Tripp Lite TLM626TEL15 User manual
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: TLM626TEL15
Protect It! Surge Suppressor
Highlights
6 right-angle outlets / 15 ft. cord
1208 joule rating
Tel/DSL surge protection (1 line)
$75,000 Ultimate Lifetime Insurance (USA & Canada only)
Description
Tripp Lite's TLM626TEL15 surge suppressor offers complete AC and Tel/DSL line surge suppression for comprehensive protection of workstations,
personal computers, home stereos, televisions, VCRs, DVD players and other sensitive electronics. Heavy grade AC surge suppression shields
connected equipment from damage and performance problems due to transient surges. Set of RJ-11 telephone line suppression jacks protect a
single dialup modem, DSL modem, fax or phone line. TLM626TEL15 offers 6 right-angle outlets, a 15 foot power cord and diagnostic LEDs to warn
of wiring problems and suppressor damage. AC surge suppression rated at 1208 joules shields equipment from surges and line noise. Rugged metal
housing with 2 designated transformer plug outlets offers convenient protection of desktop computer equipment and accessories. Lifetime warranty
with $75,000 Ultimate Lifetime Insurance (USA & Canada Only).
PLUG/OUTLETS: Input - 15 ft. AC line cord with NEMA 5-15P plug/Output - 6 NEMA 5-15R right-angle outlets
ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA 5-15R wall receptacle)
FORMAT: Metal strip
SUPPRESSION: AC: 150V RMS Clamping/1208 joules/330V UL1449
Applications
Ideal for personal computers, TV/VCR/DVD, stereos and lamps/lighting
Package Includes
TLM626TEL15 surge suppressor
6 ft. RJ-11 phone cord
Instruction manual and warranty information
Features
6 right-angle outlets
15 ft. cord
Built-in RJ-11 jacks prevent surges from damaging your telephone/DSL/modem/fax equipment; 6 ft. telephone cord included
Surge suppression rating: 1208 joules
EMI/RFI noise filtering
15 amp resettable circuit breaker protects against overload
Diagnostic LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
Convenient keyhole slots allow secure mounting on wall or desk
Can accommodate up to 2 transformers without blocking adjacent outlets
Rugged metal case provides extra safety and durability
Illuminated power switch
$75,000 Ultimate Lifetime Insurance (USA & Canada Only) covers connected equipment
Lifetime product warranty
Specifications
OVERVIEW
Intended Application Home/Office
SYSTEM OVERVIEW
Voltage compatibility 120V AC
Frequency compatibility 50/60 Hz
OUTPUT
Output volt amp capacity
(amps)
15
Output watts 1800
Outlet quantity / type 6 NEMA 5-15R
Outlet orientation Single row of outlets
Overload protection 15A resettable combo switch / circuit breaker
Transformer accommodation Supports 2 large transformers without covering adjacent outlets
INPUT
Input connection type NEMA 5-15P
Input cord gauge, type 14 gauge, SJT
Input cord length (ft.) 15 ft.
Input cord length (m) 4.5
Recommended Electrical
Service
120V (110-125V)
LEDS ALARMS & SWITCHES
Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
Switches Combination AC circuit breaker and 2 position on/off power switch
SURGE / NOISE SUPPRESSION
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
AC suppression joule rating 1208 joules
Clamping voltage (RMS) 150V
AC suppression response
time
< 1 ns
UL1499 let through rating 330V - UL Verified
EMI / RFI filtering Up to 20dB
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection Yes
Telephone/DSL Protection
Details
1 line
Cable (Coax) Protection No
Network (Ethernet) Protection No
PHYSICAL
Shipping weight (lbs) 2.5
Shipping weight (kg) 1.1
Shipping Dimensions
(HWD/in)
2.25 x 15 x 6
Shipping Dimensions
(HWD/cm)
5.7 x 38.1 x 15.2
Unit weight (lbs) 1.8
Unit weight (kg) .8
Unit Dimensions (HWD/in) 1.5 x 12.25 x 2.25
Unit Dimensions (HWD/cm) 3.8 x 31.1 x 5.7
Material of construction Metal
Form factors supported Supports floor / wall / desktop placement
Integrated keyhole mounting
tabs
Keyhole slots enable mounting to a variety of surfaces
Receptacle Color Light Gray
AC line cord color Black
Style Strip
CERTIFICATIONS
Additional International
Approvals
Complies with RoHS (Restriction of Hazardous Substances Directive)
UL1449 1998 Rev. (AC
Suppression)
UL1449
UL1363 (Power Tap) UL1363
FCC Part 68
(Communications)
FCC Part 68
cUL / CSA (Canada) cUL
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty Period Lifetime
Connected Equipment
Coverage
$75,000
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3295.
©2009 Tripp Lite. All Rights Reserved.
