Tripp Lite N302-010 User manual

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: N302-010

3M (10-ft.) Duplex MMF 62.5/125 Patch Cable (ST/ST)

Highlights

Premium PVC 62.5/125µm multimode patch cables

Attenuation loss meets or exceeds the latest industry standards

Loop-back cables provide an easier, "single-person" solution for testing fiber

optic cable systems

Description

Tripp Lite's 10-ft. multimode duplex fiber optic ST/ST patch cable is manufactured from 62.5/125 zipcord fiber. The cable has ST connectors on each

end, a PVC jacket and is FDDI and OFNR rated. Duplex multimode fiber is most commonly used in LAN applications.

System Requirements

Any fiber optic hardware or NIC card requiring multimode duplex cable with ST/ST connectors

Package Includes

10-ft. duplex MMF cable ST/ST 62.5/125 fiber

Features

Manufactured from 62.5/125 duplex (zipcord) fiber

PVC jacket

Length: 10-ft. Connectors: 2 ST connectors on each end

Insertion loss testing performed on every connector (0.2db typical) and provided with cable

Beveled edge on ends of glass makes insertion of plug a breeze

Fiber made from glass (not a polymer)

Color coded shrouds identify transmit and receive

Duplex multimode fiber is most commonly used in LAN applications where links are typically 10 feet or less

Fiber optic distributed data interface (FDDI) rated

OFNR (riser rated)

Specifications

OVERVIEW

Intended Application Computer Networking (Fiber)

INPUT

Cable Length (ft.) 10

Cable Length (m) 3.05

PHYSICAL

Color Orange

Style Fiber Optic

CONNECTIONS

Connector A

Connector B

CERTIFICATIONS

Certifications RoHS-Compliant

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Fiber Optic Cables &

Adapters

N302-003 1M (3-ft.) Duplex MMF 62.5/125 Patch Cable

(ST/ST)

Fiber Optic Cables &

Adapters

N302-006 2M (6-ft.) Duplex MMF 62.5/125 Patch Cable

(ST/ST)

Fiber Optic Cables &

Adapters

N304-010 3M (10-ft.) Duplex MMF 62.5/125 Patch Cable

(SC/ST)

Fiber Optic Cables &

Adapters

N306-010 3M (10-ft.) Duplex MMF 62.5/125 Patch Cable

(SC/SC)

Fiber Optic Cables &

Adapters

N308-010 3M (10-ft.) Duplex MMF 62.5/125 Patch Cable

(MTRJ/ST)

Fiber Optic Cables &

Adapters

N310-010 3M (10-ft.) Duplex MMF 62.5/125 Patch Cable

(MTRJ/SC)

Fiber Optic Cables &

Adapters

N314-03M 3M (10-ft.) Duplex MMF 62.5/125 Patch Cable

(MTRJ/LC)

Fiber Optic Cables &

Adapters

N316-03M 3M (10-ft.) Duplex MMF 62.5/125 Patch Cable

(LC/SC)

Fiber Optic Cables &

Adapters

N318-03M 3M (10-ft.) Duplex MMF 62.5/125 Patch Cable

(LC/ST)

Fiber Optic Cables &

Adapters

N320-03M 3M (10-ft.) Duplex MMF 62.5/125 Patch Cable

(LC/LC)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2162.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
