TRENDnet TEW-657BRM User manual
TEW-657BRM
rev:03.11.2010
The 150Mbps Wireless N ADSL 2/2+ Modem Router (model TEW-657BRM)
provides both Internet access and a high speed wireless n network.
No need to buy a separate modem and router. Install this device easily and
browse the Internet, download files, and talk online with the latest in wireless n
technology.
Installation is a breeze with a step-by-step setup wizard. Manage access to the
Internet with built-in content filtering. Connect computers, game consoles,
media players, and storage devices to the integrated 4-port switch. The latest
in wireless encryption and a double firewall protect your valuable data. One-
touch Wi-Fi Protected Setup (WPS) connects WPS peripheral devices at the
touch of a button.
TEW-657BRM(V1.0R)
150Mbps Wireless N ADSL 2/2+ Modem Router
wireless
FEATURES
• 4 x 10/100Mbps Auto-MDIX RJ-45 LAN ports
• 1 x RJ-11 WAN port (Internet)
• Supports DSL service providers with Dynamic IP, Static IP and PPPoE connection types
• High-speed data rates up to 150Mbps using an IEEE 802.11n connection
• Network Address Translation (NAT) firewall
• Quality of Service (QoS) technology prioritizes gaming, Internet calls and streaming video
• Supports Wireless Distribution System (WDS) to extend your wireless network
• Multiple SSID support
• Wi-Fi Protected Setup (WPS) button for simple network connectivity
• Universal Plug and Play (UPnP) and Application Level Gateway (ALG) support for Internet applications such as email, FTP,
gaming, remote desktop, Net Meeting, telnet and more
• Provides additional security with Internet Access Control (MAC Address and URL Filtering)
• Easy remote management via Web browser
？
• Advanced wireless encryption: WEP, WPA/WPA-RADIUS and WPA/WPA2-PSK
• Indoor coverage up to 100 meters (330ft.) and outdoor coverage up to 300 meters (980ft.)*
• 3-year limited warranty
* Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage
will vary depending on interference, network traffic, building materials and other conditions.
WPS Button
Modulation
UPnP
WAN Port (ADSL line Interface)
Power Adapter
Power Consumption
Dimension (L x W x H)
Firewall
LED Indicator
Temperature
Antenna
• Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX)
• 1x RJ-11 port Complies with ADSL standards: ANSI T1.413 Issue2
G.992.1 (G.dmt, Annex A)
G.992.2 (G.lite)
• Wireless: IEEE 802.11b, IEEE 802.11g, based on IEEE 802.11n technology
• Complies with ADSL2 standard: G.992.3 (G.dmt.bis)
• VC and LLC Multiplexing
• Max. 90% (non-condensing)
• Bridged/Routed Ethernet over ATM (RFC1483/2684) • OAM F4/F5 loop-back
• PPP over ATM (RFC2364)
• 802.11b: up to 11Mbps
• Enables Wi-Fi Protected Setup (WPS) function
• PPP over Ethernet (RFC2516)
• 1~ 11 (FCC), 1~13 (ETSI)
• WEP(HEX/ASCII): 64/128-bit
• 802.11g: 15dBm (typical) • 8802.11n: 13dBm (typical)
• WPA(AES/TKIP): WPA/WPA2-RADIUS, WPA-PSK/WPA2-PSK
• 802.11b: 18dBm (typical)
• NAT, Access Control, URL Content Filter
• Power, WPS, LAN1~LAN4, WLAN, ADSL and Internet
• 12V DC, 1A external power adapter
• 150 x 145 x 26 mm (5.9 x 5.7 x 1.0 in.)
• 6.03 watts (max)
• Operation: 0°C ~ 40°C (32°F ~ 104°F) • Storage: -20°C ~ 60°C (-4°F ~ 140°F) non-condensing
• 275 g (9.7 oz)
• CE, FCC
• 2.415 ~2.484GHz band
• DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM)
• 802.11g: up to 54Mbps • 802.11n: up to 135Mbps
• 1 x 2dBi detachable dipole antenna
• 802.11b: -83dBm (typical) @ 11Mbps • 802.11g: -66dBm (typical) @ 54Mbps • 802.11n: -62dBm (typical) @ *135Mbps
Weight
Frequency
Wireless
Standard
Hardware
SPECIFICATIONS
LAN
ATM
Receiving Sensitivity
Humidity
Certifications
Data Rate
Security
Output Power
Channels
• 4 x 10/100Mbps Auto-MDIX ports
• UPnP IGD 1.0 compliant
• Complies with ADSL2+ standard: G.992.5 Annex A
TEW-657BRM
rev:03.11.2010
TEW-657BRM(V1.0R)
150Mbps Wireless N ADSL 2/2+ Modem Router
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
RELATED PRODUCTS
PACKAGE CONTENTS
PACKAGE CONTENTS
TEW-644UB
TEW-643PI
TEW-648UB 150Mbps Mini Wireless N USB Adapter
• CD-ROM (User's Guide)
• Power adapter (12V DC, 1A)
• Cat. 5 Ethernet cable (1.5m /5ft.)
• RJ-11 telephone cable (9m /3ft)
Wireless N USB Adapter
• TEW-657BRM
Wireless N PCI Adapter
• Multi-Language Quick Installation Guide
TEW-657BRM(V1.0R)
150Mbps Wireless N ADSL 2/2+ Modem Router
150Mbps Wireless N
ADSL 2/2+ Modem Router
(TEW-657BRM)
Workstation with Wireless N
PCI Adapter
(TEW-643PI)
Notebook
Mini Wireless N USB Adapter
(TEW-648UB)
with 150Mbps
ADSL Ready Line
Phone Jack
Notebook with 300Mbps
Wireless N USB Adapter
(TEW-624UB)
