HDMI-104-70
Beijing Tricolor Technology Co., Ltd - 4 - www.chinargb.com.cn/en
Introduction
About the HDMI-104-70
The HDMI-104-70 is a 4K HDBaseT Extender with Excellent performance and
flexibility. It features the can send HDMI, audio, and bidirectional RS232 and IR
signals up to 230ft/70m over a single Cat6/6a cable. It provides an economical and
effective way for extending HDMI 4K ultra HD with embedded multi-channel audio
from HDMI sources. In addition, both transmitter and receiver can send power
over cable to the other end. The compact enclosure size and remote power
capability make HDMI-104 ideal for discreet placement behind flat-panel displays,
or wherever needed to meet installation requirements. It can make your home or
office set up more efficient and easy to use.
Features
Proven HDBaseTTM technology offering uncompromised video quality and
reliability.
Extends 1080P up to 230ft/70m over a single CAT6/6a cable — shielded cable
recommended
Extends 4K UHD up to 131ft/40m (3840x2160 @ 30Hz 4:4:4, 4096x2160 @
24Hz 4:4:4, and 4K @ 60Hz 4:2:0).
Supports all industry standard video resolutions including VGA-WUXGA and
480i-4K.
HDCP2.2 compliant.
Support all known HDMI audio formats including Dolby TrueHD, Dolby Atmos,
Dolby Digital Plus and DTS-HD Master Audio.
Remote power capability - only one external power supply is needed.
EDID and HDCP pass through.
CEC pass through.
Two-way RS232 and IR communication.
Supplied with wideband 30-60KHz infrared cables as full kit.
