Tricity Bendix SIE504 Specification sheet

MODEL NO.

SIE504

OPERATING AND INSTALLATION INSTRUCTIONS

MODEL NO. SIE 504

Voltage: 230/240 Volts AC 50Hz

Wattage: 10.2/11.1 kW

Height: 900mm

Width: 600mm

Depth: 598mm

Weight 65 kg

This appliance complies with: European Council Directive 73/23/EEC.

EMC Directive 89/336/EEC.

CE Marking Directive 93/68/EEC

TECHNICAL DETAILS

Technical Details .................................................................................................................................... 2

Contents ................................................................................................................................................. 3

Preface .................................................................................................................................................... 5

Safety ...................................................................................................................................................... 6

Before Installation .......................................................................................................................... 6

During Operation ............................................................................................................................ 6

After Use ........................................................................................................................................ 7

General ........................................................................................................................................... 7

Introduction ............................................................................................................................................ 8

Rating Plate .................................................................................................................................... 8

Installation ...................................................................................................................................... 8

General Notes on Using Your Appliance ....................................................................................... 9

About Condensation and Steam .................................................................................................... 9

The Cooling Fan for the Controls ................................................................................................... 9

Control Panel Indicator Neons ....................................................................................................... 9

Cookware ....................................................................................................................................... 9

Grill and Oven Furniture ................................................................................................................. 10

Getting to Know Your Appliance .......................................................................................................... 11

The Control Panel .......................................................................................................................... 11

The Electronic Minute Minder ......................................................................................................... 12

The Ceramic Hob ................................................................................................................................... 14

Recommended Saucepans ............................................................................................................14

Hints and Tips ................................................................................................................................ 14

Deep Fat Frying ...................................................................................................................................... 15

Preserving .............................................................................................................................................. 15

The Grill .................................................................................................................................................. 16

Uses of the Grill .............................................................................................................................. 16

Selecting the Grill ........................................................................................................................... 16

Things to Note ................................................................................................................................ 16

The Grill Pan and Handle ............................................................................................................... 16

Hints and Tips ................................................................................................................................ 17

Grilling Chart .................................................................................................................................. 17

The Fan Oven ......................................................................................................................................... 18

Uses of the Fan Oven .................................................................................................................... 18

Selecting the Top Oven .................................................................................................................. 18

Things to Note ................................................................................................................................ 18

To Fit the Oven Shelves ................................................................................................................. 18

Hints and Tips ................................................................................................................................ 19

Oven Cooking Chart .............................................................................................................................. 20

Roasting Chart ....................................................................................................................................... 21

CONTENTS

Defrosting ............................................................................................................................................... 22

Uses of Defrost Feature ................................................................................................................. 22

Selecting Defrost ............................................................................................................................ 22

Things to Note ................................................................................................................................ 22

Hints and Tips ................................................................................................................................ 22

Care and Cleaning ................................................................................................................................. 23

Cleaning Materials ......................................................................................................................... 23

Cleaning the Ceramic Hob ............................................................................................................. 23

Hints and Tips ................................................................................................................................ 24

Cleaning the Outside of the Appliance ........................................................................................... 24

Cleaning the Grill and Oven Furniture ........................................................................................... 24

Cleaning Inside the Oven and Grill Compartments ........................................................................ 25

Care of Stayclean Surfaces ........................................................................................................... 25

Hints and Tips ................................................................................................................................ 25

Cleaning the Door Glass ................................................................................................................ 25

Replacing the Oven Light Bulb .......................................................................................................26

Something not Working? ...................................................................................................................... 27

Service and Spare Parts ........................................................................................................................ 28

Guarantee Conditions ........................................................................................................................... 29

CONTENTS

Dear Customer,

Thank you for buying a Tricity Bendix appliance. With our 80 years experience in

developing and manufacturing the very best in U.K. appliances, you can be

assured that you have purchased a hard working, reliable, quality product.

Tricity Bendix appliances comply with British Standard safety and performance

requirements. They have been approved by BEAB (British Electrotechnical

Approvals Board) and are covered by a 12 month parts and labour guarantee.

To get the best from your new Tricity Bendix appliance, we ask that you PLEASE

READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made

to cooking times and temperatures, which may differ from your previous appliance.

It is most important that this instruction book is retained with the appliance for

future reference. Should the appliance be sold, or if you move house and leave

the appliance, always ensure that the book remains with the appliance. This will

enable the new owner to be acquainted with the functioning of the appliance and

the relevant warnings.

Please read the whole instruction book before attempting to use the appliance

ensuring you follow the recommendations given.

PREFACE

THESE WARNINGS ARE PROVIDED IN

THE INTERESTS OF YOUR SAFETY.

ENSURE THAT YOU UNDERSTAND

THEM ALL BEFORE INSTALLING OR

USING THE APPLIANCE.

PLEASE

READ

CAREFULLY

BEFORE INSTALLATION

This appliance is heavy and care

must be taken when moving it.

Ensure that all packaging, both

inside and outside the appliance has

been removed before the appliance

is used.

Iftheapplianceistobeplacedona

base, measures must be taken to

prevent the appliance slipping from

the base.

Do not try to lift or move the

appliance by pulling the door

handles.

The electrical installation work must

be undertaken by a qualified

electrician/competent person.

It is dangerous to alter or modify the

specifications of the appliance in any

way.

Do not use the appliance if the

ceramic glass is damaged. If a fault

or crack becomes visible during

cooking, disconnect the appliance

immediately from the electricity

supply and contact your local Service

Force Centre.

Do not place foil or plastic containers

on ceramic glass.

Do not allow young children to play

with any part of the packaging.

After installation, please dispose of

the packaging with due regard to

safety and the environment, your

local authority can arrange this.

DURING OPERATION

Do not use this appliance if it is in

contact with water. Never operate it

with wet hands.

This appliance is designed to be

operated by adults. Young children

must not be allowed to tamper with

the appliance or play with the

controls.

During use the appliance becomes

Hot. Care should be taken to avoid

touching the heating elements inside

the oven.

CAUTION: Accessible parts may

be hot when the grill is in use.

Young children should be kept

away.

Take great care when heating fats

and oils, as they will ignite if they

become too hot.

This appliance has been designed for

cooking edible foodstuffs only, and

must not be used for any other

purposes.

Never place plastic or any other

material which may melt in the oven

or on the hob.

Ensure cooking utensils are large

enough to contain foods to prevent

spillages and boil overs.

The handles of saucepans which are

smaller than the heated area on the

hob will become hot. Ensure your

hand is protected before handling the

pan.

SAFETY

Take care to follow the

recommendations given for tending

the food when grilling.

Ensure that you support the grill pan

when it is in the withdrawn or partially

withdrawn position.

Ensure that all vents are left

unobstructed to ensure ventilation of

theovencavity.

Ensure the anti-tilt shelves are put in

place correctly. Refer to instructions

on page 18.

Never line any part of the appliance

with foil. Do not allow heatproof

cooking materials e.g. roasting bags,

to come into contact with oven

elements.

Always stand back from the

appliance when opening the oven

door to allow any build up of steam or

heat to release.

Never leave the appliance

unattended when the oven door is

open.

Do not place sealed cans or

aerosols inside the oven. They may

explode if they are heated.

Do not leave the hotplates switched

ON for long periods when not

covered by a saucepan. The

controls may overheat.

AFTER USE

Ensure that all control knobs are in

the OFF position when not in use.

For hygiene and safety reasons

this appliance should be kept

clean at all times. A build-up of

fats or other foodstuffs could

result in a fire, especially in the

grill pan.

Do not leave utensils containing

foodstuffs, e.g. fat or oil in or on the

appliance in case it is inadvertently

switched on.

Cookers and hobs become very hot,

and retain their heat for a long period

of time after use. Children should be

kept well away from the appliance

until it has cooled.

GENERAL Under no circumstances should

any repairs be carried out by an

inexperienced person as this may

cause injury or serious malfunction.

This appliance should be serviced by

an authorised service Engineer and

only genuine-approved spare parts

should be used. Details of repair and

servicing arrangements are supplied

on page 28 of this book.

Do not stand on the appliance or on

the open oven door.

Do not hang towels, dishcloths or

clothes from the appliance or its

handle. They are a safety hazard.

Always allow the cooling fan to cool

the appliance down before switching

off at the wall prior to carrying out

any cleaning or maintenance work.

Only clean this appliance in

accordance with the instructions

given in this book.

Extreme care must be taken when

using a ceramic hob scraper.

Your safety is of paramount importance.

Therefore, if you are unsure about any of

the meanings of these WARNINGS contact

the:

Customer Care Department

Telephone 0870 5 950950

WARNING: THIS APPLIANCE MUST BE EARTHED

RATING PLATE

This is situated on the front frame of the appliance

and can be seen upon opening the top cavity door.

Alternatively the rating plate may also be found on

the back or top of some models (where applicable).

The appliance must be protected by a suitably

rated fuse or circuit breaker. The rating of the

appliance is given on the rating plate.

Do not remove the rating plate from the

appliance as this may invalidate the guarantee.

INSTALLATION

If your appliance has been damaged in transit,

contact your supplier immediately. DO NOT

attempt to install it.

Your appliance left the factory fully packaged to

protect it from damage. If it is delivered without

packaging and damage has occurred, the

manufacturer cannot accept responsibility. Contact

you supplier for advice.

Once the packaging has been removed the

appliance should only be moved by hand. DO

NOT use a sack barrow or any other aid to lift the

appliance as damage may occur.

Connection to the electricity supply must be carried

out by a qualified electrician/competent person.

The electrical connection should be made using a

double pole isolating switch (cooker socket) with at

least 3mm contact separation in all poles. The

cable must have conductors of sufficiently high

cross-sectional area to prevent overheating and

deterioration.

Six square millimetres (6.00mm2)isthe

recommended cross-section area.

The cable must be routed away from potentially hot

areas marked by X in the diagram below.

To move the appliance, open the oven door, and

lift the appliance by holding inside the top of the

compartment.

This is a type Y appliance which means it is free-

standing and can be fitted with cabinets on one or

both sides. It may also be fitted in a corner setting.

Ensure that the appliance is standing level.

Side walls which are above hob level should be

protected by heat resistant non-combustible

material and MUST NOT be nearer than 40mm to

the hob side.

A nominal air gap of 2mm all around the appliance

is required to enable the appliance to be moved

into position.

Always ensure an air gap is maintained at hotplate

level. Tiles or other forms of deep wall covering

should not obscure this gap.

INTRODUCTION

REAR VIEW

Air gap

Note: Vapours from the oven vents may in time

cause discolouration of wallcoverings behind the

appliance. For ease of cleaning it may be

preferable to tile behind the appliance.

Overhanging surfaces or a cooker hood should be

a minimum of 685mm above the hob.

It is important to ensure that the appliance is level

after installation. Levelling feet are fitted to the

appliance to accommodate uneven floors.

GENERAL NOTES ON USING YOUR

APPLIANCE

We suggest that you run the oven elements for 10

– 15 minutes at 220oC to burn off any residue from

their surfaces. The procedure should be repeated

with the grill for approximately 5 – 10 minutes.

During this period an odour may be emitted, it is

therefore advisable to open a window for

ventilation.

ABOUT CONDENSATION AND STEAM

When food is heated it produces steam similar to a

boiling kettle. The oven is vented to allow some of

this steam to escape. However, always stand back

from the appliance when opening the oven door to

allow any build up of steam or heat to release.

If the steam comes into contact with a cool surface

on the outside of the appliance, e.g. a trim, it will

condense and produce water droplets. This is

quite normal and is not caused by a fault on the

appliance.

To prevent discolouration, regularly wipe away

condensation and also soilage from surfaces.

For your safety wallcoverings at the rear of the

appliance should be securely fixed to the wall.

THE COOLING FAN FOR THE

CONTROLS

The cooling fan may not switch on except when

used for a longer period of time. The cooling fan

may run on, and turn on and off after the control

knobs have been switched off, until the appliance

has cooled. Do not switch the appliance off at its

power point until the fan has cooled the appliance

down.

CONTROL PANEL INDICATOR NEON

The light will indicate whether the oven is switched

on, the neon also indicates when the set

temperature has been reached. The neon will turn

on and off during use to show that the temperature

is being maintained.

COOKWARE

Baking trays, oven dishes etc., should not be

placed directly against the grid covering the fan at

the back of the oven.

Do not use baking trays larger than 30cm x 35cm

(12” x 14”) as they will restrict the circulation of

heat and may affect performance.

GRILL AND OVEN FURNITURE

The following items of grill/oven furniture have

been supplied with the appliance. If you require

replacements of any of the items listed below,

please contact your local Service Force Centre

quoting the relevant part number.

1 grill pan

(311409401)

1 grill pan handle

(311468100)

NOTE

If you require an additional handle for your grill

pan, this can be ordered from your local Service

Force Centre by quoting part number

311479800\6.

1 grill pan grid

(311419801)

1 straight shelf

for grilling

2 straight shelves

for oven cooking
