax jacks prevent surges from damaging your cable/satellite equipment; 6-ft. coax cable included
Keyhole supports for wall mounting
$150,000 Ultimate Lifetime Insurance (USA & Canada only) covers connected equipment
Failsafe shutdown mode
Lighted power switch
Lifetime product warranty
Specifications
OVERVIEW
Intended Application Home/Office, Audio/Video
SYSTEM OVERVIEW
Voltage compatibility 120 V AC
Frequency compatibility 50/60 Hz
OUTPUT
Output volt amp capacity
(amps)
15
Output watts 1800
Outlet quantity / type 10 NEMA 5-15R
Outlet orientation Two rows of outlets, including 5 widely spaced for transformers
Overload protection 15A resettable circuit breaker
Outlet safety covers Includes built-in sliding outlet safety covers
Transformer accommodation Supports 5 large transformer plug accessories without covering remaining outlets, accepts up to 8 transformers
total
INPUT
Input connection type NEMA 5-15P
Input cord gauge, type 14 gauge, SJT
Input cord length (ft.) 8 ft.
Input cord length (m) 2.4
Recommended Electrical
Service
120V (110-125V)
Input plug features Space-saving right angle input plug
LEDS ALARMS & SWITCHES
Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
Switches Two-position on/off power switch
SURGE / NOISE SUPPRESSION
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
AC suppression joule rating 3345 joules
Clamping voltage (RMS) 150V
AC suppression response
time
< 1 ns
UL1499 let through rating 330V - UL Verified
EMI / RFI filtering Up to 40dB
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection Yes
Telephone/DSL Protection
Details
1 line
Cable (Coax) Protection Yes
Cable (Coax) Protection
Details
1 line
Network (Ethernet) Protection No
PHYSICAL
Shipping Dimensions
(HWD/in)
14.75 x 7.75 x 2.3
Shipping Dimensions
(HWD/cm)
37.5 x 19.7 x 5.8
Unit weight (lbs) 2.2
Unit weight (kg) 1.0
Unit Dimensions (HWD/in) 11.6 x 5 x 2.25
Unit Dimensions (HWD/cm) 29.5 x 12.7 x 6.5
Material of construction Plastic
Integrated keyhole mounting
tabs
Keyhole mounting tabs enable wall mounting
AC line cord color Black
Style Strip
CERTIFICATIONS
UL1449 1998 Rev. (AC
Suppression)
UL1449
UL1363 (Power Tap) UL1363
UL497A (Communications) UL497A
FCC Part 68
(Communications)
FCC Part 68
cUL / CSA (Canada) cUL
Industry Canada
(Communications)
Industry Canada
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty Period Lifetime
Connected Equipment
Coverage
$150,000
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=2635.
©2009 Tripp Lite. All Rights Reserved.
